OWNER’S GUIDE

& INSTALL GUIDE

MODEL

3121V

The company behind Viper®Auto

Security Systems is Directed.

Since its inception, Directed

has had one purpose, to provide

consumers with the finest vehicle

security and accessories available.

The recipient of nearly 100

patents and Innovations Awards

in the field of advanced electronic

technology.

Quality Directed products are sold

and serviced throughout North

America and around the world.

Call (800) 876-0800 for more

information about our products

and services.

Directed is committed to delivering

world class quality products and

services that excite and delight our

customers.

NO ONE DARES

COME CLOSE ®

Vista, CA 92081

www.directed.com

Table of Contents

Congratulations ...........................................................................1

Standard Remote Conﬁguration .....................................................2

2-Button Transmitter ......................................................................2

Remote Learning..................................................................2

Arming...............................................................................3

Disarming...........................................................................4

Aux....................................................................................5

Auto Re-Arming ...................................................................5

Panic..................................................................................5

Anti Motorcycle-Jacking........................................................6

Emergency Override ............................................................6

Pin Number Setting..............................................................7

Valet Mode ........................................................................7

Memory Function.................................................................8

Feature Settings ...................................................................8

Power Saving (Sleep) Mode................................................11

System Maintenance...................................................................12

Battery Replacement...........................................................12

Battery Disposal ................................................................12

Installation Guide.......................................................................13

Government Regulations .............................................................17

Limited Lifetime Consumer Warranty.............................................19

Congratulations

Congratulations on the purchase of your state-of-the-art Power

Sports Alarm System. Reading this Installer and Owner’s Guide

prior to using your system will help maximize the use of its many

features. For more information please visit us online (see back cov-

er for URL). For any additional questions please contact your autho-

rized Directed dealer or Directed at 1-800-753-0600. Additional

support is also available at: http://support.directed.com.

Note: This system is equipped with a sleep mode to lower cur-

rent draw. After 96 hours of no activity, the system’s sleep mode

turns on and RF communication shuts down. If your system is not

responding to remotes, you may need to cycle ignition to wake

the unit up before remotes will control the system again.

3121 (500-10745) Version 1.0

Standard Remote Conﬁguration

Function Button Action

Arm

A U X

Press and release

Disarm

A U X

Press and release

Panic

A U X

Press and hold (any system state)

Aux Output

A U X

Press and release (any system state)

Tilt bypass

A U X

Press and release within 5 seconds of arming

system

All Sensor Bypass

A U X

Press and release 2 times within 5 seconds

of arming system

Anti-Jacking (On & Off)

A U X

Press and hold (ignition on & system

disarmed)

Valet mode

A U X

Cycle ignition on & off twice, then press

and release

2-Button Transmitter

Remote Learning

In case the remote is lost, or you want to add another remote (up

to 4 max), perform the following procedure:

1. With the system disarmed, turn the ignition ON & OFF 5

times within 15 seconds, and stay in the ON position on

the ﬁfth time you turn the ignition ON. 3 seconds later the

Siren will chirp 3 times to indicate the system entered remote

learning mode.

2. Press any button on the remote. The siren will chirp the num-

ber of times corresponding to the sequence of the remote

location in the system. For example, the ﬁrst remote learned

to the system will chirp once, the second two times, and so

on, until a total of 4 remotes are learned to the system.

3. Up to 4 remotes can be learned to the system. If you want to

learn a 5th remote, the 1st remote will be cleared from the

system, and when you learn a 6th remote, the 2nd remote

will be cleared, and so on.

4. To exit learn mode – The system will exit learn mode automat-

ically after 8 seconds or you can manually exit learn mode

by turning the ignition OFF. The siren will emit one long chirp

to indicate that learn mode has been exited.

Note: If your remote is lost or stolen, you can clear old remotes

from the system by simply learning the remaining remotes up to

4 times.

Arming

With the system disarmed and the ignition OFF, press the

A U X

button

once. The siren will chirp once, parking lights will ﬂash once, and

LED will ﬂash quickly. After 8 seconds, the system will fully arm,

and LED will ﬂash slowly and engine will be disabled and all

trigger zones will be active.

Ignition Trigger

In armed mode, if the ignition is turned on, the system will be

triggered and the siren will sound, and the parking lights will ﬂash

30 seconds. The system will repeat this 30 second-cycle of siren

and parking light ﬂashes until the ignition is turned OFF. After the

ignition is turned to OFF, the system will complete the current 30

second cycle before the siren and parking lights stop.

Tilt/Shock Sensor Trigger

1. Sensitivity for Tilt/Shock sensors are adjustable, see FUNC-

TION SELECT MENU 1&2.

2. If the motorcycle is tilted/moved:

• If the system is in Sleep mode: At ﬁrst, the siren will

chirp and parking lights will ﬂash 10 times, then the

siren will sound continuously for 30 seconds with park-

ing light ﬂashes.

• If the system is in Wake mode: The siren and parking

lights will trigger continuously for 30 seconds.

Note: Any alarm zone can be triggered up to 8 times per arming

cycle.

Arming and Bypassing Tilt Sensor

After arming the system, press

A U X

once within 5 seconds. The

system will emit one long chirp to indicate that the Tilt sensor is

bypassed. In this mode, the LED will ﬂash twice every 2 seconds.

Arming and Bypassing Tilt and Shock Sensor

After arming the system, press

A U X

twice within 5 seconds, The

system will emit one long chirp to indicate that the Tilt sensor is

bypassed and then will chirp three more times to indicate that

shock sensor is also bypassed. In this mode, the LED will ﬂash

twice every 2 seconds.

Disarming

In armed mode, press

A U X

once. The siren will chirp twice, the

parking lights will ﬂash twice, and the system will be disarmed.

If the alarm was triggered during armed mode, the siren will chirp

4 times when disarming. The parking lights will ﬂash a number of

times to indicate the last zone that was triggered when the system

was armed.

Table of Zones

Parking Light Flash System Triggered Zone

4 times Tilt/Shock sensor triggered

5 times Instant triggered

6 times Loop wire triggered

7 times Ignition triggered

Aux

Press and release

A U X

and

A U X

. An optional auxiliary function, such

as lighting or radio turn on, can be controlled by pressing these

buttons. By default, the aux channel sends a 1-second pulse on

the aux wire. This can change to a latched output that stays on

when the command is sent, and then turns off when the command

is sent again.

Auto Re-Arming

Note: This is an optional feature that needs to be turned on. See

“Feature Settings” on page 8 for more information.

After disarming and no ignition activity, the system will re-arm after

60 seconds. During the 60 second countdown, the LED will ﬂash

quickly. When the system re-arms, the siren will chirp and the

parking lights will ﬂash once.

Panic

If you are threatened near your motorcycle, you can attract at-

tention by triggering the system with your transmitter. Just press

A U X

for 2 seconds to enter panic mode. The siren will sound for 10

second, and the parking lights will ﬂash for 10 seconds. Press

A U X

to stop panic.

Anti Motorcycle-Jacking

1. With the ignition ON, press and hold

A U X

for 2 seconds. The

LED will ﬂash quickly indicating that motorcycle-jacking mode

is activated. The siren will chirp once every 3 seconds. After

chirping 5 times, the siren will chirp once every 1.5 second.

After chirping 8 times, the siren will sound continuously; the

parking lights will continuously ﬂash and the engine will be

disabled. (Press and hold

A U X

for 2 seconds to exit motorcy-

cle-jacking mode). During anti motorcycle-jacking mode, the

siren will long chirp, when the key turns to OFF, the siren will

stop, and the parking lights will stop ﬂashing as long as the

ignition turns OFF. If key has been turned to ON again, the

siren will sound and engine will not be able to start.

2. To exit anti motorcycle jacking: EMERGENCY OVERRIDE.

Emergency Override

In armed mode or motorcycle-jacking mode, if the remote is not

working or lost, refer to following step for Emergency Override:

1. Turn the ignition to ON/OFF 5 times within 10 second and

stay in ON position on the ﬁfth turn on. The LED will turn solid

for 2 seconds.

2. Once the LED turns OFF, turn the ignition OFF, and the LED

will start ﬂashing.

3. Once the LED ﬂashes the number of times corresponding to

the digit of your PIN code, turn the ignition ON. The Siren

will chirp 4 times, and the parking lights will ﬂash 7 times to

indicate the system is disarmed.

Pin Number Setting

Factory Preset Pin Number: 1 (Led Blinks One Time)

In disarming mode, turn ignition ON/OFF 8 times within 15 sec-

ond, and end in ON position on the eighth time. The LED will stay

solid for 2 seconds, then the system enters into PIN setting mode:

1. Conﬁrm the original (preset) PIN Number

Turn the ignition OFF within 10 second, LED will start blink-

ing slowly to conﬁrm the preset PIN Number. Turn the igni-

tion ON once the LED blinks the number of times correspond-

ing to the original preset PIN number. If correct, the siren will

chirp once (if siren does not chirp, it means the preset PIN

number conﬁrmation failed. Start the process over again if

this happens);

2. Input the new PIN NUMBER

Right after the siren chirp once, turn the ignition Off, and the

system enters into new PIN number setting, and LED starts

to ﬂash. When the LED ﬂashes the number of times wanted

for the new PIN number, turn the ignition ON then OFF. The

LED will ﬂash the new PIN number once, and then exit PIN

NUMBER setting mode.

Exit Pin Number Setting

If no operation is performed or the wrong initial password was

entered within 30 seconds, the system will exit PIN NUMBER set-

ting mode.

Valet Mode

You can prevent your security system from automatically arming by

using valet mode, this is very useful when washing the motorcycle,

for example. In valet mode, the security system will not arm, even

with the transmitter, but any accessory functions will continue to

work normally.

Tabla de contenidos

Otros manuales de Sistema de seguridad de Viper

Viper

Viper Directed 4706V Manual de usuario

Viper

Viper Home 502M Manual de usuario

Viper

Viper 3606V Manual de usuario

Viper

Viper home 503V Manual de usuario

Viper

Viper Home 504S Manual de usuario

Viper

Viper 5704 Responder LC3 Manual de usuario

Viper

Viper 5806V Manual de usuario

Viper

Viper Home Manual de usuario

Manuales populares de Sistema de seguridad de otras marcas

Inner Range

Inner Range Concept 2000 Manual de usuario

Climax

Climax Mobile Lite R32 Instrucciones de montaje

CADDX

CADDX NX-6 Manual de usuario

FBII

FBII XL-31 Series Manual de usuario

Johnson Controls

Johnson Controls PENN Connected PC10 Manual de usuario

Aeotec

Aeotec Siren Gen5 Manual de usuario

Blaupunkt

Blaupunkt SA 2700 Manual de usuario

IDEAL

IDEAL Accenta Manual del propietario

AJAX

AJAX DoubleButton Manual de usuario

Swann

Swann SW-P-MC2 Manual de usuario

Ecolink

Ecolink Siren+Chime Manual de usuario

Digital Monitoring Products

Digital Monitoring Products XR150 Manual de usuario

EDM

EDM Solution 6+6 Wireless-AE Manual de usuario

Highway Safety Group

Highway Safety Group EA401 Manual de usuario

Siren

Siren LED GSM Manual de usuario

Detection Systems

Detection Systems 7090i Instrucciones de montaje

Se-Kure Controls

Se-Kure Controls MicroMini SK-4841 Manual de usuario

Siemens

Siemens FDM273 Manual de usuario
