Service instructions

for contractors

VIESMANN

Vitodens 200-W

Type WB2B, 45 and 60 kW

Wall mounted gas fired condensing boiler

Natural gas and LPG version

For applicability, see the last page

VITODENS 200-W

5692 760 GB 11/2008 Please keep safe.

Please follow these safety instructions closely to prevent accidents and mate-

rial losses.

Safety instructions explained

Danger

This symbol warns against the

risk of injury.

!Please note

This symbol warns against the

risk of material losses and envi-

ronmental pollution.

Note

Details identified by the word "Note" con-

tain additional information.

Target group

These instructions are exclusively

designed for qualified personnel.

■ Work on gas equipment must only be

carried out by a qualified gas fitter.

■ Work on electrical equipment must

only be carried out by a qualified elec-

trician.

■ The system must be commissioned by

the system installer or a qualified per-

son authorised by the installer.

Regulations

Observe the following when working on

this system

■ all legal instructions regarding the pre-

vention of accidents,

■ all legal instructions regarding envi-

ronmental protection,

■ the Code of Practice of relevant trade

associations,

■ all current safety regulations as

defined by DIN, EN, DVGW, TRGI,

TRF, VDE and all locally applicable

standards,

■ Gas Safety (Installation & Use) Regu-

lations

– the appropriate Building Regulation

either the Building regulations, the

Building Regulation (Scotland),

Building Regulations (Northern Ire-

land),

– the Water Fittings Regulation or

Water Bylaws in Scotland,

– the current I.E.E. Wiring Regula-

tions.

If you smell gas

Danger

Escaping gas can lead to explo-

sions which may result in serious

injury.

■ Never smoke. Prevent naked

flames and sparks. Never

switch lights or electrical appli-

ances ON or OFF.

■ Close the gas shut-off valve.

■ Open windows and doors.

■ Remove all people from the

danger zone.

■ Notify your gas or electricity

supplier from outside the build-

ing.

■ Shut off the electricity supply to

the building from a safe place

(outside the building).

Safety instructions

5692 760 GB

If you smell flue gas

Danger

Flue gas can lead to life-threat-

ening poisoning.

■ Shut down the heating system.

■ Ventilate the boiler room.

■ Close all doors leading to the

living space.

Working on the system

■ When using gas as fuel, also close the

main gas shut-off valve and safeguard

against unauthorised reopening.

■ Isolate the system from the power sup-

ply and check that it is no longer 'live',

e.g. by removing a separate fuse or by

means of a main isolator.

■ Safeguard the system against unau-

thorised reconnection.

!Please note

Electronic modules can be dam-

aged by electro-static dis-

charges.

Touch earthed objects, such as

heating or water pipes, to dis-

charge static loads.

Repair work

!Please note

Repairing components which ful-

fil a safety function can compro-

mise the safe operation of your

heating system.

Replace faulty components only

with original Viessmann spare

parts.

Ancillary components, spare and

wearing parts

!Please note

Spare and wearing parts which

have not been tested together

with the heating system can com-

promise its function. Installing

non-authorised components and

non-approved modifications/con-

version can compromise safety

and may invalidate our warranty.

For replacements, use only orig-

inal spare parts from Viessmann

or those which are approved by

Viessmann.

Safety instructions

Safety instructions (cont.)

5692 760 GB

Commissioning, inspection, maintenance

Steps - commissioning, inspection and maintenance.......................................... 6

Further details regarding the individual steps....................................................... 8

Codes

Code 1.................................................................................................................. 38

Code 2.................................................................................................................. 41

Resetting codes to their delivered condition......................................................... 62

Service scans

Service level overview ......................................................................................... 63

Temperatures, boiler coding card and brief scans .............................................. 64

Checking outputs (relay test)................................................................................ 67

Scanning operating conditions and sensors ........................................................ 68

Troubleshooting

Fault display......................................................................................................... 71

Fault codes........................................................................................................... 73

Repairs................................................................................................................. 83

Function description

Constant temperature control unit........................................................................ 91

Weather-compensated control unit...................................................................... 92

Extensions for external connections (accessories).............................................. 94

Control functions.................................................................................................. 98

Remote control DIP switches............................................................................... 104

Electronic combustion control unit........................................................................ 105

Designs

Connection and wiring diagram – internal connections ....................................... 107

Connection and wiring diagram – external connections....................................... 108

Parts lists............................................................................................................ 110

Commissioning/service reports

............................................................................................................................. 115

Specification....................................................................................................... 116

Certificates

Declaration of conformity...................................................................................... 118

Manufacturer's certificate according to the 1st BImSchV [Germany]................... 118

Index

5692 760 GB

Keyword index.................................................................................................... 119

Index

Index (cont.)

5692 760 GB

For further information regarding the individual steps, see the page indicated

Commissioning steps

Inspection steps

Maintenance steps Page

•1. Filling the heating system.............................................. 8

•2. Venting the boiler........................................................... 9

•3. Venting the heating system........................................... 9

•4. Filling the siphon with water......................................... 10

••• 5. Checking all connections on the heating water side

and DHW side for leaks

•6. Checking power supply connection

• • 7. Setting the time and date (if required) – only for

weather-compensated control units............................. 11

•8. Selecting the language (if required) – only for weather-

compensated control units............................................ 12

• • 9. Checking the gas type.................................................... 12

•10. Gas type conversion (only for operation with LPG).... 13

••• 11. Function sequence and possible faults....................... 13

••• 12. Checking the static and supply pressure..................... 15

•13. Setting the maximum output ........................................ 17

•14. Checking the balanced flue system for tightness

(annular gap check)........................................................ 18

• • 15. Removing the burner and checking the burner gasket

(replace gasket every 2 years)...................................... 19

• • 16. Checking the burner gauze assembly & replacing, if

required........................................................................... 21

• • 17. Checking and adjusting the ignition and ionisation

electrodes........................................................................ 22

• • 18. Cleaning the combustion chamber/heat exchanger

and installing the burner................................................ 22

• • 19. Checking the condensate drain and cleaning the

siphon.............................................................................. 24

Commissioning, inspection, maintenance

Steps - commissioning, inspection and maintenance

5692 760 GB

Commissioning steps

Inspection steps

Maintenance steps Page

• • 20. Checking the neutralising system (if installed)

• • 21. Checking the diaphragm expansion vessel and

system pressure............................................................. 24

••• 22. Checking function of safety valves

••• 23. Checking electrical connections for tightness

••• 24. Checking gas equipment for tightness at operating

pressure .......................................................................... 24

••• 25. Flue gas emissions test................................................. 25

••• 26. Checking the external LPG safety valve (if installed)

•27. Matching the control unit to the heating system ........ 26

•28. Adjusting the heating curves (only for weather-

compensated control units)........................................... 31

•29. Connecting the control unit to the LON system (only

for weather-compensated control units)...................... 34

•30. Instructing the system user........................................... 36

•31. Scanning and resetting the "Service" display............. 37

Commissioning, inspection, maintenance

Steps - commissioning, inspection and… (cont.)

5692 760 GB

Filling the heating system

!Please note

Unsuitable fill water increases the level of deposits and corrosion and may

lead to boiler damage.

■ Thoroughly flush the entire heating system prior to filling it with water.

■ Only use fill water of potable quality.

■ Soften fill water with a water hardness in excess of the following values, e.g.

with a small softening system for heating water (see the Viessmann Vitoset

pricelist):

– Vitodens 200-W to 45 kW: 3.0 mol/m3

– Vitodens 200-W from 60 kW and multi-boiler systems: 2.0 mol/m3

■ An antifreeze additive suitable for heating systems can be mixed with the

fill water. The antifreeze manufacturer must verify its suitability.

1. Check the pre-charge pressure of the

diaphragm expansion vessel.

2. Close the gas shut-off valve.

3. Fill the heating system at the boiler fill

& drain valve A (on the connection

set, accessories or on-site). Minimum

system pressure > 1.0 bar.

4. Close boiler fill & drain valve A.

Commissioning, inspection, maintenance

Further details regarding the individual steps

5692 760 GB

Venting the boiler

1. Close the shut-off valves on the heat-

ing water side.

2. Connect the drain hose at the boiler

fill & drain valve B (on the connec-

tion set, accessories or on-site).

3. Open valves A and B and vent

using mains pressure until no more

air noise is audible.

4. Close valves A and B and open

the heating water shut-off valves.

Venting the heating system

1. Close the gas shut-off valve and

switch ON the control unit ON/OFF

switch.

2. Activate the venting program via cod-

ing address "2F:1".

Note

To call up code 1 and for setting the

coding address, see page 38.

For function and sequence of the

venting program, see page 99.

Whilst the venting program runs, the

display shows "EL" (constant tem-

perature control unit) or "Entlüf-

tung" (Venting) (weather-compen-

sated control unit).

3. Check the system pressure.

Commissioning, inspection, maintenance

Further details regarding the individual steps (cont.)

5692 760 GB

Filling the siphon with water

ACB

1. Remove retaining clip A and pull out

insert B.

2. Fill siphon C with water and reas-

semble.

Note

Install the supply hose the correct

way round.

Commissioning, inspection, maintenance

Further details regarding the individual steps (cont.)

5692 760 GB

Otros manuales para Vitodens 200-W System

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Caldera de Viessmann

Viessmann

Viessmann VITOCROSSAL 200 Manual de instrucciones

Viessmann

Viessmann Vitodens 200-W System Manual de usuario

Viessmann

Viessmann Vitodens 100 WB1A Guía rápida

Viessmann

Viessmann VITODENS 200 Instrucciones de funcionamiento

Viessmann

Viessmann Vitotronic 100 GC1 Guía rápida

Viessmann

Viessmann VITOGAS Guía de inicio rápido

Viessmann

Viessmann Vitodens 100-W WB1B Series Manual de usuario

Viessmann

Viessmann VITOROND 200 Type VD2 Manual de instrucciones

Viessmann

Viessmann VITOCELL 100-B Instrucciones de funcionamiento

Viessmann

Viessmann VITODENS 333 WS3A Manual de usuario

Viessmann

Viessmann Vitorond 100 Manual de instrucciones

Viessmann

Viessmann VITODENS 200-W B2HE 85 Manual de usuario

Viessmann

Viessmann VITODENSd 100-W Manual de instrucciones

Viessmann

Viessmann VITOPLEX 200 Type SX2A Instrucciones de funcionamiento

Viessmann

Viessmann B2HB 45 Manual de usuario

Viessmann

Viessmann Vitoladens 300-C Manual de usuario

Viessmann

Viessmann Vitodens 100-W Manual de usuario

Viessmann

Viessmann Vitodens 111-W Guía rápida

Viessmann

Viessmann Vitodens 300 Manual de usuario

Viessmann

Viessmann VITOLADENS 300-W Instrucciones de funcionamiento

Viessmann

Viessmann VITODENS 050-W Guía rápida

Viessmann

Viessmann VITODENS 200 Manual de usuario

Viessmann

Viessmann Vitodens series Manual de usuario

Viessmann

Viessmann VITODENS 200 Manual de usuario

Manuales populares de Caldera de otras marcas

Vaillant

Vaillant uniSTOR VIH SW GB 500 BES Manual de usuario

Radijator

Radijator BIO max 23.1 Manual de usuario

Brunner

Brunner BSV 20 Manual de usuario

Buderus

Buderus Logamax GB062-24 KDE H V2 Manual de usuario

Potterton

Potterton 50e Hoja de datos

UTICA BOILERS

UTICA BOILERS TriFire Manual de usuario

Joannes

Joannes LADY Series Manual

ECR International

ECR International UB90-125 Manual de instrucciones

Froling

Froling FHG Turbo 3000 Manual de usuario

Froling

Froling P4 Pellet 8 - 105 Manual de usuario

U.S. Boiler Company

U.S. Boiler Company K2 Manual de usuario

Henrad

Henrad C95 FF Manual de usuario

NeOvo

NeOvo EcoNox EF 36 Manual de usuario

Potterton

Potterton PROMAX SL 12 Manual de usuario

Eco Hometec

Eco Hometec EC 25 COMPACT Manual de usuario

Baxi

Baxi Prime 1.24 Manual de usuario

REXNOVA

REXNOVA ISA 20 BITHERMAL Manual de usuario

Radiant

Radiant R2K 55 Manual
