Disclaimer and Warning
Legends
1.1 Introduction
1.Product Introduction
1.
Important NoteWarning
Q30TIR-1352 is a high-precision 3-axis gimbal integrated with a
2.13MP 30x optical zoom SONY camera and dual 640*480 IR
thermal sensor with 13mm + 52mm lens. It supports visible optical
zoom, IR thermal and visible PIP switch, IR color palette switch,
photographing and video, target tracking, thermal digital zoom.
When the external GPS and time input, the OSD can display angle,
zoom times,GPS and real-time and tracking frame, also can select
to turn off the OSD. The 3 axis gimbal can achieve stabilization in
yaw, roll and pitch. The integrated design of damping system and
gimbal can greatly reduce mechanical vibration. Even with 30x
optical zoom, it can fast focus and the image can be very stable.
The 13mm and 52 mm dual thermal cameras can be switched to 1~4
optical zoom. It can show the the fire point in the forest and the
location of people or animals and so on via the heat source detec-
tion.
Congratulations on purchasing your new Viewpro product. Please
read this entire document carefully. Failure to read or follow instruc-
tions and warnings in this document may result in damage to your
Viewpro product. Disassemble the gimbal camera by user is not
permitted, as which may cause the camera does not work normally.
Viewpro accepts no liability for damage, injury or any legal responsi-
bility incurred directly or indirectly from the use of this project. The
user shall observe safe and lawful practices including, but no limited
to, those set forth in the manual.
