Viessmann Vitodens 100-W Manual de usuario

7826 213 v1.0 CA 11/2007

Safety and Installation Requirements

Please ensure that these instructions are read and understood before commencing installation. Failure to comply with the

instructions listed below can cause product/property damage,severe personal injury, and/or loss of life.

Working on the equipment

The installation, adjustment, service,

and maintenance o this product must

be done by a licensed professional

heating contractor who is quali ied and

experienced in the installation, service,

and maintenance o hot water boilers.

There are no user serviceable parts on

the boiler, burner, or control.

Ensure main po er supply to

equipment, the heating system, and all

external controls has been deactivated.

Close main gas supply valve. Take

precautions in both instances to avoid

accidental activation o power during

service work.

Ensure that the installation

literature of other applicable

components is referenced.

Removing Front Enclosure Panel

1. Remove the screw at the top o

boiler .

2. Press down on springs at bottom

o boiler and remove the ront

enclosure panel .

3. Drain heating water rom boiler.

4. Flip control console down .

Please file in Service Binder

Installation Instructions

for use by heating contractor

Heating Return Connection Pipe,

Part No. 7826 213

or Vitodens 100-W, WB1A boilers

Installation

Burner Removal

1. Disconnect electrical cables rom

gas valve , and ignition

trans ormer unit .

2. Remove connection hose rom

air pressure switch.

3. Loosen the itting on the gas

connection pipe.

4. Loosen our screws, remove

burner and disconnect all

electrical cables rom blower

motor .

7826 213 v1.0 CA

F C

B A

To avoid damage to the burner, do

not lay burner on its cylindrical

burner tube.

Failure to heed this caution may

cause damage to the burner tube,

hich may lead to improper

operation.

CAUTION

Installation

Replacing the Heating Return Connection Pipe

1. Loosen screw, remove plug-in

connector and connector pipe .

2. Loosen connector and remove

condensate pipe .

3. Dismantle the vent system, loosen

the two screws on the vent pipe

adaptor and remove adaptor.

4. Remove the plug-in connector and

dismantle the return pipe .

5. Loosen the mounting bracket nuts

and remove the heat exchanger .

6. Loosen screw and remove plug-in

connector rom the heat

exchanger .

7. Attach new plug-in connector to

heat exchanger using screw.

8. Reassemble the boiler in reverse

order. Pay extra attention to correct

installation o gasket

onto the

heat exchanger when

reinstalling the vent pipe

adaptor .

9. Fill the boiler with water, lush and

check or leaks.

Vitodens 100

Installation and Service

Instructions

Use ne gaskets and pipe sealing

compound on all gas and ater pipe

connections.

Lubricate all hot ater O-rings ith

supplied lubricant.

B D

IMPORTANT

Gas leaks can lead to explosions.

Check gas pipe seals to ensure that

there are no leaks.

WARNING

Viessmann Manu acturing Company Inc.

750 McMurray Road

Waterloo, Ontario •N2V 2G5 •Canada

1-800-387-7373 •Fax (519) 885-0887

www.viessmann.ca •in o@viessmann.ca

Viessmann Manu acturing Company (U.S.) Inc.

45 Access Road

Warwick, Rhode Island •02886 •USA

1-800-288-0667 •Fax (401) 732-0590

www.viessmann-us.com •in o@viessmann-us.com

Printed on environmentally riendly

(recycled and recyclable) paper.

Technical in ormation subject to change without notice. Printed on environmentally riendly

(recycled and recyclable) paper.
