versa CSG300 Series Manual de usuario
At a Glance
The Versa Cloud Services Gateway (CSG) 300 series appliances deliver highly secure site-to-site data connectivity to
small businesses and to home offices.
These appliances provide the following features:
• Single hardware platform that supports different CPUs and memory sizes
• Management Ethernet ports with dual use and dedicated options:
• One RJ45 RS232 console port
• One USB 2.0 management port for plugging in external LTE or WiFi modems
• One Cu GE dual purpose port for data and management
• MDI and MDIX autoswitchable EoC ports
• PoE source support on four Ethernet ports with NIC module add-on
• Wireless options:
• CSG350–Two built-in wireless slots
• CSG355 and CSG365–Three dedicated built-in wireless slots to support LTE
• External AC power supply
• Fan-based cooling
• Desktop or ceiling mount, rack-mountable in a 19” rack
CSG300 Appliance Models
The CSG300 appliances are available in the following models:
• CSG350—Compact and optimized appliance for deployment in small branches (up to 75 users) that require
advanced application and cloud intelligence with hierarchical QoS, providing a cost-effective SD-WAN solution.
• CSG355–Powerful appliance perfect for deployment in both small- and medium-sized branches that need
advanced SD-Security (NGFW and UTM) along with comprehensive advanced application and cloud-intelligent
SD-WANservices on-premises.
• CSG365—High performance, powerful appliance for deployment at a medium-sized branch locations that
require advanced application and cloud-intelligent SD-WAN services, advanced SD-Security (NGFW and UTM).
The CSG300 appliance models provide the following CPU, memory, and storage sizes. See Table 1.
Table 1: CSG300 Appliance Models
https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_300_Series/Overview/At_a_Glance
Updated: Tue, 31 Mar 2020 19:09:37 GMT
Powered by
1
CSG Appliance Model CPU Memory Storage
CSG350 Intel Rangeley with 4 cores 4 GB DRAM
(configurable to 16GB) 32 GB
CSG355 Intel Rangeley with 4 cores 8 GB DRAM
(configurable to 16GB) 32 GB
CSG365 Intel Rangeley with 4 cores (higher performance) 8 GB DRAM
(configurable to 16GB) 64 GB
Chassis Views
The CSG350 appliance is smaller in size than the CSG355 and CSG365 appliances. The CSG355 and
CSG365 appliances are physically identical.
CSG350 Appliance
Figure 1 and Figure 2 show the front and rear panels of the CSG350 appliance.
Note: The front panel is the side of the appliance with the SIM slots and two LEDs, for status and power. This is the side
that is visible when you install the appliance in an office environment. The rear panel has the power and reset buttons
and various connectors and ports.
Figure 1: Front Panel of the CSG350 Appliance
Figure 2: Rear Panel of the CSG350 Appliance
CSG355 and CSG365 Appliance
Figure 3 and Figure 4 show the front and rear panels of the CSG355. The panels for the CSG355 and CSG365
appliances are identical.
Figure 3: Front Panel of the CSG355 Appliance
https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_300_Series/Overview/At_a_Glance
Updated: Tue, 31 Mar 2020 19:09:37
GMT
Powered by
2
CSG300 Series Appliance Specifications
A CSG300 series appliance chassis is made of aluminum for optimal heat dissipation. This article lists the chassis and
regulatory compliance specifications for the CSG300 series appliance. It also lists certifications and export control
classification numbers (ECCNs) for the appliance.
Chassis Specifications
CSG350 Appliance
Table 1 lists the specifications for a CSG350 appliance chassis.
Table 1: CSG350 Series Chassis Specifications
Item Specification
Services and Slot Density
RJ-45 ports 10/100/1000 Mbps 4
External USB ports (USB 2.0) 1
RJ-45 serial console port 1
Memory DDR4 ECC DRAM 4 GB
Disk 1 SSD default size 32 GB
Disk 2 and Disk 3, USB-based Flexible
Power supply 12VDC, 5A
Power Adapter Specifications
AC input voltage 100–240 Volts
AC input line frequency 50–60 Hz
Typical power consumption 25 Watts
Chassis Physical Specifications
https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_300_Series/Components_and_Specifications/01_CSG…
Updated: Tue, 31 Mar 2020 17:58:46 GMT
Powered by
1
Item Specification
Chassis height 1.38” (34 mm)
Chassis width 7.87” (200 mm)
Chassis depth 5.91" (152 mm)
Chassis weight
2.75 lb (1.25 kg)
Chassis weight with installation kit: 1.8 kg maximum
Package Specifications
Package height 7" (17.78 cm)
Package width 16.7" (42.4 cm)
Package depth 12" (30.48 cm)
Package weight 15.4 lb (7 kg)
Operating Conditions
Temperature 0 to 40°C (32 to 104°F) at sea level
Humidity 10 to 85% relative humidity
Altitude Maximum 3000 m (10000 ft)
Noise level Less than 20 dBA
Storage Conditions
Temperature 20 to 70°C (68 to 158°F) at sea level
Humidity 10 to 85% relative humidity
Reliability
MTBF Minimum of 70,000 hours
CSG355 and CSG365 Appliance
Table 2 lists the specifications for a CSG355 and CSG365 appliance chassis.
https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_300_Series/Components_and_Specifications/01_CSG…
Updated: Tue, 31 Mar 2020 17:58:46 GMT
Powered by
2
Item Specification
Services and Slot Density
RJ-45 ports 10/100/1000 Mbps 4 + 2
External USB ports (USB 2.0) 2
RJ-45 serial console port 1
Memory DDR4 ECC DRAM CSG355: 8 GB
CSG365: 8 GB
Disk 1 SSD default size CSG355: 32 GB
CSG365: 64 GB
Disk 2 and Disk 3, USB-based Flexible
Power supply 12VDC, 5A
Power Specifications
AC input voltage 100–240 Volts
AC input line frequency 50–60 Hz
Typical power consumption 33 Watts
Chassis Physical Specifications
Chassis height 1.65” (43 mm)
Chassis width 13.8” (370 mm)
Chassis depth 6.7” (172 mm)
Rack height 1 RU
Chassis weight Chassis weight with installation kit: 2.5 kg maximum
Package Specifications
Package height 7" (17.78 cm)
Package width 16.7" (42.4 cm)
https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_300_Series/Components_and_Specifications/01_CSG…
Updated: Tue, 31 Mar 2020 17:58:46 GMT
Powered by
4
Package depth 12" (30.48 cm)
Package weight 15.4 lb (7 kg)
Operating Conditions
Temperature 0 to 40°C (32 to 95°F) at sea level
Humidity 10 to 85% relative humidity
Altitude Maximum 3000 m (10000 ft)
Noise level Less than 30 dBA
Storage Conditions
Temperature 20 to 70°C (68 to 158°F) at sea level
Humidity 10 to 85% relative humidity
Reliability
MTBF Minimum of 70,000 hours
Regulatory Compliance
Table 2 lists the regulatory compliance specifications for a CSG300 series chassis.
Table 2: CSG300 Series Regulatory Compliance Specifications
Item Specification
Safety CE Marketing
Security TPM 2.0
Designed to be FIPS 140-2 Level 2 compliant
EMC CE EMC, EN55032 Class A; FCC Part 15, Class A
Environmental RoHS
https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_300_Series/Components_and_Specifications/01_CSG…
Updated: Tue, 31 Mar 2020 17:58:46 GMT
Powered by
5
Certifications
A CSG300 series appliance complies with the certificates listed in Table 3.
Table 3: CSG300 Series Certifications
Region Certifications
Europe
¥ EN 300 328 (Bluetooth)
¥ EN 301 489-1
¥ EN 301 489-17 (Bluetooth)
¥ EN 50385 MPE(SAR Evaluation)
¥ EN 55032
¥ EN 60950-1 CE(LVD)
America
¥ FCC 47 CFR Part 15B
¥ FCC 47 CFR Part 15C, 15.247 (Bluetooth)
¥ MPE
¥ Contain FCC ID: N7NEM7455(For models with LTE)
¥ Contain FCC ID: 2ARF9CSG-W1(For models with WIFI)
Japan TBD once Japan has completed their testing
Export Control Information
Table 4 lists the ECCN, HTS, and CCATS numbers.
Table 4: ECCN, HTS, and CCATS Numbers
Item ECCN Number HTS
Number
CCATS
Number
Use of item
by Versa
MatrixSSL software module 5E002 8542310000 G161333 SSL-VPN
Proxy
QuickSec IPsec toolkit as used by Versa
Analytics, Versa Director and Versa FlexVNF 5D002 8542310000 G161333 IPSec crypto
module
Hardware-based encryption and decryption 5A002U 8542310001 G156910L1 CSG300
series
https://docs.versa-networks.com/Hardware/Cloud_Services_Gateway_300_Series/Components_and_Specifications/01_CSGÉ
Updated: Tue, 31 Mar 2020 17:58:46
GMT
Powered by
6
