Vivicam 3710

User Manual

English

041119TP

Contents

Contents……………………………………………………………1

Section 1 Getting to Know Your ViviCam 3710……………..3

Section 2 Getting Up and Running……………………………6

Section 3 Camera Mode…………………………………………9

Section 4 Playback Mode………………………………………23

Section 5 Viewing Images and Movie Clips on a TV………27

Section 6 Transferring Data to a Computer…………………28

Section 7 Troubleshooting……………………………………..31

Section 8 Specifications and Requirement………………….32

FCC Statement:

This equipment has been tested and found to comply with the limits for a Class

B digital device, pursuant to Part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against harmful interference in a

residential installation. This equipment generates, uses and can radiate radio

frequency energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and

on, the user is encouraged to try to correct the interference by one or more of

thefollowingmeasures:

-- Reorient or relocate the receiving antenna.

-- Increase the separation between the equipment and receiver.

-- Connect the equipment into an outlet on a circuit different from that

to which the receiver is connected.

-- Consult the dealer or an experienced radio/TV technician for help

Section 1

Getting to Know Your ViviCam 3710

Overview

Your new ViviCam 3710 delivers high quality digital-still images as well as short movie clips

using a 3 Megapixel sensor. With the optical viewfinder and built-in 1.5" TFT color LCD

monitor, you can compose images and then examine them in detail. The camera adjusts

exposure and color balance automatically or lets you change these settings manually and

features a 4x digital zoom to increase your control over the pictures you capture. A Movie

Hotkey lets you switch rapidly between capturing movie clips and capturing photographs.

Memory is built in tothe camera so you can capture images and movie clips without installing a

memory card. Thememory card slot allows you to increase the storage capacity if you wish.

When you want to print out images, play movie clips to friends, post images on websites or

inside emails, images and movie clips can be downloaded from the camera to a computer

where you have the option of editing them using ArcSoft PhotoImpression and ArcSoft

VideoImpression software provided.

Front View

Flash

Viewfinder

ShutterButton

Self

imer LED

Lens Cover

Rear View

ðThe mode button ( ) is used to switch between the two mainoperation modes. Turn

to section 3, Camera Mode, and section 4,Playback Mode, for full details

ðThe direction button ( ) is used in Camera Mode for general setting, and in the

Playback Mode to navigate through menus. Turn to section 3, Camera Mode, and

section 4, Playback Mode, for full details

ðFor information on using the PC Mode/Movie button ( ), turn to Section 6,

Transferring Data to a Computer

Side View

TV Out Port

USBPort

Macro Switch

Battery / SD Card

Cover

Eyelet for Wrist Strap

ReleaseButton

Power Button

Mode Button

Wrist Strap

LCD Monitor

Direction Button

PC Mode / Movie Button

Speaker

ðFor information on fitting batteries, turn to Loading the Batteryin section 2.

ðTo learn how to install a memory card, turn to Inserting an Optional SD Cardin

section 2.

ðFor information on transmitting images and movie clips to a computer using the TV

Out ( ) and USB ( ) ports, turn to Section 5,Viewing Images and Movie Clips

on a TV, and Section 6, Transferring Data to a Computer respectively.

ðThe Macro Switch ( //) is used when capturing images with different lengths of

focus. Turn toCapturing Close-Up Imagesin section 3 for full details.

Bottom View

TripodMount

Section 2

Getting Up and Running

Loading the Batteries

You must insert 2 AA size alkaline batteries

before the camera can be used:

Press down and hold the release button,

and slide the battery/SD Card cover in the

direction of the arrowto release the cover.

2. Insert the batteries according to the correct

polaritymarks(+or -).

3. Close the battery/SD card cover firmly.

SD Card

Battery/SD

Card Cover

AA Size Battery

Release Button

SD Card

Battery/SD

Card Cover

AA Size Battery

Release Button

Inserting and Removing an SD Card (Optional)

The camera comes with built-in memory, allowing you to store im ages and movie clips. You

canexpand the memory capacity by using an optional SD (Secure Digital) memory card. To

insert a memory card, refer to the figure above and:

1. Open the battery/SD card cover.

2. Insert thememorycardwith the metal surface facingthe front of the camera.

3. Press the card into the slot until it locks into position.

To remove an installed SD card, press the card inwards to release it. When the card pops out,

gently slide it from its slot.

Release

button

Note

A memory card that has previously been used in

another device may have to be formatted before it can

be used. Turn to Formatting a Memory Card in

section 3 for details.

Note

When a memory card is fitted, images and movie clips

are saved on the card rather than on the built-in

memory..

Protecting Data on an SD Card

Valuable data on an SD Card can be protected by preventing any new data beingwrittenonto

the same card. To do this:

Slide the write-

protected tab on

the side of the SD memory

card

to LOCK.

Opening and Closing the Lens Cover

To open the lens cover, simply use a finger

to slide the cover across, as shown.

To close the lens cover, slide in the other

direction.

Turning the Camera On and Getting Started

To turn on once the batteries are loaded:

1. Open the lens cover first, and then press down and hold the power

button for ONE second.

2. When the camera is turned on, the GREEN LED underneath the

direction button will light up.

Note

If you only want to use the camera in Playback

Mode (i.e. you don’

t intend to capture any

images) you do not have to open the lens cover

before turning on the camera.

Note

The camera will turn itself off automatically if it is

left unused for THREE minutes.

ðTo capture a picture, press the shutter button. For full details turn to

Capturing Images in Section 3.

ðTo view stored images press the mode button once to move to

Playback Mode. Press a second time to return to Camera Mode. For

full details turn to Section 4, Playback Mode.

ðTo capture a movie clip, press the PC mode/movie button to

temporarily switch to MovieModethentheshutterbuttontostartfilming.

For full details of capturing movie clips turn to Capturing Movies in

Section3.

Turning the Camera Off

Toturnoffthecamera:

1. Press down and hold the power button for ONE second. The GREEN

LED will light out.

2. Close the lens cover.

Section 3

Camera Mode

Direction Button Functions

The Camera Mode is for capturing images and short movies. In this mode, the direction button

has the following functions:

Right button: LCD monitor on but information off →

Monitor off →Monitor on with information

Left button: Self-timer on/off

Up button: Digital zoom in

Down button:Digital zoom out

Enter button:Enter options menu

Note

Press the mode button to switch between

Camera Mode and Playback Mode.

LCD Monitor Information

The indicators shown maydisplay

on the LCD

monitor when images

are recorded to indicate

the following:

78 The number of images that can still

captured at current resolution.

Single Image (photograph) Mode

Movie Mode

Multisnap (continuous shooting) Mode

SDcardinserted

MacroMode

Self-timer Mode

Auto-flash

Flash off

Battery indicator: full power /

medium power / low power /

powerempty

Up Button

EnterButton

RightButton

Left Button

Down Button

Up Button

EnterButton

RightButton

Left Button

Down Button
