Vicon VC2500-DSP Manual de usuario

MODELSVC2500=DSP,VC25OOC=DSP

VC2600-DSPANDVC26OOC-DSP

COLORDIGITAL

CAMERAS

VICON INDUSTRIES INC. 89 ARKAY DRIVE, HAUPPAUGE. NY 11788

TEL:516-95%CCTV(2288)

fAX:518-951-CCTV(2288)

.TOLL

FREE:800-645-9116

UK:44/(0)1489-566300

lNFOFAX:800-287-1207

+WORLD WIDE WEB:www.vicon-cctvxom

VICON,

To prevent fire or shock hazard, do not

expose the unit to rain or moisture.

The symbol is intended to alert the user to the presence

of important operating and maintenance (servicing)

Sk 1?66 instructions in the I iterature accompanying the appliance.

The symbol is intended to alert the user to the presence

of uninsulated “dangerous voltage” within the product’s

enclosure that may be of sufficient magnitude to

SA 1965 constitute a risk of electric shock to persons,

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELEC-

TRIC SHOCK, DO NOT REMOVE

COVER(OR BACK). NO USER-

SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALI-

FIED SERVICE PERSONNFL

CAUTION:

To prevent electric shocks and

risk of fire hazards, do NOT

use other than specified power

source.

Warning --This equipment has been tested and found to comply with

the limits for a Class A digital device, pursuant to part

15 of the FCC Rules.

These limits are designed to provide reasonable

protection against harmful interference when the

equipment is operated in a commercial environment.

This equipment generates, uses, and can radiate radio

frequency energy and, if not installed and used in

accordance with the instruction manual, may cause

harmful interference to radio communications, Operation

of this equipment in a residential area is likely to cause

harmful interference in which case the user wi II be

required to correct the interference at his own expense.

Caution --Any changes or modifications in construction of this

device which are not expressly approved by the party

responsible for compliance could void the user’s

authority to operate the equipment.

~PRECAUII~NS

1. Do not attempt to disassemble the camera.

In order to prevent electric shock, do not remove screws or

cover. There ‘are no user-serviceable parts inside.

Refer all servicing to qualified service personnel.

2. Handle the camera with care.

The camera could be damaged by improper hand

storage. ing or

3. Do not expose the camera to rain or moisture, or

operate it in wet areas.

Take immediate action if the camera becomes wet. T

the

power off and refer servicing to qualified service personnel.

Moisture can damage the camera and also create a danger of

electric shock,

4. Do not use strong or abrasive detergents when cleaning

the camera body,

Use a dry cloth to clean the camera when dirtv. In case the

dirt is hard to remove, use a mild detergent and’wipe gently,

5, Never point the camera toward the sun.

Whether the camera is used outdoors or not, never point i

toward the sun,

Use caution when operating the camera in the vicinity of spo

lights or other bright I ights and I ight reflecting objects.

6, Do not operate the camera beyond its temperature

humidity or power source ratings.

Do not use the camera in an extreme environment where high

temperature or high humidity exists. Use the camera under

conditions where temperatures are between

14”F-l22”F(-10”C

--+5O”c), and humidity is below 85%. For the correct power

supply, refer to the specification sheet,

Caution:

To prevent fire or shock hazard, UL listed wire VW-l, style

1007, should be used for the cable.

-2-

lPACKING LIST

1. Iris lens connector plug for DC drive-lpc

2, C-Mount lens adapter ring-lpc

3. Dust protective cap-lpc

-3-

ICONNECTORS

AND

CONTROLS

REAR PANEL

TOP VIEW

SIDE VIEW

CONNECTORS AND CONTROLS

Video output connector (BNC)

l,OVp-p/758

composite video signal is provided at this

connector,

@Power input connector(screw terminal)

AC24V

AC AC

Back of camera

This terminal accepts 24

“AC

power source.

Recommended Power Supply:

Minimum 300

or 7.2 W

Cautions:

1. Connect to a class 2 power supply only.

2, To prevent fire or shock hazard, UL listed wire VW-l, style

1007, should be used for the cable.

Autoiris

lens connector for video-drive lens.

This connector supplies 9 VDC power and video signal without

sync, for video-drive type

autoiris

lens.

Signal

GROUND

POWER SUPPLY

(9 VDC,

40 mA)

Back of camera

VIDEO OUTPUT (0.7 Vp-p without sync)

ICONNECTORS

AND

CONTROLS

Autoiris

lens connector for DC drive lens

This connector supplies the contort signals to the DC drive

autoir is lens.

Autoiris

lens cable

If the cable is thick

or the

plug

cover

does not fit properly,

cut this rib away

Lens plug (supplied)

3 Drive(+)

Drive(-)

Power indicator LED

E4-191

J-100

This LED turns ON only when power is supplied properly and

the DC-DC converter (or the regulator) inside the camera

works wel I.

@ALC level adjustment potentiometer for DC drive lens.

This potentiometer is used only if the camera is fitted with a

DC-drive

autoiris

lens. It is used to control the amount of

light striking the CCD image sensor.

LENS-

IRIS level

LEVEL

Monitor screen LEVEL control direction

To increase the brightness clockwise

To decrease the brightness counterclockwise

CONNECTORS AND CONTROLS

AWB HOLD push button

l Use the AWB HOLD Push Button :

When a subject is I ighted by many kinds of light.

2. When you use a special lamp, such as a sodium lamp or

mercury vapor lamp.

l How to use :

1. Select AWB of model select switch No, 8 (ATW/AWB)

2. Display a full screen of white paper or white subject on

the monitor.

3, Adjust the screen color to be white pushing AWB HOLD

Push button.

MODE SELECT SWITCH

LL/INT sw

tch

This camera can operate independently, using its internal

crystal-controlled sync generator, or it may be synchronized

using I ine-locking.

To select one or the other of these sync modes, set the DIP

switch on the rear panel to either LL or INT.

If line-locking is selected, al I the cameras in the system

must be adjusted to begin the video field scan at the same

time. This is described in the following procedures

(8,

@J).

2. NOT USED.

-7-

/C~N~IECTORS

AND

CONTROLS

continued 1

3. BLC (back1 ight compensation) ON/OFF Switch

If the subject you wish to view is too dim because of a

bright background, set the BLC switch to ON to compensate

for the bright background.

With BLC on, the background brightness may saturate in some

cases, This function may not operate properly if the object

is too small compared to the area of the background. This

function can be used with either the

inear

shutter (EE

mode) or an

autoiris

lens (Al lens mode).

WITH BLC OFF

4. ELC/ALC

Select

Switch

WITH BLC ON

This switch is-used to select EE (electronic exposure or ELC

electronic light control) mode or Al (autoiris lens or ALC

automatic I ight control) mode.

In the EE mode, a continuously variable electronic shutter is

employed to automatically control the exposure time of the

CCD image sensor according to the incoming light level.

With this mode selected, a fixed or manual iris lens can be

used instead of an

autoiris

lens. In the Al mode, the CCD

shutter speed is fixed to

l/60

(l/50)

set, and the incoming

I ight level is control led by the

autoiris

lens.

To use a video-drive type or the DC-drive type of

autoiris

lens, set this switch to the Al position.

~C~NNEU~RS

ANDcoNTRoLs

-@continued

Cautions :

1, Under bright lighting conditions such as outdoors, use an

autoiris

lens because the ELC control range is not wide

enough under these conditions.

2. Under certain unique lighting conditions, the following

phenomena may appear:

. Strong smear and/or blooming on highlight objects such

spot1

ights or windows.

sNoticeable flicker in the picture and/or color rendition

variations,

To avoid this, use an

autoiris

lens,

3. When operating in EE mode with a manual iris lens, the

depth of field of the image may be less than that

obtained by using an ALC lens. Depth of field varies

inversely with the iris opening. Thus, using this camera

in EE mode with the manual iris lens fully opened may

result in less depth of field, and the distant objects in the

picture may be seen out of focus.

4. Fixed iris or manual iris lenses may be used with the

linear shutter (EE mode) where the scene brightness

varies over a limited range.

5. Do not the EE mode when an autoir is lens is installed.

ATW/AWB

Select Switch

This camera has AUTO WHITE BALANCE (ATW), and

MANUAL WHITE BALANCE (AWB) function.

The color is automatically adjusted to the best condi

the ATW mode.

In the AWB mode, it can be adjusted for the best

manually by pushing the AWB HOLD button

(a).

tion

6. AGC ON/OFF Switch

The automatic gain function

gain in accordance with the br

7. HI-GAIN ON/OFF Switch

automatically adjusts p

ghtness of the subject.

cture

Switching the HI-GAIN switch to the ON mode while the

AGC switch (6) is on increases gain by up to 6dB over the

Off mode.

9 -
