USER MANUAL

1. Introduction

Important environmental information about this product

This symbol on the device or the package indicates that disposal of

the device after its lifecycle could harm the environment. Do not

dispose of the unit (or batteries) as unsorted municipal waste; it

should be taken to a specialized company for recycling. This device

should be returned to your distributor or to a local recycling

service. Respect the local environmental rules.

If in doubt, contact your local waste disposal authorities.

Thank you for choosing Velleman! Please read the manual thoroughly before

bringing this device into service. If the device was damaged in transit, don't

install or use it and contact your dealer.

Refer to the Velleman® Service and Quality Warranty on the last pages

of this manual.

2. Used Symbols

This symbol indicates: Read instructions.

Not reading the instructions and manual can lead to damage,

injury or death.

This symbol indicates: Danger.

A hazardous condition or action that may result in injury or death.

This symbol indicates: Risk of danger/damage.

Risk of a hazardous condition or action that may result in damage,

injury or death.

This symbol indicates: Attention; important information.

Ignoring this information can lead to hazardous situations.

AC (Alternating Current)

DC (Direct Current)

Both AC and DC

Double insulation (class II-protection)

Earth

Fuse

Resettable fuse

Diode

DVM630

V. 01 –22/04/2013 4 ©Velleman Inc.

Continuity

3. Safety Instructions

Read this manual thoroughly. Familiarize yourself with the functions

of the device before actually using it.

Only use the device for its intended purpose. Using the device in an

unauthorized way will void the warranty. Damage caused by

disregard of certain guidelines in this manual is not covered by the

warranty and the dealer will not accept responsibility for any ensuing

defects or problems.

WARNING: To avoid electrical shock always disconnect the test

leads prior to opening the housing. To prevent damage or injury,

only use batteries and fuses of the same type and ratings as

specified in this manual.

Remark: Refer to the warning on the back of the meter.

Keep the device away from children and unauthorized users.

Protect this device from shocks and abuse. Avoid brute force

when operating.

Avoid humidity, cold, heat, and large temperature fluctuations. When

the unit is moved from a cold to a warm location, leave it switched

off until it has reached room temperature. This to avoid condensation

and measuring errors. Ideal working environment is 73 °F ± 2 °F,

humidity 45-75 %.

This is an installation category CAT II 600V measuring

instrument. Never use this equipment in a higher category than

indicated. Refer to §4 Overvoltage/installation category.

Pollution degree 2 device. For indoor use only. Keep this device away

from rain, moisture, splashing and dripping liquids. Not for industrial

use. Refer to §5 Pollution degree.

For your safety, use only the test leads supplied with the

instrument. Before use, check that they are in good condition. Do not

use the meter or test leads if they look damaged. When damaged,

replace them with test leads of the same type and with the same

specifications.

Always place your fingers behind the protective edges of the test

probes while measuring!

Never touch free terminals when the meter is connected to a circuit.

DVM630

V. 01 –22/04/2013 5 ©Velleman Inc.

Use the correct input terminals, function, and range for your

measurements. When the range of the value to be measured is

unknown, check that the range initially set on the meter is the

highest possible.

To avoid damages to the instrument, do not exceed the maximum

limits of the input values as shown in the technical specifications

tables.

Risk of electric shock during operation. Be very careful when

measuring live circuits. Use extreme caution when measuring

voltages higher than 60 VDC or 30 VAC rms.

Never connect the test leads to a voltage source if the rotary switch

is in the current, resistance, diode, transistor, or continuity mode.

This may damage the meter.

Disconnect circuit power and discharge all high-voltage capacitors

before testing resistance, continuity, capacitance or diodes. For

transistor tests, use the included transistor socket.

In TV repair work or when carrying out measurements on power

switching circuits, remember that high-amplitude voltage pulses at

the test points can damage the meter. Use of a TV filter will

attenuate any such pulses.

Do not replace internal parts yourself. Replace damaged or lost

accessories by identical ones with the same specifications. Order

spare accessories, e.g. test leads, from your dealer.

Switch off the meter and remove test probes prior to replacing the

battery or fuses.

All modifications of the device are forbidden for safety reasons.

Damage caused by user modifications to the device is not covered by

the warranty.

If the meter is used near a source of electromagnetic interference, the

display may become unstable or may indicate large errors.

Use the meter only as specified in this manual; otherwise, the

protection provided by the meter may be impaired.

Use extreme caution when working around bare conductors or bus bars.

Do not operate the meter near explosive gases, vapor, or dust.

Verify the meter‟s operation by measuring a known voltage. Do not use

the meter if it operates abnormally. Protection may be impaired. When

in doubt, have the meter serviced by a qualified technician. Make sure

the device cannot be used until it is repaired.

When making connections, connect the common test lead (black) before

connecting the live test lead (red). When disconnecting, disconnect the

live test lead (red) before disconnecting the common test lead (black).

DVM630

V. 01 –22/04/2013 6 ©Velleman Inc.

Before changing functions or measuring range, disconnect the test leads

from the circuit under test.

For all DC functions, to avoid the risk of shock due to possible improper

readings, verify the presence of any AC voltages first by using the

AC function. Then select a DC voltage range equal to or greater than

the AC range.

Use 2 x 1.5 V AAA type batteries, properly installed in the meter‟s

battery case, to power the meter.

Replace the battery as soon as the battery indicator appears. With

a low battery, the meter may produce false readings that can lead to

electric shock and personal injury.

Do not operate the meter with the case (or part of the case) removed.

Always verify that all connections are reliable and safe.

Avoid body contact with ground potential (e.g. metallic terminals,

output sockets, lead clamp…) while measuring. Make sure to be

electrically insulated from ground during measurement.

4. Overvoltage/Installation Category

DMMs are categorized depending on the risk and severity of transient

overvoltage that might occur at the point of test. Transients are short-lived

bursts of energy induced in a system, e.g. caused by lightning strike on a

power line.

The existing categories according EN 61010-1 are:

CAT I

A CAT I-rated meter is suitable for measurements on protected

electronic circuits that are not directly connected to mains power,

e.g. electronics circuits, control signals…

CAT II

A CAT II-rated meter is suitable for measurements in CAT I

environments and mono-phase appliances that are connected to

the mains by means of a plug and circuits in a normal domestic

environment, provided that the circuit is at least 33 ft (10 m) apart

from a CAT III, or 66 ft (20 m) apart from a CAT IV environment.

E.g. household appliances, portable tools…

CAT III

A CAT III-rated meter is suitable for measurements in CAT I and

CAT II environments, as well as for measurements on (fixed)

mono- or poly-phased appliances which are at least 33 ft (10 m)

apart from a CAT IV environment, and for measurements in or on

distribution level equipment (fuse boxes, lighting circuits, electric

ovens).

CAT IV

A CAT IV-rated meter is suitable for measuring in CAT I, CAT II

and CAT III environments as well as on the primary supply level.

Note that for all measurements on equipment for which the supply

cables run outdoors (either overhead or underground) a CAT IV

meter must be used.

DVM630

V. 01 –22/04/2013 7 ©Velleman Inc.

Warning: This device was designed in accordance with EN 61010-1

installation category CAT II 600V. This implies that certain restrictions in use

apply that are related to voltages and voltage peaks which can occur within

the environment of use. Refer to the table above.

This device is suitable for measurements up to 600 V on:

protected electronic circuits that are not directly connected to mains

power, e.g. electronics circuits, control signals, circuits behind isolating

transformer…

circuits that are directly connected to mains power, but limited to:

omeasurements on mono-phase appliances that are connected to the

mains by means of a plug

omono-phase appliances and circuits directly connected to the mains

in a normal domestic environment, provided that the circuit is at

least 33 ft apart from a CAT III, or 66 ft (20 m) apart from a CAT IV

environment. E.g. household appliances, portable tools, light circuits

at more than 33 ft (10 m) from a distribution board…

This device is NOT suitable for:

voltages above 600 V

measurements in/on low-voltage distribution boards (distribution boards

behind meter box)

measurements on (fixed) mono- or poly-phased appliances and circuits

in CAT III/CAT IV environments (e.g. mains outlets, electric ovens,

lighting circuits, bus bars, low-voltage distribution boards and circuit

breakers).

measurements on distribution equipment and outdoor installations

including meter boxes and equipment/circuits outside or remote from

the domestic environment e.g. circuits in sheds, garden houses and

free-standing garages, or circuits using underground wiring e.g. garden

lighting, pool-pump…

This device is only suitable for measurements up to 600 V in CAT II

environments.

5. Pollution Degree

IEC 61010-1 specifies different types of pollution environments, for which

different protective measures are necessary to ensure safety. Harsher

environments require more protection, and the protection against the

pollution which is to be found in a certain environment depends mainly on

the insulation and the enclosure properties. The pollution degree rating of

the DMM indicates in which environment the device may be used.

Pollution

degree 1

No pollution or only dry, nonconductive pollution occurs. The

pollution has no influence (only to be found in hermetically

sealed enclosures).

DVM630

V. 01 –22/04/2013 8 ©Velleman Inc.

Pollution

degree 2

Only nonconductive pollution occurs. Occasionally, temporary

conductivity caused by condensation is to be expected (home

and office environments fall under this category).

Pollution

degree 3

Conductive pollution occurs, or dry nonconductive pollution

occurs that becomes conductive due to condensation that is to be

expected (industrial environments and environments exposed to

outside air - but not in contact with precipitation).

Pollution

degree 4

The pollution generates persistent conductivity caused by

conductive dust or by rain or snow (exposed outdoor

environments and environments where high humidity levels or

high concentrations of fine particles occur).

Warning: This device was designed in accordance with EN 61010-1

pollution degree 2. This implies that certain restrictions in use apply that

are related to pollution which can occur within the environment of use. Refer

to the table above.

This device is only suitable for measurements in Pollution

degree class 2 environments.

6. Overview

Refer to the illustrations on page 2 of this manual.

LCD display, 3 full digits and 1 half (max. range 1999)

HOLD: to lock the current reading

BACKLIGHT: press to switch on the display backlight. The backlight

switches off automatically after 3 seconds.

Rotary switch: to select type of measurement and range

VΩmAhFE: input terminal for all measurements except current

measurements > 200 mA

10A: input terminal for currents > 200 mA

COM: common input terminal

For cable testing:

USB jack

8P8C (RJ45)/RJ12/RJ11 jack

cable test lights

Remote cable test unit:

USB jack

8P8C (RJ45)/RJ12/RJ11 jack

cable test lights

DVM630

V. 01 –22/04/2013 9 ©Velleman Inc.

Display:

Indicates negative reading.

The meter is in data hold mode.

The battery is low.

Warning: To avoid false readings, which can possibly

lead to electric shocks or personal injury, replace the

battery as soon as the battery indicator appears.

Over range.

7. Use

7.1 Input Protection

Never exceed the limit value for protection.

Function

Red lead connection

Input protection

200 mV

VΩmAhFE

220 VAC

V & V

VΩmAhFE

600 VDC or VAC

VΩmAhFE

fuse 200mA/600V (resettable)

10A

fuse 10A/600V (fast)

measurement during max. 10 s

VΩmAhFE

220 V rms (15 s)

VΩmAhFE

250 VDC or 250 VAC rms

VΩmAhFE

250 VDC or 250 VAC rms

7.2 Switching On and Off

To switch the meter on, set the rotary switch [4] in the desired

measurement range position.

To switch the meter off, set the rotary switch to the OFF position.

Note: This device does not switch off automatically. To preserve the

battery, always set the rotary switch in the OFF position when the device is

not in use.

7.3 Data Hold Mode

The data hold mode locks the current readout on the display. Press the

HOLD key [2] to enter data hold mode. The display shows “H”. Press the

HOLD key again to return to normal measuring mode.

DVM630

V. 01 –22/04/2013 10 ©Velleman Inc.

7.4 Measuring AC/DC Voltage

To avoid electrical shock and/or damage to the instrument, do not

attempt to measure voltages exceeding 600 VDC or 600 VAC rms.

To avoid electrical shock and/or damage to the instrument, do not

apply more than 600 VDC or 600 VAC rms between the COM

terminal and the earth ground.

DC voltage measuring range: 200.0 mV, 2.000 V, 20.00 V, 200.0 V, 600 V.

AC voltage measuring range: 200.0 V, 600 V.

To measure AC or DC voltages:

1. Select the appropriate V (DC voltage) or V (AC voltage) range with

the rotary switch.

2. Connect the black test lead to the “COM” socket and the red test lead to

the “VΩmAhFE” socket.

3. Connect the test probes in parallel to the circuit under test.

The measured value appears on the display. For DC measurements: if a

negative polarity is present at the red test probe, the indicated value is

preceded by a “–” sign.

Notes:

If the measured voltage exceeds the selected range, the display

shows “1”. Select a higher range.

The displayed value may be unstable in the lower ranges, even without

input or without connecting the test probes. In this case, hold the tips

of the test probes together and make sure the meter displays zero;

then measure again.

7.5 Measuring DC Current

To avoid electrical shock and/or damage to the instrument,

disconnect the circuit power and discharge all high-voltage

capacitors before measuring current.

To avoid damage to the meter, check the meter‟s fuse before

proceeding. Use the proper terminals, function and range for your

measurement. Never place the test probes in parallel with a circuit or

component when the leads are plugged into the current terminals.

In the 10 A range, measure current for maximum 10 seconds, then

wait for 15 minutes before the next measurement.

The meter‟s ranges are: 2.000 mA, 20.00 mA, 200.0 mA, 10.00 A.

To measure current:

1. Cut off the power supply of the circuit to measure.

2. Discharge all the high-voltage capacitors.

3. Select the appropriate A (DC) range with the rotary switch.

4. Connect the black test lead to the “COM” socket and the red test lead to

the “VΩmAhFE” socket for measurements of max. 200 mA. For a

maximum of 10 A, move the red test lead to the “10A” socket. If the

Tabla de contenidos

Idiomas:

Otros manuales de Multímetro de Velleman

Velleman

Velleman DVM811 Manual de usuario

Velleman

Velleman DVM205AM Manual de usuario

Velleman

Velleman DVM6243 Manual de usuario

Velleman

Velleman DVM894 Manual de usuario

Velleman

Velleman DVM840 Manual de usuario

Velleman

Velleman DVM345DI Manual de usuario

Velleman

Velleman DVM830 Manual de usuario

Velleman

Velleman AVM460 Manual de usuario

Velleman

Velleman DVM 890L Manual de usuario

Velleman

Velleman DVM892N Manual de usuario

Velleman

Velleman DVM1400 Manual de usuario

Velleman

Velleman DVM94 Manual de usuario

Velleman

Velleman DVM810 Manual de usuario

Velleman

Velleman DVM855 Manual de usuario

Velleman

Velleman DVM835 Manual de usuario

Velleman

Velleman DVM1000 Manual de usuario

Velleman

Velleman DVM898 Manual de usuario

Velleman

Velleman DVM401 Manual de usuario

Velleman

Velleman DVM4200 Manual de usuario

Velleman

Velleman DVM66 Manual de usuario

Velleman

Velleman DVM92 Manual de usuario

Velleman

Velleman INHA511 Manual de usuario

Velleman

Velleman DVM040 Manual de usuario

Velleman

Velleman DVM1500 Manual de usuario

Manuales populares de Multímetro de otras marcas

Agilent Technologies

Agilent Technologies 34420A Manual de usuario

Fluke

Fluke 83 Manual de usuario

Hameg

Hameg HM 8012 Manual de usuario

Mastech

Mastech MY70 Manual de usuario

Steren

Steren MUL-300 Manual de usuario

Somogyi Elektronic

Somogyi Elektronic home SMA 92 Manual de usuario

Gossen MetraWatt

Gossen MetraWatt METRAmax 6 Manual de usuario

PeakTech

PeakTech 4000 Manual de uso y cuidado

YOKOGAWA

YOKOGAWA 90050B Manual de usuario

Gossen MetraWatt

Gossen MetraWatt METRALINE DMM16 Manual de usuario

Fluke

Fluke 8846A Manual de operación y mantenimiento

Tempo Communications

Tempo Communications MM200 Manual de usuario

Elenco Electronics

Elenco Electronics CM-1555 Manual de usuario

Mastech

Mastech MS8238C Manual de usuario

SDAR

SDAR 830A, 830B, 830D, 830C Manual de usuario

RS PRO

RS PRO RS-9519BT Manual de usuario

BGS technic

BGS technic 8890 Manual de usuario

Amprobe

Amprobe Hexagon 60 Manual de usuario
