ViewSonic ViewBook VS13550 Manual de usuario
- UserGuide
- Guidedel’utilisateur
- Guíadelusuario
- 使用手冊 (簡中)
VNB145
ViewBook
ViewSonic®
ModelNo.:VS13550
ViewSonic VNB145 i
ImportantSafetyInstructions
1. DO NOT press or touch the LCD Screen. DO NOT place notebook PC with small items,
they may scratch LCD Screen or penetrate the vents of notebook PC.
2. DO NOT expose notebook PC to dirty or dusty environment. Keep the environment clean
and dry.
3. DO NOT place notebook PC on uneven or unstable work surface.
4. DO NOT place or drop objects on the top of notebook PC. DO NOT shove any foreign
objects into notebook PC. DO NOT close with force the LCD Screen lid.
5. DO NOT expose notebook PC to strong magnetic or electrical elds; DO NOT place oppy
disks near or on notebook PC as this may cause the loss of data on the oppy disks.
6. DO NOT leave notebook PC facing the sun as it can damage the LCD Screen, especially
when in a car.
7. SAFE TEMPERATURE: This notebook PC should only be used in environments with
ambient temperatures between 5°C (41°F) and 35°C(95°F).
8. DO NOT expose notebook PC to or use near liquids, rain, or moisture.
9. Caution: there is a risk of explosion if the battery is replaced by an incorrect type. Dispose
of used batteries according to the instructions.
10. DO NOT throw notebook PC in municipal waste. Check local regulations for disposal of
electronic products. Please recycle the Battery Pack, and check with your Local Authority
or retailer for an advice on recycling.
11. Notebook PC and its power adapter may produce some heat during operation or charging
of its internal battery. DO NOT leave notebook PC on your lap or any part of your body in
order to prevent discomfort or injury from heat exposure.
12. INPUT RATING: Refer to the rating label on notebook PC and make sure that the Power
Adapter complies with that rating. Only use accessories recommended by ViewSonic.
13. Check the connections between the main unit and attached devices before turning on your
notebook PC.
14. DO NOT use notebook PC during eating to avoid dirtying your notebook PC.
15. DO NOT insert anything into notebook PC that may result in short circuit or can damage
the electronic circuits.
16. Power off your notebook PC, if you want to install or remove some external devices, which
do not support hot-plugging-in.
17. Disconnect your notebook PC from the electrical outlet and remove any installed batteries
before cleaning the notebook PC. Keep your notebook PC away from children.
18. DO NOT disassemble notebook PC. Only a certied service technician should perform
repairs on your computer.
19. Use only the Battery Packs approved by ViewSonic.
20. Notebook PC has vents to disperse heat. DO NOT place notebook PC on soft objects
(e.g.: bed, sofa, your lap) as this can block the air ow from those vents and cause system
halt due to overheating.
ViewSonic VNB145 ii
DeclarationofRoHSCompliance
This product has been designed and manufactured in compliance with Directive 2002/95/EC
of the European Parliament and the Council on restriction of the use of certain hazardous
substances in electrical and electronic equipment (RoHS Directive) and is deemed to comply
with the maximum concentration values issued by the European Technical Adaptation
Committee (TAC) as shown below:
Substance
ProposedMaximum
Concentration
ActualConcentration
Lead (Pb) 0,1% < 0,1%
Mercury (Hg) 0,1% < 0,1%
Cadmium (Cd) 0,01% < 0,01%
Hexavalent Chromium (Cr6+) 0,1% < 0,1%
Polybrominated biphenyls (PBB) 0,1% < 0,1%
Polybrominated diphenyl ethers (PBDE) 0,1% < 0,1%
Certain components of products as stated above are exempted under the Annex of the RoHS
Directives as noted below:
Examples of exempted components are:
1. Mercury in compact uorescent lamps not exceeding 5 mg per lamp and in other lamps not
specically mentioned in the Annex of RoHS Directive.
2. Lead in glass of cathode ray tubes, electronic components, uorescent tubes, and
electronic ceramic parts (e.g. piezoelectronic devices).
3. Lead in high temperature type solders (i.e. lead-based alloys containing 85% by weight or
more lead).
4. Lead as an allotting element in steel containing up to 0.35% lead by weight, aluminium
containing up to 0.4% lead by weight and as a cooper alloy containing up to 4% lead by
weight.
ViewSonic VNB145 iii
CopyrightInformation
Copyright © ViewSonic® Corporation, 2010. All rights reserved.
Microsoft®, Windows®, Windows NT®, and the Windows® logo are registered trademarks of
Microsoft® Corporation in the United States and other countries.
ViewSonic®, the three birds logo, OnView®, ViewMatch™, and ViewMeter® are registered
trademarks of ViewSonic® Corporation.
Intel®, Pentium®, and Atom™ are registered trademarks of Intel Corporation.
Disclaimer: ViewSonic® Corporation shall not be liable for technical or editorial errors or
omissions contained herein; nor for incidental or consequential damages resulting from
furnishing this material, or the performance or use of this product.
In the interest of continuing product improvement, ViewSonic® Corporation reserves the right
to change product specications without notice. Information in this document may change
without notice.
No part of this document may be copied, reproduced, or transmitted by any means, for any
purpose without prior written permission from ViewSonic® Corporation.
ProductRegistration
To meet your future needs, and to receive any additional product information as it becomes
available, please register your product on the Internet at:
www.viewsonic.com. The ViewSonic® Wizard CD-ROM also provides an opportunity for you to
print the registration form, which you may mail or fax to ViewSonic®.
ForYourRecords
ProductName:
ModelNumber:
DocumentNumber:
SerialNumber:
PurchaseDate:
VNB145
ViewSonic ViewBook
VS13550
VNB145-1_UG_ENG Rev. 1A 04-20-10
Productdisposalatendofproductlife
ViewSonic® is concerned about the preservation of our environment. Please dispose of this
product properly at the end of its useful life. For the recycling information, please refer to our
website:
1. USA: www.viewsonic.com/company/green/recycle-program/
2. Europe: www.viewsoniceurope.com/uk/support/recycling-information/
3. Taiwan: recycle.epa.gov.tw
ViewSonic VNB145
Contents
Chapter 1: Preparing the netbook for use
Package contents ......................................................................1
Insert the battery ........................................................................1
Connect the power adapter .......................................................1
Chapter 2: Turning on the VNB145
Top View with the lid open .........................................................2
Turn on the VNB145 ..................................................................2
The function keys .......................................................................3
Chapter 3: Conguring BIOS, installing an operating system and drivers
Installing an operating system ...................................................4
Other settings of the Setup CMOS Utility ..................................5
Installing the drivers ...................................................................8
Chapter 4: Devices and interfaces
Expand the interface devices .....................................................9
Chapter 5: Control Center Functions
Using the Control Center .........................................................10
ViewSonic VNB145 1
User'sGuide
Dear customer!
Thank you for choosing ViewSonic’s VNB145 netbook.
Your VNB145 has powerful information processing capabilities and mobile
characteristics. Whether you are in the ofce, at home, or travelling,
VNB145 is your effective assistant that accompanies you all the time.
This manual will help you master the methods and techniques of using
VNB145 to the best.
Chapter1
Preparingthenetbookforuse
NO.1.1 Package contents
First of all, please open the VNB145 box and carefully remove the contents;
check if anything is missing or damaged.
NO.1.2 Insert the battery
Insertingthebattery Removingthebattery
NO.1.3 Connect the power adapter
ViewSonic VNB145 2
Chapter2
TurningontheVNB145
NO.2.1 Top View with the lid open
Open the lid of your VNB145. Please be careful when
opening or closing the lid; do not do it with excessive
force as you can damage the netbook.
NO.2.2 Running the notebook
Make sure the computer has connected the adapter or the battery before
press the power button for one second to run the computer.
1 Power indicator Green light ashing means into sleep appearance.
2
The battery and
charging status
indicator
If the light being orange means the battery is charging, if the light being
green means it's been fully charged.
3 HDD indicator Green light ashing means the HDD is been used.
4 WIFI signal
indicator
Green light ashing means it's connected the wireless AP,while the
green light not shining means the wireless Internet access is not turned
on.
ReferenceVersion
ViewSonic VNB145 3
NO.2.3 The function keys
Key Description
Fn+Esc Enter suspend state
Fn+F1 Enable or disable the touchpad
Fn+F2 Enable or disable 3G (option)
Fn+F3 Enable or disable the wireless module
Fn+F4 Enable or disable sound
Fn+F5 Decrease the brightness of the LCD
Fn+F6 Increase the brightness of the LCD
Fn+F7 Turn ON of OFF the video-out signal for externally connected LCD or projector
Fn+F8 Turn ON or OFF the internal display
Fn+F9 Customizable; the default setting is to open a web browser
Fn+F10 Customized; Support NVIDIA Optimus switch technology. (The OS shall be
Windows Vista, Windows 7 Home Basic model at least) (For select models)
Fn+F11 Customizable; the default setting is to open a media player
Fn+F12 Open or close the Bluetooth (option)
Fn+ ↑ Increase the sound volume
Fn+ ↓ Decrease the sound volume
ViewSonic VNB145 4
Chapter3
ConguringBIOS,installingan
operatingsystemanddrivers
NO.3.1 Installing an operating system
Before installing OS, you will need to set up BIOS to allow boot from USB-
CD/DVD drive. To do that, turn on VNB145, and press F2 when prompted
to run BIOS setup.
After you enter BIOS setup application, use the [→] and [←] keys to choose
BOOT section of the main menu, select your USB-CD/DVD drive in the
Boot priority list and use the [ + ] and [ - ] buttons to set the order in which
drives and devices will be checked for a useable OS to boot at the time of
startup.
ViewSonic VNB145 5
NO.3.2 Other settings of the Setup CMOS Utility
Main Menu: Set system time and date, check the related information such
as: CPU ID,CPU,BIOS, EC, MB version, System Memory, and the extended
Memory, etc.
• Sata Port: the settings specic to SATA devices can be done here.
The specic operation can be found in the System promoted screens.
