Liebert® SmartAisle2

User manual

The content in this document is subject to change without notice. All rights, including rights of

translation, reproduced by printing, copying or similar methods, and even of parts, are reserved.

Violators will be liable for damages. All rights, including rights deriving from patent license or

registration of a utility model or design, are reserved. No part of this document may be reproduced

or transmitted in any form or by any means without the prior written consent of Vertiv Co. Ltd.

Notice

The purchased products, services, and features are stipulated by the contract made between Vertiv

Co., and the customer. All or part of the products, services, and features described in this document

may not be within the purchasing scope or the usage scope. Unless otherwise specified in the

contract, all statements, information, and recommendations in this document are provided "AS IS"

without warranties, guarantees or representations of any kind, either express or implied. The

information in this document is subject to change without notice. Every effort has been made in the

preparation of this document to ensure the accuracy of the contents, but all statements,

information, and recommendations in this document do not constitute a warranty of any kind,

express or implied.

Vertiv Co., Ltd.

China

Website:www.vertivco.com

E-mail: support@Vertivco.com

Customer service hotline: 4008876510

Asia-Pacific

Homepage: www.vertivco.com

E-mail: overseas.support@Vertivco.com

For Technical Support, users may contact the nearest Vertiv Co. local sales office or service center.

Styling used in the Guide

The styles used in this manual are defined in the following table:

Situation

Description

Warning/Danger/Caution

The Warning/Danger/Caution note indicates a hazardous or

potentially harmful situation that can result in death or

injury. It also indicates instructions that need to be adhered

to, failing which may result in danger and safety issues,

thereby having an adverse effect on the reliability of the

device and security. Even for practices not related to physical

injury, the content under the Warning heading is used for

precautions which need to be taken which, otherwise, could

result in equipment damage, performance degradation, or

interruption in service.

Note

The Note section indicates additional and useful information,

including tips and tweaks. It also calls attention to best

practices and industry-best protocols that are standardized

and help make maximum utilization of the resources at

hand. Helpful information related to the mainstream content

also comes under the Note heading helping the users get to

grips with the definitions, concepts, and terminologies used

in the manual.

Version History

Issue

Revision Date

BOM

Changes

1.0

---

Safety Precautions & Measures

In this section, the safety measures related to the entire SmartCabinet™ unit will be explained in

detail.

Read the manual prior to installation and operation of the unit. Only qualified personnel

should move, install, or service this equipment.

The user reads and takes into account all the precautions, compliance, and safety measures

before working on the equipment. The unit control must be used exclusively for the purpose

which it is intended for; the manufacturer takes no liability for incorrect use or a

modification to the unit control.

Please read this manual carefully before installing, maintaining and troubleshooting;

especially the Warning/ Danger/ Caution information in the User Guide. Apart from the User

Guide, also pay attention to the warning labels on the unit and its components.

This manual is retained for the entire service life of the machine. The user must read all the

precautions, danger, warnings, and cautionary measures mentioned in the manual prior to carrying

out any operations on the machine.

Adhere to all the notes, warnings, cautions, potential dangers, and precautions mentioned in the

manual. Read this manual before carrying out any operation on the unit.

The Warnings/Danger/Cautions/Precautions/Notes do not represent the entire safety points to be

observed and only supplementary in nature. This product is tailored for industrial, commercial, or other

professional units (such as manufacturing, electrical, and instrumentation setups) and not meant for

purposes related wholly to individuals without the credentials. The purpose of the design is well defined

and therefore, the manufacturers do not assume any responsibility for any incorrect usage. Strict

adherence to the norms and usage should be observed. In case of any improper use or modifications,

the warranty will be void; handle with care, especially the key to the product must be allocated to the

service personnel responsible for maintenance.

General Safety Instructions

Use the tools with an insulation handle.

Wear rubber gloves and safety shoes.

Avoid placing tools and metal objects on the battery surface

Remove the watches, rings, or any metal objects.

Only after all the power is disconnected, operate on the inner components of the product.

Before operating on the inner components for any maintenance, you must switch off the

mains breaker and all UPS power.

After an alarm occurs through product monitoring platform, the need for timely find the

cause, treatment failure, to avoid more trouble, damage.

Risk of electric shock

There is a risk of an electric shock which may lead to personnel injury or death: To prevent or avoid

such a situation, the following points must be taken into account:

Disconnect the control box and remote power supplies prior to working on the product.

Local codes, regulations, and protocols may vary from region to region. Therefore, adhere

to all these local protocols and rules prior to installing, operating, or servicing of the

machine.

Read all the instructions, ensure that all the parts and components are included, and check

the nameplate to ascertain that the voltage matches the available mains; Proceed with the

installation, maintenance, troubleshooting, and operating on the machine only after going

through the preceding steps.

This product is suitable only for the TT and TN type power grid; it doesn’t apply to the IT

type power grid.

Finally, read all the labels on the unit and its components before operating on those

components during installation and maintenance. The warnings and cautionary measures

mentioned in this manual are supplementary and therefore, the measures listed on the

labels of the components and the unit must be considered strictly before any operation.

PART I

Introducing SmartAisle

1 Introduction

SmartAisle2 is an intelligent, integrated infrastructure in a self-contained line-up solution that is

easy to deploy and tailored for large data centers and computer rooms. All data centers have

distinct operation and business objectives. Balancing the data center practices for capacity, space

utilization, availability, and efficiency has been tedious owing to the ever-increasing demand in the

IT space.

Enter SmartAisle2 –an enclosed complete data center solution (referred to as SmartAisle) in an

indoor environment. With Precision cooling, UPS, power management, monitoring and control

technologies and fire suppression integrated into a holistic enclosed system, this smart solution is

ideally suited for environments where dedicated IT room improvements are neither practical nor

cost-effective. It is flexible as it can be placed unobtrusively into workspaces without the clutter or

bulk associated with these kinds of solutions. It is highly effective, economical, interoperable, and

makes use of the existing infrastructure or whitespace, avoids expensive room upgrades along with

the optional fire suppression system- all in one enclosed solution. This top-notch modular

enterprise-grade solution is unique and brings together industry-best practices and latest

technologies to enable streamlined management in a compact footprint.

It is an ideal solution tailored for 19” rack hardware device, including servers, voice data, the

internet network equipment, cabinets, closure assembly and power supply, cooling, monitoring

equipment, equipment for bearer cabinets and is best suited for large data centers.

1.1 Configuration Specification for SmartAisle

The typical configuration of the SmartAisle solution is shown in Table 1-1.

Table 1-1 Configuration

Parameter

Specifications

Size

Corridor width

1200mm

Machine external dimensions

See Section 1.5.3

Overall key

indicators

Density levels

Low-density

Power Architecture

Centralized power supply

Cooling architecture

Air cooled DX based row cooling units,

independent cooling modules

Structured Cabling

Column header network wiring closet

Fire architecture

External fire, borrow building

The total number of U-bit single

module

966 (single cabinet 42U, including the

network cabinet)

Redundant power supply

The average power consumption of

a single cabinet

4kW

IT power consumption single

module

92kW

Single refrigeration module

105kW

Altitude

Less than 1000m (air conditioning derating

more than 1000m)

Mounting

Raised floor or ground installation

Voltage

standard

Voltage

(380 ~ 415) Vac ± 10%, 3N ~

frequency

50Hz / 60Hz

Colour

Pantone 877C + RAL7021

1.2 Salient Features

SmartAisle has several distinct features that make it an outstanding utility for mid-tier and large

data centers.

Efficiency

Close control of precision air cooling with an exact match with the thermal load using a variable

capacity system that provides focussed cooling with high energy savings

Intelligent Monitoring

Enables supervision and management of the environment, equipment, electric doors, roof and

alarm linkage intelligent control system in a centralized manner for the administrator.

Convenient Operations & Maintenance

Use of electric door anti-pinch safety and access control systems improves the user comfort and

safety experience.

Security Management

Use of electric doors and roof-emergency response system that enables enhanced security

feature.

Intelligent Lighting

The integrated 3-color bright lights, set display, illumination and easy-to-understand interface

to facilate appropriate space lighting needs.

Human Machine Interface

A 15-inch large control panel which is quite intuitive and advanced enables administrators and

facility managers to visualize the entire system operation in real time

1.3 Appearance and Components

The bifurcation of all components that constitute the SmartAisle solution is depicted in the

following figure (Refer Figure 1-1);

Figure 1-1 SmartAisle layout diagram

Base

Server Cabinet

Network Cabinet

Access door

Top Plate

A/C Column

Distribution Cabinet

Strong wire passage groove

Power cable trunking; copper

and fibre cable tray

Control panel

Configuration of Components

The Base enables achieving a common ground to mount the entire machine equipment,

eliminating the need to set up static flooring and providing pipeline space.

The cabinet is an ideal utility for 19 "rack-mount hardware, including servers, voice, data,

Internet, and other network equipment.

Closure assembly (Access door & Roof) enables achieving closure of the hot and cold aisles,

personnel access control, and linkage opening function.

Lighting provides an environment within the channel display, operation, and maintenance

of lighting and warning prompts.

A Bridge from the distribution cabinet helps realize the connection related to the capacity

of the network cabinet to the circuit between the enclosure management functions.

Distribution cabinet power distribution equipment enables achieving the functionality to

provide 19” rack-mount hardware.

Refrigerant equipment helps realize a 19” rack mount hardware cooling.

Monitoring device enables achieving the USMS (meaning supervision of Power, Cooling

Temperature, Humidity, Water, and Leakage) equipment monitoring and control linkage.

Local Display helps administrators or the concerned facility managers by presenting

information to achieve the overall capacity, 2D and 3D temperature fields, alarms, and PUE

to name a few.

1.4 Environmental Requirements

1.4.1 Operating conditions

The installation site of the SmartAisle should be such that the product is away from heat and

environments where there is a presence of easy-to-produce sparks, direct sunlight, corrosive gases,

and organic solvents

Otros manuales para Liebert SmartAisle2

Tabla de contenidos

Otros manuales de Unidad de control de Vertiv

Vertiv

Vertiv Liebert CW Instrucciones de instalación y mantenimiento

Vertiv

Vertiv Liebert MBSM Manual de usuario

Vertiv

Vertiv Netsure Manual de usuario

Vertiv

Vertiv Netsure Manual de usuario

Vertiv

Vertiv Liebert iCOM Instrucciones de instalación y mantenimiento

Vertiv

Vertiv Liebert NXL Manual de usuario

Vertiv

Vertiv NetSure M831A Manual de usuario

Vertiv

Vertiv eSure R48-1000e3 Manual de usuario

Vertiv

Vertiv LIEBERT RPC2 Manual de funcionamiento

Vertiv

Vertiv R48-500 Manual de usuario

Vertiv

Vertiv MPUIQ-VMCHS Manual de usuario

Vertiv

Vertiv Liebert iCOM Instrucciones de instalación y mantenimiento

Vertiv

Vertiv NetSure R24-3000 Manual de usuario

Vertiv

Vertiv LIEBERT RPC2 Manual de usuario

Vertiv

Vertiv eSure R48-2000e3 Manual de usuario

Vertiv

Vertiv eSure S48-2000e3 Manual de usuario

Vertiv

Vertiv eSure R48-3500e3 Manual de usuario

Vertiv

Vertiv LIEBERT MPX PEM Manual de usuario

Vertiv

Vertiv Net Sure SM-DU+ Manual de usuario

Vertiv

Vertiv NetSure7100 Series Manual de usuario

Vertiv

Vertiv NetSure R48-2000 Manual de usuario

Vertiv

Vertiv NetSure Series Manual de usuario

Vertiv

Vertiv Geist Manual de lista de piezas

Manuales populares de Unidad de control de otras marcas

Festo

Festo Compact Performance CP-FB6-E Manual de lista de piezas

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manual de usuario

JS Automation

JS Automation MPC3034A Manual de usuario

JAUDT

JAUDT SW GII 6406 Series Guía rápida

Spektrum

Spektrum Air Module System Manual de usuario

BOC Edwards

BOC Edwards Q Series Manual de usuario

KHADAS

KHADAS BT Magic Manual de usuario

Etherma

Etherma eNEXHO-IL Manual de usuario

PMFoundations

PMFoundations Attenuverter Manual de usuario

GEA

GEA VARIVENT Manual de usuario

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manual de usuario

Altronix

Altronix LINQ8PD Instrucciones de montaje

Eaton

Eaton Powerware Series Manual de usuario

WAGO

WAGO 750-407/040-000 Manual de usuario

Sony

Sony CCU-590 Manual de usuario

Graco

Graco 25D614 Manual de usuario

Task Force Tips

Task Force Tips YE-RF-900 Manual de programación

Shini

Shini SPV-U Series Manual de usuario
