Vector TCY-MT Series Manual de referencia

11/19/2010 Intro TCY-MT, TCY-FT Slide 1

Product Introduction

LESS IS MORE!

Competitive PI controller series

TCY-MT, TCY-FT

11/19/2010 Intro TCY-MT, TCY-FT Slide 2

Product Pictures

TCY-MT-U, TCY-FT-U

TCY-MT, TCY-FT

Contents

SFeatures Overview

SApplications

SProduct Range (2-Pipe or 4-Pipe)

SPlug & Play (Auto Detection of Inputs)

SControl Modes

SOutput Options: VAV, Manual Override

SChange of Heat – Cool Mode for -2 Types

SAuxiliary Features on External Input

SUser Settings

SConnection Diagrams

11/19/2010 Intro TCY-MT, TCY-FT Slide 3

Applications

STemperature Control for

oRadiator, Floor heating, Cooling Ceilings

oStand alone VAV outlets for pressure

dependent control or in conjunction with

VAV actuators: pressure independent

control

oZone control for residential, offices, meeting

rooms, hotels or schools.

oFor 0-10V/2-10V or 24VAC 3-point

actuators

11/19/2010 Intro TCY-MT, TCY-FT Slide 4

11/19/2010 Intro TCY-MT, TCY-FT Slide 5

Main Features

SSpecific temperature control

Less programming, lower cost

SAuto detection for external

control sensor

SKey card or occupation sensor

input.

SSpecific solution for 2-pipe or

4-pipe applications

SVAV solution for –MT type

SPlug & Play for standard

applications. No need to setup

anything.

S-MT: 0-10V/2-10V outputs

-FT: 24VAC 3-point outputs

SLimitation of setpoints

11/19/2010 Intro TCY-MT, TCY-FT Slide 6

Product Range

SHousing types: Wall mounted.

oTCY-MT, TCY-FT : Flush mount ø60mm

oTCY-MT-U, TCY-FT-U : Flush mount 2” x 4”

SConfiguration:

Name System Output Input

TCY-MT2(-U) 2-pipe 1 0/2-10VDC 2 NTC / OC

TCY-MT4(-U) 4-pipe 2 0/2-10VDC 1 NTC / OC

TCY-FT2(-U) 2-pipe 2 24VAC TRIAC 2 NTC / OC

TCY-FT4(-U) 4-pipe 4 24VAC TRIAC 1 NTC / OC

NTC / OC = NTC temperature probe or open contact input

Plug & Play

SAuto detection of

inputs

SThe control signal

will be taken

automatically from

the external sensor if

a valid input signal is

detected

SNo need to program

11/19/2010 Intro TCY-MT, TCY-FT Slide 7

Control Modes

11/19/2010 Intro TCY-MT, TCY-FT Slide 8

SThe temperature controller operates a heating or

cooling device.

Select the control logic with one parameter:

SCP11 defines the control mode

S0 = Cooling mode: order preset with W01

S1 = Heating only mode: order preset with W02

S2 = 2-pipe mode: (Factory default for -2 products)

S3 = 4-pipe mode: (Factory default for -4 products)

This option is only available on -4 products.

VAV Function on TCY-MT

11/19/2010 Intro TCY-MT, TCY-FT Slide 9

Define individual min and max limits for

heating and cooling on the analog outputs

This is used to set min and max airflow on

linearized VAV actuators.

Manual Override

SActivate manual

positioning for

comissioning

SSet CP12 to ON to set

the outputs into

manual mode.

SOn -4 products: To

switch between heating

and cooling outputs,

change heat – cool

mode of controller

11/19/2010 Intro TCY-MT, TCY-FT Slide 10
