Service instructions

for heating engineers

Vitodens 333

Type WS3B

Compact gas fired condensing boiler

4.2 to 19 kW natural gas and LPG version

For applicability, see the last page

VITODENS 333

5692 568 GB 12/2005 Please keep safe

Please follow these safety instructions closely to prevent accidents and

material losses.

Safety instructions explained

Danger

This symbol warns against the

risk of injury.

!Please note

This symbol warns against the

risk of material losses and

environmental pollution.

Note

Details identified by the word "Note"

contain additional information.

Target group

These instructions are exclusively

designed for qualified personnel.

&Work on gas equipment must only

be carried out by a qualified gas fit-

ter.

&Work on electrical equipment must

only be carried out by a qualified

electrician.

&The system must be commissioned

by the system installer or a qualified

person authorised by the installer.

Regulations

Observe the following when working

on this system

&all legal instructions regarding the

prevention of accidents,

&all legal instructions regarding

environmental protection,

&the Code of Practice of relevant

trade associations,

&all current safety regulations as

defined by DIN, EN, DVGW, TRGI,

TRF, VDE and all locally applicable

standards.

If you smell gas

Danger

Escaping gas can lead to

explosions which may result in

serious injury.

&Never smoke. Prevent naked

flames and sparks. Never

switch lights or electrical

appliances ON or OFF.

&Close the gas shut‐off valve.

&Open windows and doors.

&Remove all people from the

danger zone.

&Notify your gas or electricity

supplier from outside the

building.

&Shut off the electricity supply

to the building from a safe

place (outside the building).

If you smell flue gas

Danger

Flue gas can lead to life‐threa-

tening poisoning.

&Shut down the heating sys-

tem.

&Ventilate the boiler room.

&Close all doors leading to the

living space.

Safety instructions

5692 568 GB

Working on the system

&When using gas as fuel, also close

the main gas shut‐off valve and

safeguard against unauthorised

reopening.

&Isolate the system from the power

supply and check that it is no longer

'live', e.g. by removing a separate

fuse or by means of a mains isola-

tor.

&Safeguard the system against

unauthorised reconnection.

!Please note

Electronic modules can be

damaged by electro‐static dis-

charges.

Touch earthed objects, such as

heating or water pipes, to dis-

charge static loads.

Repair work

!Please note

Repairing components which

fulfil a safety function can com-

promise the safe operation of

your heating system.

Replace faulty components

only with original Viessmann

spare parts.

Ancillary components, spare and

wearing parts

!Please note

Spare and wearing parts which

have not been tested together

with the heating system can

compromise its function. Instal-

ling non‐authorised compo-

nents and non‐approved

modifications/conversion can

compromise safety and may

invalidate our warranty.

For replacements, use only ori-

ginal spare parts from

Viessmann or those which are

approved by Viessmann.

Safety instructions (cont.)

Safety instructions

5692 568 GB

Initial start-up, inspection, maintenance

Steps –initial start-up, inspection and maintenance .................................... 6

Further details regarding the individual steps .............................................. 9

Coding

Code 1........................................................................................................ 42

Code 2........................................................................................................ 44

Resetting codes to the delivered condition .................................................. 61

Service scans

Service level overview ................................................................................ 62

Temperatures, boiler coding card and brief scans ....................................... 63

Checking outputs (relay test) ...................................................................... 66

Scanning operating conditions and sensors ................................................ 67

Troubleshooting

Fault display ............................................................................................... 70

Calling up fault codes from the fault memory (fault history) .......................... 71

Fault codes................................................................................................. 72

Repairs ...................................................................................................... 80

Function description

Constant temperature control unit ............................................................... 90

Weather–compensated control unit............................................................. 92

Extensions for external connections............................................................ 95

Control functions ........................................................................................ 99

Remote control DIP switches ...................................................................... 105

Electronic combustion control unit............................................................... 105

Designs

Connection and wiring diagram –internal connections ................................ 107

Connection and wiring diagrams –external connections.............................. 109

Parts lists .................................................................................................. 111

Commissioning/service reports ............................................................... 118

Specification............................................................................................. 119

Certificates

Declaration of conformity ............................................................................ 120

Manufacturer's certificate according to the 1st BImSchV [Germany]............. 121

Index

5692 568 GB

Keyword index .......................................................................................... 122

Index (cont.)

Index

5692 568 GB

For further information regarding individual steps, see the pages indicated.

Commissioning steps

Inspection steps

Maintenance steps Page

!!!



•01. Filling the heating system ................................................. 9

•02. Venting the boiler .................................................................. 10

•03. Venting the heating system............................................... 10

•04. Filling the siphon with water............................................. 11

••• 05. Checking all connections on the primary and DHW

side for leaks

•06. Checking the power supply connection

• • 07. Setting the time and date (if required) –only for

weather‐compensated control units.............................. 11

•08. Selecting the language (if required) ‐only for

weather‐compensated control units.............................. 11

••• 09. Pivoting down the control unit for commissioning

and maintenance work........................................................ 12

• • 10. Checking the gas type......................................................... 12

•11. Gas type conversion (only for operation with LPG) .13

••• 12. Function sequence and possible faults ....................... 14

••• 13. Checking the static and supply pressure .................... 15

•14. Setting the maximum output ............................................ 17

•15. Checking the balanced flue system soundness

(annular gap check) ............................................................. 18

• • 16. Removing the burner and checking the burner

gasket (replace gasket every two years)...................... 19

• • 17. Checking the burner gauze assembly........................... 20

• • 18. Checking and adjusting the ignition and ionisation

electrodes ................................................................................ 21

• • 19. Cleaning the combustion chamber/heating

surfaces and fitting the burner ........................................ 22

Steps –initial start-up, inspection and maintenance

Initial start-up, inspection, maintenance

5692 568 GB

Commissioning steps

Inspection steps

Maintenance steps Page

!!!



• • 20. Checking the condensate drain and cleaning the

siphon........................................................................................ 23

• • 21. Checking the neutralising system (if installed)

•22. Testing the anode earth current with an anode

tester.......................................................................................... 23

•23. Cleaning the DHW cylinder ............................................... 24

•24. Checking and replacing the magnesium anode (if

required)................................................................................... 24

•25. Returning the DHW cylinder into use ............................ 25

••• 26. Checking the diaphragm expansion vessel and

system pressure

••• 27. Checking the function of all safety valves

••• 28. Checking the tightness of electrical connections

••• 29. Checking all gas equipment for soundness at

operating pressure............................................................... 25

••• 30. Checking the combustion quality................................... 26

••• 31. Checking the ionisation current...................................... 28

••• 32. Checking the external LPG safety valve (if

installed)

•33. Matching the control unit to the heating system ...... 28

•34. Adjusting the heating curve (only for weather‐

compensated control units).............................................. 34

•35. Connecting the control unit to the LON system

(only for weather‐compensated control units) .......... 37

•36. Implementing a user check (in conjunction with

the LON system for weather‐compensated control

units).......................................................................................... 39

•37. Instructing the system user .............................................. 39

•38. Scanning and resetting the "Maintenance" display 40

Steps –initial start-up, inspection and . . . (cont.)

Initial start-up, inspection, maintenance

5692 568 GB

Commissioning steps

Inspection steps

Maintenance steps Page

!!!



••• 39. Locking the control unit and fitting the front

panels........................................................................................ 41

Steps –initial start-up, inspection and . . . (cont.)

Initial start-up, inspection, maintenance

5692 568 GB

Filling the heating system

!Please note

Unsuitable fill water increases the level of deposits and corrosion and

may lead to boiler damage.

&Thoroughly flush the entire heating system prior to filling it with water.

&Only use fill water of potable quality.

&Fill water with a water hardness in excess of 3.58 mmol/l must be sof-

tened, e.g. with the small softening system for heating water (see the

Vitoset pricelist).

&An anti‐freeze additive suitable for heating systems can be mixed with

the fill water.

1. Check the inlet pressure of the dia-

phragm expansion vessel.

2. Close the gas shut‐off valve.

3. Fill the heating system at the fill

valve in the heating return (on the

connection set or on site).

(Minimum system pressure

> 0.8 bar).

Note

If the control unit has not been

switched ON prior to filling the sys-

tem, then the servo drive of the

changeover valve will still be in its

central position, and the system

will be completely filled.

4. If the control unit had already been

switched ON before filling began:

Start the control unit and activate

the fill program via coding "2F:2".

Note

To call up coding level 1 and for

setting the coding address, see

page 42.

For function and details of the fill

program, see page 100.

Whilst the fill program runs, the dis-

play shows "bF" (Vitotronic 100) or

"Filling" (Vitotronic 200).

5. Close the boiler fill & drain valve.

6. Set code "2F:0".

Further details regarding the individual steps

Initial start-up, inspection, maintenance

5692 568 GB

Venting the boiler

1. Close the shut‐off valves on the

heating water side.

2. Connect the drain hose on valve

Awith a drain outlet.

3. Open valve Aand the fill valve in

the heating return and vent at

mains pressure, until no sound of

escaping air can be heard any-

more.

4. Close valve Aand the fill valve in

the heating return and open the pri-

mary shut‐off valves.

Venting the heating system

1. Close the gas shut‐off valve and

switch ON the control unit.

2. Activate the venting program via

coding "2F:1".

Note

To call up coding level 1 and for

setting the coding address, see

page 42.

For function and sequence of the

venting program, see page 100.

Whilst the venting program runs,

the display shows "EL"

(Vitotronic 100) or "Venting"

(Vitotronic 200).

3. Check the system pressure.

Further details regarding the individual steps (cont.)

Initial start-up, inspection, maintenance

5692 568 GB

Otros manuales para VITODENS 333

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Caldera de Viessmann

Viessmann

Viessmann Vitodens 222-F Manual de usuario

Viessmann

Viessmann Vitoflame 100 Instrucciones de funcionamiento

Viessmann

Viessmann VITODENS 050-W Manual de usuario

Viessmann

Viessmann VITOCELL 100-U Manual de usuario

Viessmann

Viessmann Vitodens 100-W Guía rápida

Viessmann

Viessmann VITODENS 200 WB2A Nota de publicación

Viessmann

Viessmann VITOCELL 100-V Guía rápida

Viessmann

Viessmann VITOPLEX 200 Type SX2A Instrucciones de funcionamiento

Viessmann

Viessmann VITODENS 050-W Manual de usuario

Viessmann

Viessmann VITODENS 200 Guía

Viessmann

Viessmann Vitodens 200-W System Instrucciones de funcionamiento

Viessmann

Viessmann VITOCROSSAL 300 Instrucciones de funcionamiento

Viessmann

Viessmann VITOCROSSAL 200 Manual de usuario

Viessmann

Viessmann Vitodens 200-W System Instrucciones de funcionamiento

Viessmann

Viessmann Vitogas 100 GS1 Series Manual de usuario

Viessmann

Viessmann VITOROND 100 VR1 Series Guía rápida

Viessmann

Viessmann Vitodens 100-W WB1A Series Guía

Viessmann

Viessmann VITOCROSSAL 300 Instrucciones de funcionamiento

Viessmann

Viessmann Vitorond 100 Instrucciones de funcionamiento

Viessmann

Viessmann B2TB004 Manual de usuario

Viessmann

Viessmann Vitodens 100-W B1HA 26Vitodens 100-W B1HA 35Vitodens 100-W B1KA... Guía rápida

Viessmann

Viessmann VITOPLEX 100 Instrucciones de funcionamiento

Viessmann

Viessmann VITOROND 200 Instrucciones de funcionamiento

Viessmann

Viessmann Vitodens 100-W Manual de usuario

Manuales populares de Caldera de otras marcas

Vaillant

Vaillant uniSTOR VIH SW GB 500 BES Manual de usuario

Radijator

Radijator BIO max 23.1 Manual de usuario

Brunner

Brunner BSV 20 Manual de usuario

Buderus

Buderus Logamax GB062-24 KDE H V2 Manual de usuario

Potterton

Potterton 50e Hoja de datos

UTICA BOILERS

UTICA BOILERS TriFire Manual de usuario

Joannes

Joannes LADY Series Manual

ECR International

ECR International UB90-125 Manual de instrucciones

Froling

Froling FHG Turbo 3000 Manual de usuario

Froling

Froling P4 Pellet 8 - 105 Manual de usuario

U.S. Boiler Company

U.S. Boiler Company K2 Manual de usuario

Henrad

Henrad C95 FF Manual de usuario

NeOvo

NeOvo EcoNox EF 36 Manual de usuario

Potterton

Potterton PROMAX SL 12 Manual de usuario

Eco Hometec

Eco Hometec EC 25 COMPACT Manual de usuario

Baxi

Baxi Prime 1.24 Manual de usuario

REXNOVA

REXNOVA ISA 20 BITHERMAL Manual de usuario

Radiant

Radiant R2K 55 Manual
