Viking Designer DFUW1441CR Manual de usuario

F20690 EN (082009J)

Viking Range Corporation

111 Front Street

Greenwood, Mississippi 38930 USA

(662) 455-1200

For product in ormation,

call 1-888-VIKING1 (845-4641)

or visit the Viking web site at

vikingrange.com

Viking Installation Guide

DDHK 9 Designer Handle Kit

For Use With DFUR, DFUW, DFRI, DFIM, DFWD101 Models

IMPORTANT–Please Read and Follow!

2 3

•Be ore beginning, please read these instructions completely and care ully.

•Use caution during assembly to minimize scratches.

•Do not remove permanently a ixed labels, warnings or plates rom the product. This may

void the warranty.

•Please re er to the DFUR, DFUW, DFRI, DFIM, DFWD101 Installation Instructions or more

in ormation on installing the door panel.

•The installer should leave instructions with the customer who should retain for local

inspector’s use and future reference.

Parts Included

Required Tools

Handle Installation

To Install:

Installation with Wooden Full Overlay

Custom Door Front

1. Locate the wooden custom panel.

2. Using the illustrations on the next page, layout the handle location on the panels. It is

recommended that masking tape be placed where the our holes will be drilled to help mark

the hole placement and to prevent any damage to the door when drilling the holes.

3. The Designer handle will be mounted using (4) o the #10 x 3/4” Hex head screws provided.

Using the 3/16”(0.5 cm) drill bit, drill completely through the door in the hole locations.

Using the 7/16” (1.1 cm) bit, counter-bore our holes 1/2” (1.2 cm) deep max. on the

BACKSIDE o the custom door panel.

4. Attach the Designer handle to the panel using (4) #10 x 3/4” screws provided.

Par Quan i y

Designer Handles

#10 x 3/4” Hex Head Screws

Installation Instructions

(1)

(4)

Electric Drill

3/16” (0.5 cm) Drill Bit

7/16” (1.1 cm) Spade or Forstner Bit (Counterbore)

Tape Measure

Hex Head Screw Driver

Masking Tape and Pencil

13/16”

(2.1 cm)

26-7/16”

(67.2 cm)

DFUW - WINE CELLAR

DFIM - ICE MACHINE

DFUR - BEVERAGE CENTER

DFRI - COMBINATION BEVERAGE CENTER/ICE MAKER

3/4” (1.9 cm)

Full Overlay

Panel

3/16” (0.5 cm)

Thru Hole

7/16” (1.1 cm)

Counter Bore x 1/2”

Depth (max)

13/16”

(2.1 cm)

Section A-A

DFWD101 - WARMING DRAWER

4 5

Handle Installation

CUSTOM FRONT INSTALLATION

1. Open the drawer and remove the pan.

2. Center the custom ront on the inside panel.

3. Attach the custom ront with the (6) six #8 x 3/4” screws provided.

13/16” (2.1 cm)

26-7/16”

(67.2 cm)

1-1/4”

(3.2 cm)

Custom Front Installation

Mounting Screws

(4) - #8 x 3/4”

Cavity

Assembly

(6) - #8 x 3/4” screws

to attach custom front

Custom

Front

Speci ications subject to change without notice.

3/4” (1.9 cm)

Full Overlay

Panel

3/16” (0.5 cm)

Thru Hole

7/16” (1.1 cm)

Counter Bore x 1/2”

Depth (max)

13/16”

(2.1 cm)

Section A-A
