VBox TV Gateway XTi-3442 -
Installation Instructions
Thank you for buying the VBox TV Gateway
XTi-3442
the revolutionary TV router and PVR
Your VBox TV Gateway connects to an aerial antenna and streams the different Free-To-Air TV and
Radio channels available in your area to all your connected devices across your network
The VBox also records TV and Radio, programs and series, directly to an attached USB storage or
network folder and NAS (SMB/CIFS) for sharing between your devices
To receive software and news updates we recommend to follow us on Facebook, Twitter and
registering your product in the following link - Register
Installation Guide
Setting up
1. Make sure that UPnP is enabled on your
network router (In most routers this feature is
enabled by default)
2. Connect the VBox to your DVB-T/T2 Antenna
3. If you would like to record, connect a USB Hard
Drive or USB Flash Drive, you can setup recording
to a network storage at a later stage
4. Connect the network cable from the VBox to
your network router
5. Connect the VBox to the power adapter and
press the power button located at on the back
panel of the VBox
Software Installation
1. Make sure that the power LED is green
2. Download one of the VBox applications for
Tablet, iPad or Firefox
3. Make sure that your Tablet or PC is connected
to the same network as your VBox
4. You can quickly setup your VBox by using the
VBox apps for Tablet or with a PC
Quick Setup
The fastest and simplest way to setup your device
is by using the free VBox apps for Tablet and iPad
Setting up with your Tablet or Smartphone
(Android and iOS)
1. Run the VBox Live TV app
2. The application will search your network for the
VBox device
3. The app will open the Quick Setup Wizard
(jump to Step 1)
Setting up with a PC - Windows
1. From a computer connected to the same router
open Network folder
2. Find the VBox device and press the mouse's
right click button over it to open the WEB page
3. As your device was not configured, the Quick
Setup Wizard page will open (jump to Step 1)
Setting up with a Mac or any other device
1. Find the VBox's IP address, you can see the
VBox IP address from any VBox app or by
accessing your router
2. From any WEB browser type the VBox IP
address
3. As your device was not configured, the Quick
Setup Wizard page will open (jump to Step 1)
Step 1 - System Configuration
Interface Language - Set the VBox management
pages language
TV Source - Set your TV source DVB-T/T2 for
Antenna reception or DVB-C for Cable TV
reception
System Name - Name you TV Gateway
Country - Select your country to automatically set
the appropriate country's settings
Auto Tune - Press the Auto tune to automatically
scan for available channels in your area
Manual Tune - Manually select the frequencies to
scan
Step 2 - Scan (Automatic Tune)
The VBox TV Gateway will automatically scan
preselected frequencies available in your country
Scanning - The currently scanned frequency
Available (Green) - Successfully locked frequency
that is available in your area
Cannot Lock (Red) - Unable to lock to that
frequency, this frequency may not be available in
your area
In cases when the VBox is unable to lock to any or
all available frequencies in your area, try to adjust
or move your Antenna to a different location
Step 3 - Channel Setup
Select the TV and Radio channels you would like
to use, you can select individual channels, all Free
To Air TV channels, all Pay TV channels, all Radio
channels or all the available channels.
Please note that selecting more than 150
channels may slow down your player application
and program guide collection
Sort Channels - The channels are automatically
sorted according to your broadcaster’s (LCN)
automatic channel sorting number, where
available.
Broadcasters that do not provide LCN data the
channels will be sorted according to their
discovery.
Order - You can change the channel order by
pressing the up or down arrows or by pressing on
the cycle icon and selecting the channel location
from the drop down menu
LCN - Channel number is provided automatically
by the broadcaster (LCN) where available, When
LCN is not available the channel will receive
channel number higher than 1000, you can
change the channel number to a more friendly
number
Language - There is no need to change this
settings, However you can narrow down the
streamed data by selecting specific language and
audio tracks, or enable Advanced settings to
stream Single Program Transport Stream (SPTS)
Press Next to continue
Step 4 - Recording Setup
You can set recording now or later, recording is
available on a self powered USB removable Hard
Disk Drive or USB Flash Drive; or to a Network
shared Windows folder or NAS (SMB/CIFS)
USB - Plug your USB device to the VBox USB port
located on the rear panel and wait for few
seconds until the Current status refreshes and the
available storage is displayed, please make sure
that your device is formatted in the supported file
system and that it is self powered, or connect a
self powered USB hub to the VBox and connect
your device to the hub
Network Wizard - Browse to a Network storage
that is located on the same Domain or Workgroup
Network Manual - Write your network folder path
Press Finish to complete the VBox setup and go to
the Live TV screen
Live TV
Make sure to visit the Player and apps page for list
of supported applications and devices
You can watch live TV or record program using
any of the below options:
Apple iPad and iPhone - VBox free Live TV app,
Kodi, VLC or any UPnP Player
Android Tablet and phone - VBox free Live TV app,
Kodi, VLC or any UPnP Player
Android Set-Top-Box - VBox Live TV for STB or
Kodi
Samsung Smart TV (2013/4 models) - VBox Live TV
app
PC - WEB browser (with VLC webplugin) - Firefox,
Internet Explorer, Opera or Kodi
Mac - Safari (with VLC webplugin) or Kodi
Raspberry Pi 2 - OpenELEC (with Kodi 15)
and many more...
