Velleman-Kit K8057 Manual de usuario
1
2 Channel RF receiver
K8057
2 Channel RF receiver 3
Tweekanaals RF ontvanger 9
Récepteur RF à 2 canaux 15
2-Kanal-RF-Empfänger 21
receptor RF de 2 canales 27
2
3
Thank you for purchasingthis 2 channel RF receiver. Please read the instructions carefully to ensure correct and safe use.
WARRANTY
This product is guaranteed against defects in components and construction from the moment it is purchased and for a period of ONE YEAR starting from the
date of sale. This guarantee is only valid if the unit is submitted together with the original purchase invoice. VELLEMAN Ltd limits its responsibility to the
reparation of defects or, as VELLEMAN Ltd deems necessary, to the replacement or reparation of defective components. Costs and risks connected to the
transport, removal or placement of the product, or any other costs directly or indirectly connected to the repair, will not be reimbursed by VELLEMAN Ltd.
VELLEMAN Ltd will not be held responsible for any damages caused by the malfunctioning of a unit.
CONTENTS :
FEATURES & SPECIFICATIONS.........................................................................................................................................................4
CONNECTION.......................................................................................................................................................................................5
RECEIVER INSTRUCTIONS................................................................................................................................................................6
Contents
WARNING
DISCONNECT AC OR DC POWER DURING INSTALLATION!
READ THE OPERATING INSTRUCTIONS IN THIS USER GUIDE CAREFULLY!
!
4
Specifications & features
Specifications and features
FEATURES
Two relay contact outputs.
Transmitter optional : Ordernr. VM108 or K8059.
Toggle or pulse function selectable per output.
Pulse function can have turn off timer.
Learning unique 32-bit random code.
Up to 31 different transmitters can be stored.
Code memory can be erased for safety purposes.
LED indicators for outputs and functions.
Special function in pulse mode: If both transmitter buttons are pressed, both outputs are be set simultaneously.
For various control applications, garage door, house door, light, car...
SPECIFICATIONS
Receiver:
Power supply : 9 to 12V AC or DC / 100mA max.
Relay contacts NO / NC: 3A each.
Selectable timers per output: 0.5s, 5s, 30s, 1min, 5min, 15min, 30min and 60min.
Open field range of up to 30m possible.
On board antenna or external antenna.
Dimensions : 100 x 82mm.
5
Connection
Connection
CH2 status
CH1 status
Confirm/timer indicator
Mode/timer indicator
AC or DC power
‘Setup’ button
See connection diagram page 34.
CH1/ CH2
NO NC
COM
Receiver module
6
Receiver instructions
Receiver instructions
At power up, LD4 turns on, hereby indicating that the unit is operational. At this time, it will respond to the default code
emitted by the transmitter. If you have changed the code of your transmitter (recommended), then the receiver needs to
‘learn’ the new code.
To learn a remote :
1. Hold 'setup' button, LD3 turns on after a few seconds.
2. Hold any remote button.
3. LD4 lights when the code has been grabbed.
4. Release 'setup' button.
Repeat steps 1 through 4 so the receiver can learn the codes for other transmitters
31 transmitters can be stored.
If the memory is full, LD3 and LD4 will flash simultaneously when 'setup' button is pressed
To remove all remotes from memory :
1. Turn off the power (remove power cord).
2. Hold 'setup' button
3. Turn on power
DISCONNECT RELAY OUTPUTS DURING SETUP!
!
7
4. LD3 and LD4 start flashing.
5. Release 'setup' when leds turn off.
This process takes about 10 seconds.
If the button is released before the leds turn off, the memory will not be cleared.
To set 'pulse'/ 'toggle' / 'timer' for each relay :
1. Push 'setup'-button repeatedly to select relay1 (output 1) or relay2 (output 2).
2. Confirm with a long push (LD4 flashes 3 times).
The selected relay will remain ON.
3. Push 'setup'-button repeatedly to select between pulse (LD3 : one flash) and toggle (LD3 : two flashes)
4. Confirm with a long push (LD4 flashes 3 times)
If you have selected 'toggle', the relay will turn off and your unit is ready for use.
For ‘pulse’ selection the setup continuous with timer selection.
5. Press 'setup'-button repeatedly to select the appropriate timer.
LD3 will flash 1..8 times, indicating the selected timer :
6. Confirm with a long push (LD4 flashes 3 times)
The relay will turn off and your unit is ready for use.
Repeat the process for the other relay.
Important : If you have made a mistake, you can return to normal operation by not operating any buttons for 10s.
flashes delay
1
2
3
4
5
6
7
8
pulse mode, no timer
5s
30s
1 minute
5 minutes
15 minutes
30 minutes
1 hour
Instructions
8
Use :
The left remote button controls CH1 relay, the right remote button controls CH2 relay. Each relay is equipped with a status
LED.
In ‘pulse’-mode, a relay will remain on for as long as the remote button is held.
If a timer has been set for this particular channel, the relay will turn on when the button is pushed. When the preset time has
elapsed, the relay will turn off.
A timer can be turned off at any time by pressing the transmitter button again.
As long as the timer is running, the corresponding led will flash.
In ‘toggle’-mode, a relay will toggle between ON and OFF every time a button is pushed.
⇒ Extra feature : If both channels are configured as ‘pulse’, you can press both remote buttons simultaniously to operate
both channels at the same time.
Receiver instructions
9
Hartelijk dank voor de aanschaf van deze tweekanaals RF ontvanger.
WAARBORG
Dit produkt is gewaarborgd wat betreft gebreken in materialen en vakmanschap op het ogenblik van de aankoop en dit gedurende een periode van EEN JAAR vanaf de
aankoop. De waarborg geldt enkel indien het produkt voorgelegd wordt samen met het origineel aankoop bewijs. De verplichtingen van VELLEMAN N.V. beperken zich tot
het herstellen van defecten of, naar vrije keuze van VELLEMAN N.V., tot het vervangen of herstellen van defecte onderdelen. Kosten en risico’s van transport; het wegnemen
en terugplaatsen van het produkt, evenals om het even welke andere kosten die rechtstreeks of onrechtstreeks verband houden met de herstelling, worden niet door VELLE-
MAN N.V. vergoed. VELLEMAN N.V. is niet verantwoordelijk voor schade van gelijk welke aard, veroorzaakt door het falen van een product.
INHOUD :
EIGENSCHAPPEN & TECHNISCHE GEGEVENS...........................................................................................................................10
AANSLUITING.....................................................................................................................................................................................11
INSTRUCTIES VOOR DE ONTVANGER ..........................................................................................................................................12
Inhoud
WAARSCHUWING
TIJDENS DE INSTALLATIE MAG ER GEEN AC- OF DC-SPANNING
AANGESLOTEN ZIJN!
LEES AANDACHTIG DE BEDIENINGSINSTRUCTIES IN DEZE
HANDLEIDING!
!
LE
BEDIENI
N
10
Eigenschappen en technische gegevens
Eigenschappen & technische gegevens
EIGENSCHAPPEN
2 relaisuitgangen met omschakelcontact.
Zender optioneel : Ordernummer VM108 of K8059.
Wissel- of pulscontact instelbaar per uitgang.
Pulsfunctie met instelbare uitschakelvertraging.
Kan unieke 32-bit code leren.
Sla max. 31 zenders op.
Codegeheugen kan worden gewist om veiligheidsredenen.
LED indicators voor uitgangen en functies.
Speciale functie in pulsmode: u kunt beide uitgangen tegelijk schakelen wanneer u de twee zendknoppen samen indrukt.
Geschikt voor allerlei controletoepassingen: garagedeur, deur van uw huis, verlichting, wagen...
TECHNISCHE GEGEVENS
ontvanger:
voeding: 9 tot 12V AC of DC / 100mA max.
relaiscontacten NO / NC: elk 3A
selecteerbare timers per uitgang: 0.5s, 5s, 30s, 1min, 5min, 15min, 30min en 60min
bereik in open veld tot 30m
ingebouwde antenne of externe antenne
afmetingen: 100 x 82mm
