Vertiv HMX3080T Manual de usuario

Vertiv™ Avocent®

HMX 3080T/HMX 3080R

HMX 3080TP/HMX 3080RP

HMX 4080T/HMX 4080R

HMX 4080TP/HMX 4080RP

User Manual

Vertiv™ | HMX 3080/HMX 4080 series User Manual

Technical Support Site

If you encounter any installation or operational issues with your product, check the pertinent

section of this manual to see if the issue can be resolved by following outlined procedures.

The information contained in this document is subject to change

without notice and may not be suitable for all applications. While

every precaution has been taken to ensure the accuracy and

completeness of this document, Vertiv assumes no responsibility

and disclaims all liability for damages resulting from use of this

information or for any errors or omissions. Refer to other local

practices or building codes as applicable for the correct methods,

tools, and materials to be used in performing procedures not

specifically described in this document.

The products covered by this instruction manual are manufactured

and/or sold by Vertiv. This document is the property of Vertiv and

contains confidential and proprietary information owned by Vertiv.

Any copying, use or disclosure of it without the written permission of

Vertiv is strictly prohibited.

Names of companies and products are trademarks or registered

trademarks of the respective companies. Any questions regarding

Vertiv™HMX 3080/HMX 4080 series User Manual

TABLE OF CONTENTS

1 Important Safety Instructions 1

2 Product Introduction 3

3 Product features 5

4 Package contents 7

4.1 Accessories (Optional) 9

5 Product specifications 11

5.1 HMX 3080T/HMX 3080R Specification 11

5.2 HMX 3080TP/HMX 3080RP Specification 12

5.3 HMX 4080T/HMX 4080R Specification 13

5.4 HMX 4080TP/HMX 4080RP Specification 14

6 Product Overview 17

6.1 HMX 3080T/HMX 3080R 17

6.2 HMX 3080TP/HMX 3080RP 17

6.3 HMX 4080T/HMX 4080R 19

6.4 HMX 4080TP/HMX 4080RP 19

7 Connection Diagram 21

7.1 Before Connection 22

7.2 Direct Connection 22

7.2.1 Single Transmitter to Single Receivers 22

7.2.2 Single Transmitter to Multiple Receivers 23

7.2.3 Multiple Transmitters to Single Receiver 23

7.3 Connection via a Hub/Switch 24

7.4 Network Redundancy 25

8 Operation 27

8.1 Front Panel Buttons and LED Indication 27

8.1.1 Functions of LINK/MODE (Left/Right) Buttons 27

8.1.2 LED Indication 28

8.1.3 Keyboard Hot-keys 29

8.2 OSD Menu 30

8.3 Receiver Configuration 32

8.3.1 Advanced settings 33

8.3.2 Console Collaboration 34

8.3.3 Mouse Roaming Function 34

Vertiv™ HMX 3080/HMX 4080 series User Manual

8.3.4 Video Wall Function 34

8.4 Transmitter Configuration 35

8.5 Administrator’s OSD Menu 37

9 System Upgrade 41

10 Technical Support 43

11 FCC CE Statements 45

Vertiv™ HMX 3080/HMX 4080 series User Manual

1 Important Safety Instructions

EMI Declaration: i.e. products that are EMC certified in the region or country shown will have the required

marking or declaration on the product label. The applicable declaration for that country is listed below

China warns users that this is a Class A information product, which may cause radio frequency interference

when used in indoor environments, in which case users need to take appropriate countermeasures to

respond.

Technical Support Sites: If your product encounters any installation or operational issues, review the

relevant sections of this manual to see if you can resolve the issue with the steps outlined in this manual.

For additional assistance, visit https://www.vertiv.com/en-us/support/.

Thank you for purchasing the HMX 3080/4080 Series IP KVM Extenders. With our high-quality and reliable

products, you can enjoy the convenience and benefits they bring to you.

1 Important Safety Instructions 1

Vertiv™ HMX 3080/HMX 4080 series User Manual

1 Important Safety Instructions

This page intentionally left blank

Vertiv™ HMX 3080/HMX 4080 series User Manual

2 Product Introduction

The new generation HMX 3080/HMX 4080 series is an IP-based matrix KVM extender that allows users to

transmit the computer's DVI remotely over a gigabit switched network USB, Analog audio, RS-232, and

infrared signals. The HMX 3080/HMX 4080 series includes two main units, the transmitter unit, and the

receiver unit. Those two units have their unique IP address so that they can transfer and receive KVM

signals over the Gigabit network. In a Gigabit network, multiple transmitters and multiple receivers can be

interleaved with each other to achieve IP matrix switching, depending on the network bandwidth and the

network switch deployed, the maximum number of theoretical devices can reach 65,000.

Figure 2.1 Avocent HMX 3080T/R and Avocent HMX 4080T/R

2 Product Introduction 3

Vertiv™ HMX 3080/HMX 4080 series User Manual

2 Product Introduction

This page intentionally left blank

Vertiv™ HMX 3080/HMX 4080 series User Manual

3 Product features

lSupports hot-swapping SFP optical module slots-2 Hot-plug SFP Optical Module Sockets.

lSpecific Models support PoE (Power over Ethernet).

lSupports USB 2.0 over IP pass-through for KVM application.

lSupports transmitter DVI -D local loop-back outlet (local KVM interface).

lSupports high resolutions quality video streaming up to 1920x1200 @ 60Hz.

lLow latency time<1 frame/second (less than one frame per second).

lSupports uncompressed and loss-less multichannel audio formats.

lSupports Integrated RS232 serial port for distributed remote control (IP transmission).

3 Product features 5

Vertiv™ HMX 3080/HMX 4080 series User Manual

3 Product features

This page intentionally left blank

Vertiv™ HMX 3080/HMX 4080 series User Manual
