Velleman DTP6 Manual de usuario
DTP6
V. 00 – 22/03/2012 2 ©Velleman nv
User manual
1. Introduction
To all residents of the European Union
Important environmental information about this product
This symbol on the device or the package indicates that
disposal of the device after its lifecycle could harm the
environment. Do not dispose of the unit (or batteries) as
unsorted municipal waste; it should be taken to a
specialized company for recycling. This device should be
returned to your distributor or to a local recycling service. Respect
the local environmental rules.
If in doubt, contact your local waste disposal authorities.
Thank you for choosing Velleman! Please read the manual thoroughly
before bringing this device into service. If the device was damaged in
transit, don't install or use it and contact your dealer.
2. Safety Instructions
•Keep the device away from children and unauthorised users.
•The probe is sharp. Cover it after every use.
•Batteries (charged and used) may explode or leak if recharged or
disposed of in fire.
•All modifications of the device are forbidden for safety reasons.
1
4
2
3
DTP6
V. 00 – 22/03/2012 3 ©Velleman nv
•Only use the device for its intended purpose. All other uses may
lead to injuries. Using the device in an unauthorised way will void
the warranty.
•Always take your local legislation and guidelines into account
when disposing of used batteries.
3. Features
•For checking the core temperature
•Stainless steel probe
•With on/off and hold button
•Protective plastic sleeve with stainless steel clip
4. Overview
Refer to the illustrations on page 2of this manual.
1 ON-OFF button 3 Battery cover
2 HOLD button 4 Celsius & Fahrenheit button
5. Installation
The package comes with one LR44 (1.5V) battery.
Always use this type of battery. To insert it:
•Unscrew the battery lid [3].
•Insert the battery properly.
•Close the battery lid.
6. Operation
To measure an object’s temperature
1. Hold the probe against the object of which you want to measure
the temperature.
2. Push the ON-OFF button [1].
The object’s temperature will appear on the display.
3. Push the ON-OFF button again to turn off the device.
Other functions
DTP6
V. 00 – 22/03/2012 4 ©Velleman nv
Hold
Press the HOLD button [4] to hold the
temperature value when measuring. Press
again to start new measuring.
Celsius & Fahrenheit Press the button
℃
/
℉
[3] to switch
between Celsius & Fahrenheit.
7. Cleaning and maintenance
•You can clean the stainless steel probe after use with a damp
cloth and a little soap.
•Keep the plastic part of the device out of the water. Immersing
the device in water will cause malfunction or permanent failure.
8. Technical Specifications
measuring range -50°C~+300°C (58°F~572°F)
resolution ± 0.1° °C/°F
power supply 1 x LR44 (1.5V) battery (incl.)
LCD size 22 x 10mm
probe length 145mm
total length 235mm
Weight 22g
Spare battery (not included): V13GAC, see www.velleman.eu
Use this device with original accessories only. Velleman nv
cannot be held responsible in the event of damage or injury
resulted from (incorrect) use of this device.
For more info concerning this product and the latest version
of this manual, please visit our website www.velleman.eu.
The information in this manual is subject to change without
prior notice.
© COPYRIGHT NOTICE - The copyright to this manual is
owned by Velleman nv. All worldwide rights reserved.
No part of this manual or may be copied, reproduced, translated or
reduced to any electronic medium or otherwise without the prior
written consent of the copyright holder.
