Venstar T2000 Instrucciones originales

Owner’s Manual

& Installation

Instructions

7 Day Programmable •Up to 2-heat & 2-cool

with

Wi-Fi

and local

API

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for an

intentional radiator, pursuant to Part 15, subpart C of the FCC rules.These limits

are designed to provide reasonable protection against harmful interference

in a residential installation.This equipment generates, uses and can radiate

radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference in radio communications.

However, there is no guarantee that the interference will not occur in a particular

installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and

on, the user is encouraged to try to correct the interference by one or more of the

following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that of the

receiver.

• Consult the dealer or an experienced radio orTV technician for help.

Notice: Only peripherals complying with FCC limits may be attached to this

equipment. Operation with noncompliant peripherals or peripherals not

recommended by Venstar, is likely to result in interference to radio and TV

reception. Changes or modiﬁcations to the product, not expressly approved by

Venstar could void the user’s authority to operate the equipment.

FCC - INDOOR Mobile Radio Information:

To comply with FCC/IC RF exposure limits for general population / uncontrolled

exposure, the antenna(s) used for this transmitter must be installed to provide a

separation distance of at least 20 cm from all persons and must not be co-located

or operating in conjunction with any other antenna or transmitter.

This Device complies with Industry Canada License-exempt RSS standard(s).

Operation is subject to the following two conditions: 1) this device may not

cause interference, and 2) this device must accept any interference, including

interference that may cause undesired operation of the device.

Follow the Installation Instructions before proceeding. Set the

thermostat mode to “OFF” prior to changing settings in setup

or restoring Factory Defaults.

CAUTION

This Explorer Mini thermostat has the ability to receive updates to its ﬁrmware.

Periodically ﬁrmware updates are released by the manufacturer to add features

and/or performance enhancements.This manual was produced reﬂecting the

most current ﬁrmware/feature set at the time of publication, ﬁrmware rev. 1.0.

Firmware releases after rev. 1.0 may not be adequately depicted in this manual.

Please refer to the appropriate website or contact your place of purchase to learn

about changes to the thermostat after ﬁrmware release 1.0.

Under Industry Canada regulations, this radio transmitter may only operate using

an antenna of a type and maximum (or lesser) gain approved for the transmitter

by Industry Canada.To reduce potential radio interference to other users, the

antenna type and its gain should be so chosen that the equivalent isotropically

radiated power (e.i.r.p.) is not more than that necessary for successful

communication.

Cet appareil est conforme avec Industrie Canada, exempts de licence standard

RSS(s). Son fonctionnement est soumis aux deux conditions suivantes: 1) ce

dispositif ne doit pas causer d’interférences, et 2) ce dispositif doit accepter

toute interférence, y compris les interférences qui peuvent causer un mauvais

fonctionnement de l’appareil.

En vertu des règlements d’Industrie Canada, cet émetteur de radio ne peut

fonctionner en utilisant une antenne d’un type et maximale (ou moins) Gain

approuvé pour l’émetteur par Industrie Canada. Pour réduire les interférences

radio potentielles aux autres utilisateurs, le type d’antenne et son gain doivent

être choisis aﬁn que la puissance isotrope rayonnée équivalente (PIRE) ne est pas

plus de ce qui est nécessaire pour une communication réussie.

We, Venstar, declare under our sole responsibility that the device to which

this declaration relates: Complies with Part 15 of the FCC Rules. Operation is

subject to the following two conditions: (1) this device may not cause harmful

interference, and (2) this device must accept any interference received, including

interference that may cause undesired operation.

MUH-SKYPORT8

Table of Contents

Installation Instructions..........................................................1

Wire Connections.....................................................................2

Thermostat Backplate .............................................................3

Dip Switch Settings .................................................................4

Connect to WiFi.......................................................................10

Front Panel...............................................................................13

Display......................................................................................14

Basic Operation......................................................................16

User Setup................................................................................17

Backlight Operation..........................................................18

Service Filter......................................................................19

Installer Setup.........................................................................21

Programming a Daily Schedule...........................................27

About Advanced Features & Operation..............................29

Advanced Setup Table...........................................................34

Follow Installation Instructions carefully. Disconnect

Power to the Heater/Air Conditioner before removing

the old thermostat and installing the new thermostat.

CAUTION

IMPORTANT

iii

Auto-Changeover: A mode in which the thermostat will turn on the

heating or cooling based on room temperature demand.

Cool Setpoint: The warmest temperature that the space should rise

to before cooling is turned on (without regard to deadband).

Deadband: The number of degrees the thermostat will wait, once a

setpoint has been reached, before energizing heating or cooling.

Differential: The forced temperature difference between the heat

setpoint and the cool setpoint.

Heat Setpoint:The coolest temperature that the space should drop

to before heating is turned on (without regard to deadband).

Icon: The word or symbol that appears on the thermostat display.

Mode: The current operating condition of the thermostat (i.e. Off,

Heat, Cool, Auto, Program On).

Non-Programmable Thermostat: A thermostat that does not have the

capability of runningTime Period Programming.

Programmable Thermostat: A thermostat that has the capability of

runningTime Period Programming.

Temperature Swing: Same as Deadband.

Time Period Programming: A program that allows the thermostat

to automatically adjust the heat setpoint and/or the cool setpoint

based on the time of the day.

Glossary of Terms

Installation Instructions

Remove and Replace the old thermostat

To install the thermostat properly, please follow these step by step

instructions. If you are unsure about any of these steps, call a qualiﬁed

technician for assistance.

• Installationtools:Smallatbladescrewdriver,Phillipsscrewdriver,

wire cutters and wire strippers.

• MakesureyourHeater/AirConditionerisworkingproperlybefore

beginninginstallationofthethermostat.

• Carefullyunpackthethermostat.Savethescrews,anybrackets,

and instructions.

• TurnoffthepowertotheHeating/AirConditioningsystematthemain

fusepanel.Mostresidentialsystemshaveaseparatebreakeror

switchfordisconnectingpowertothefurnace.

• Removethecoveroftheoldthermostat.Ifitdoesnotcomeoffeasily,

checkforscrews.

• Loosenthescrewsholdingthethermostatbaseorsubbasetothewall

and lift away.

• Ifyouhaveasmartphonehandy,takeaphotoofthewiringforfuture

reference.

• Disconnectthewiresfromtheoldthermostat.Tapetheendsofthe

wiresasyoudisconnectthem,andmarkthemwiththeletterofthe

terminal for easy reconnection to the new thermostat.

• Keeptheoldthermostatforreferencepurposes,untilyournew

thermostatisfunctioningproperly.

Installation Instructions

Wire Connections

Iftheterminaldesignationsonyouroldthermostatdonotmatchthose

on the new thermostat, refer to the chart below or the wiring diagrams

that follow.

Wire from the Install on the

old thermostat Function new thermostat

terminal marked connector marked

G or F Fan G

Y1,Y Cooling Y1

W1, W Heating W1/O/B

Rh, R, M, Vr, A Power R

C Common C

O/B Rev. Valve W1/O/B*

W2 2nd Stage Heat W2

Ck1 Dry Contact Switch CK

CKGND Dry Contact Switch R

* O/B is used if your system is a Heat Pump.

SCALE 1 : 1

Installation Instructions

The Explorer Mini Thermostat Backplate

R 24 VAC return

GFan relay

W1/O/B 1st stage heat circuit

W2 2nd stage heat circuit

Y1 1st stage compressor relay

Y2 2nd stage compressor relay

C24 VAC common

CK1 Dry Contact

IMPORTANT: This thermostat requires both R (24 VAC Return) and C (24 VAC

Common) wires be connected to the backplate terminals to operate properly.

To remove the thermostat backplate:

Gently separate the display from the

basebypullingfromthecenter.

W1/O/B

CK1

Installation Instructions

Check Dip Switch

Ensure which switch is correct for your

system.Dipswitchesarelocatedonthe

backofthethermostat.

GAS/EL HP

123

OBBO

12 3

GAS ELEC

12 3

GAS

GAS/EL

ELEC

GAS

GAS/EL

ELEC

Thisswitch(GASorELEC)controlshowthe

thermostatwillcontroltheFan(G)terminalin

heatingmode.WhenGAS is chosen, the thermostat

willnotenergizetheFan(G)terminalinheating.

WhenELECischosenthethermostatwillenergize

thefaninheating.

For Heat Pump Only

WhentheGAS/EL or HPdipswitchisconguredfor

HP,thisdipswitch(OorB)mustbesettocontrol

theappropriatereversingvalve.IfOis chosen, the

W1/O/Bterminalwillenergizeincooling.IfBis

chosen, the W1/O/Bterminalwillenergizeinheating.

Thisdipswitchconguresthethermostattocontrol

aconventionalgas/electricsystemoraheatpump.

Ifyoursystemisanythingotherthanaheatpump,

leavethisswitchsetforGAS/EL.

SCALE 1 : 1

Installation Instructions

1 Stage Heat, 1 stage Cool

GAS

GAS/EL

ELEC

GAS

GAS/EL

ELEC

Dip Switch Settings

W1/O/B

CK1

O or B

Thermostat

HVAC

Equipment

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Termostato de Venstar

Venstar

Venstar T4950SCH-IAQ Instrucciones de funcionamiento

Venstar

Venstar T1050 Manual de usuario

Venstar

Venstar T2700 Manual de usuario

Venstar

Venstar T2300FS Manual de usuario

Venstar

Venstar T2700 Manual de usuario

Venstar

Venstar T0051FS Manual de usuario

Venstar

Venstar ColorTouch T6800 Instrucciones de funcionamiento

Venstar

Venstar T1800 Manual de usuario

Venstar

Venstar T2900 Manual de usuario

Venstar

Venstar T4975-IAQ Instrucciones de funcionamiento

Venstar

Venstar ACC0433 Manual de usuario

Venstar

Venstar EXPLORER Mini T2100 Instrucciones originales

Venstar

Venstar ColorTouch T5800 Manual de uso y cuidado

Venstar

Venstar EXPLORER Mini T2100 Manual de usuario

Venstar

Venstar T1100RF Manual de usuario

Venstar

Venstar TSTATEZ Manual de usuario

Venstar

Venstar T3900 Guía de inicio rápido

Venstar

Venstar ColorTouch T6800 Instrucciones de funcionamiento

Venstar

Venstar ColorTouch Manual de usuario

Venstar

Venstar T1119RF Manual de usuario

Venstar

Venstar T1000FS Manual de usuario

Venstar

Venstar T1700 Manual de usuario

Venstar

Venstar INSTEON 2491T1E Manual de usuario

Venstar

Venstar T1 900 Manual de usuario

Manuales populares de Termostato de otras marcas

EWELLY

EWELLY EW-181 Manual de usuario

Prolon

Prolon T1100 Instrucciones de instalación

Computherm

Computherm Q20 Manual de usuario

Heatmiser

Heatmiser neoStat Manual de usuario

Aube Technologies

Aube Technologies TH111GFCI-NP 240 VCA Manual de usuario

Mars

Mars HEAT CONTROLLER IR Wireless Thermostat Manual de usuario

Saswell

Saswell SAS920XWHB-7-S-RF Guía

Aircalo

Aircalo TFP1-ET85P2 Manual de usuario

Honeywell

Honeywell CM721 Manual de usuario

Carrier

Carrier DEBONAIR 33CS Manual de usuario

Lennox

Lennox iHarmony Zone Thermostat Instrucciones de montaje

Gemtech

Gemtech GT7000 Manual de instrucciones

Rollei

Rollei Smartes 45000 Manual de usuario

Sinope

Sinope TH1300RF Manual de usuario

Honeywell

Honeywell RLV4305 Manual de usuario

Honeywell

Honeywell Prestige 2.0 THX9421 Manual de usuario

NuTone

NuTone NTBZ48 Instrucciones de funcionamiento originales

Stelpro

Stelpro MAESTRO ASMT402AD Manual de usuario
