C85-TO-Be/C85-TO-Pe

C85-TO series

Let’s get started

Let’s talk safety

This vacuum cleaner is intended for household use only and

NOT for commercial or industrial use.

• Only use the vacuum cleaner indoors on dry surfaces and

keep the area you’re cleaning well lit.

• Keep ngers, hair and loose clothing away from moving parts

and openings whilst using the vacuum cleaner.

• Don’t use this vacuum cleaner if it has been dropped, damaged

or left outdoors or the lters not in their original place.

• Don’t run over the power cord or use vacuum cleaner if the

power cord or plug is damaged. Please contact our Customer

Care Line on: 0330 026 8455 (Mon-Fri 8.30am-6-30pm Sat

9.00am-5.00pm).

• Don’t handle the plug or use the vacuum cleaner with wet hands.

• Don’t pull or carry this vacuum cleaner by the power cord.

• Don’t use the power cord as a handle, pull the power cord

around corners, sharp edges or close a door over the

power cord.

• Don’t unplug vacuum cleaner by pulling on the power cord.

• Don’t lift or carry the vacuum cleaner by the dirt

container handle.

• Turn o all controls on the vacuum cleaner before

disconnecting or connecting the power cord.

• Always make sure both the pre-motor/post-motor lters are in

place before use.

• Always switch o the vacuum cleaner before disconnecting or

connecting the hose and accessories.

• Keep all openings clear and free from debris as this may aect

the airow/suction.

• Always replace the fuse in the plug with a British 13amp fuse.

• Always protect the power cable from heated surfaces and

open ames.

Basic

safety

precautions

Don’ts

Do’s

• This vacuum cleaner can be used by children aged from 8 years and above

and persons with reduced physical, sensory or mental capabilities or lack of

experience and knowledge if they have been given supervision or instruction

concerning use of the vacuum cleaner in a safe way and understand the

hazards involved. Children shall not play with the vacuum cleaner. Cleaning

and user maintenance shall not be made by children without supervision.

• Only Vax recommend tools and accessories should be used with this

vacuum cleaner.

• Don’t vacuum up any ammable or combustible materials (lighter uid, petrol,

kerosene etc.) or use the vacuum cleaner in an area with explosive vapours

or liquid.

• Don’t vacuum up hot coals, cigarette butts, matches or smoking hot burning

items or use in an area where there may be harmful uids (chlorine, bleach,

and ammonia drain cleaner).

• Don’t attempt to remove blockages with sharp objects as this may cause

damage to your vacuum cleaner.

• Don’t vacuum up hard or sharp objects such as glass, nails, screws

or coins etc.

• Don’t use the vacuum cleaner with incorrect voltage as this may result

in damage or injury to the user. The correct voltage is listed on the

ratings label.

• Take extra care when positioning and using the vacuum cleaner on the stairs.

• Use only CE approved 13amp extension cords, non-approved extension cords

may overheat. Care should be taken to arrange the extension cord as it can be

a trip hazard.

• Store your vacuum cleaner in a cool, dry area. If lters have been cleaned as

per user guide instructions ensure they are thoroughly dry before

storing away.

Please keep instructions for further use.

Thank you for buying this C85-TO series.

Taking care of your carpets and hard oors

The C85-TO series is designed to make vacuuming carpets and hard oors regularly, as eective

and ecient as possible and this user guide will help you get the most out of your machine.

Maintaining your carpets and hard oors will ensure they keep their appearance for longer.

You’ve chosen carpets and hard oors for your home for a reason and Vax will help you take

good care of them.

Taking care of your C85-TO series

Also inside this guide are instructions on maintaining your new machine, so that it’s always ready

when you are to tackle your carpets and hard oors.

Let us know what you think @VaxUK

Taking care of you

We’re here if you need us. Instead of taking me back

to the shop, simply visit:

vax.co.uk/support or call:

(UK) 0330 026 8455 (ROI) 1-800 928 308

Monday-Friday 8.30am to 6.30pm, Saturday 9.00am to 5.00pm

Calls are charged at the UK local rate. Please make a note of the serial number and model number

of the product before calling.

Alternatively, you can write to us at:

Vax Ltd, Plot 302, Stonebridge Cross Business Park, Hampton Lovett, Droitwitch, WR9 OLW, UK

This User Guide can be found online at: vax.co.uk/support

Contents

Let’s talk safety

Getting to know your machine

Getting started

Using your machine

Taking care of your machine

Let’s talk technical

Accessories

What to do if it goes wrong

Getting in touch

C85-TO-Be

Included with

your machine

C85-TO-Pe

Initial Setup for normal operation

1. Use the base accessories.

a. Shortest hose

b. Extension tube set to shortest practicable length.

2. Clean lters installed.

3. Dust receptacle empty.

4. All Bleeds must be closed.

5. Floor heads/tools set to Carpet Mode for carpet cleaning.

6. Mechanical Agitation turned ON for carpet cleaning.

7. Floor heads/tools set to Hard Floor Mode for hard oor cleaning.

8. Mechanical Agitation turned OFF for hard oor cleaning.

Accessory hose and handle

2 pc extension tube

Combination oorhead

Crevice tool

Upholstery tool

Post-motor lter

Pre-motor lter

Frame Foam

TurboTool

Tool connector

Getting to know your machine

Name C85-TO-Be/C85-TO-Pe

Voltage 220-240~50Hz

Wattage 700watts

Cord Length 5m

Weight 4.9kg

Technical Specication

Subject to technical change without notice.

Filter Kit (Type 109)

1-1-134393-00

TurboTool (Type 6)

1-1-134419-00

Tool Connector (Type 1)

1-1-133838-00

Crevice Tool (Type 10)

1-9-128020-00

Combination Floor Tool (Type 6)

1-1-134330-00

Upholstery Tool (Type 4)

1-9-128019-00

Accessories & Consumables

*To purchase consumables and accessories, please visit vax.co.uk

On/O button

Post-motor

lter cover

Floorhead

parking slot

Cord rewind

button

Dirt container

release button

Dirt container handle

Shroud

Carry handle

Post-motor lter

release button

Hose entry point

Getting started

Assembling your upright

Press both buttons at end

of hose and insert into

hose entry point.

Insert hose grip into

extension tube.

Insert the other end of the

telescopic tube into the

oorhead.

Before you begin cleaning

IMPORTANT: The vacuum cleaner is equipped with a thermal cut-out. If for any reason the vacuum cleaner does

overheat the thermostat will automatically turn the vacuum cleaner o. If this happens, switch the vacuum cleaner

o and unplug. Remove and empty the dirt container also check the vacuum cleaner for blockages. Allow the vacuum

cleaner to cool for approximately 1 hour (if you have cleaned the lters please wait 24 hours for the lters to fully dry

before putting back into the machine).

For best cleaning results clean the pre-motor lter every time the dirt container is emptied and replace

the post-motor lter every 12 months.

If the vacuum cleaner is blocked, switch o and unplug before removing the blockage.

PLEASE READ ‘LET’S TALK SAFETY’ AT THE BEGINNING BEFORE USE

CAUTION

Always switch o the vacuum

cleaner before connecting

or disconnecting the hose

/attachments, or removing and

emptying the dirt container.

TIP

Brushes on the oorhead

should be visible when using

on hard oors.

Unwind the power cord.

Do not pull further than the

yellow marker.

Plug into mains and push

the On/O button to turn

your machine on.

IMPORTANT: The base of the vacuum cleaner should always be positioned at on the oor when starting and in use.

CAUTION: When unwinding the power cord do not pull further than the yellow marker.

Using your machine

For use on carpets, click

rocker switch forward. For

use on hard oors click rocker

switch back.

Slide vent cover on hose grip open

to reduce suction if required.

Lower brushes for hard oors.Raise brushes for carpets.

Using your machine

Emptying and cleaning the dirt container

Using your tools

Taking care of your machine

Always use the carry handle to lift and

carry the machine. Do not use the dirt

container handle.

Choose an accessory and

push onto the telescopic

extension tube or hose.

Press dirt container

release button and lift

to remove.

Press the button at the

top of the dirt container

to release lter.

Hold dirt container over

a bin allowing dirt/debris

to fall out.

Replace lid, making sure

central protruding (part A) is

over outer protruding piece

(part B) to complete the hinge.

Attach accessory to hose end. If required use tool connector.

Carrying your machine

IMPORTANT: Unplug and switch o vacuum cleaner before performing maintenance or troubleshooting checks.

Don’t over ll the dirt container

to avoid blocking the air ow

through the vacuum cleaner.

CAUTION

Cleaning the shroud

Taking care of your machine

Let’s talk technical

Rinse both dirt container and shroud under water

(Max 40°C). Leave to dry for 24 hours or until fully

dry before placing back in the machine.

IMPORTANT: The shroud cannot be removed from the dirt container.

Cleaning the pre-motor lter

Press dirt container release

button and lift to remove.

Leave to dry for 24

hours or until fully dry

before placing back in

the machine.

Line up the pre-motor lter frame with dirt container,

push into place.

If the pre-motor lter is not correctly tted the pre-

motor latch will prevent the dirt container from locking

into place.

Tap the lter frame and

foam over a bin to remove

any dirt/debris.

Remove the pre-motor

lter together with frame

and foam.

Rinse both the frame

and foam under water

(Max 40°C).

IMPORTANT: Do not wash the pre-motor lter in the washing machine or dishwasher.

For best cleaning results clean the pre-motor lter every time the dirt container is emptied.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Aspiradora de Vax

Vax

Vax VX13 Instrucciones de instalación

Vax

Vax Kruz K-020 Manual de usuario

Vax

Vax Blade 2 Manual de usuario

Vax

Vax Mach Compact VZL-7061 Manual de usuario

Vax

Vax WashVax V-020 PU Manual de usuario

Vax

Vax PowerCompact UCNBPCP1 Instrucciones de instalación

Vax

Vax W85-PL-T Dual Power Pro Advance Manual de usuario

Vax

Vax Agility Compact V-128 Manual de usuario

Vax

Vax CARVAX 6135 Hoja de información del producto

Vax

Vax Steam Fresh Combi Classic S86-SF-CC Instrucciones de instalación

Vax

Vax V-111 Manual de usuario

Vax

Vax Mach1 VZL-6011 Manual de usuario

Vax

Vax Impact 302 C86-ID-Pe Manual de usuario

Vax

Vax H89-12V Series Manual de usuario

Vax

Vax Essentials VEU-01 Manual de usuario

Vax

Vax W86-DD-B, Dual Power Max Instrucciones de instalación

Vax

Vax KONE K-001 Manual de usuario

Vax

Vax VS-19EC Manual de usuario

Vax

Vax AirTM Lift DRIVE Manual de usuario

Vax

Vax MACH 1 VZL-6011 Manual de usuario

Vax

Vax Powerplus pet 18 V Manual de usuario

Vax

Vax power7 Manual de usuario

Vax

Vax 613 0 Hoja de información del producto

Vax

Vax AirPetVCAP1500 Manual de usuario

Manuales populares de Aspiradora de otras marcas

Bissell

Bissell LittleGreen Proheat 1425 Series Manual de usuario

Panasonic

Panasonic MC-YL637S147-AE Manual de usuario

NEFF

NEFF N17XH10 0 Series Manual de usuario

LG A9 Series Manual de usuario

Oreck

Oreck Cordless Captura BK51700 Series Manual de usuario

Kogan

Kogan KAVACROBVWA Manual de usuario

Kränzle

Kränzle VENTOS 50 ID Guía del usuario

EVVO

EVVO Ai35 Manual de usuario

DeWalt

DeWalt DWH200D Manual de usuario

Pontec

Pontec Pondomatic Vacuum Cleaner Manual de usuario

Cleanmaxx

Cleanmaxx PC-P007E Manual de usuario

Exido

Exido 240-114 Manual de usuario

RIDGID

RIDGID WD1685AU0 Manual de usuario

Ezviz

Ezviz RE4P Manual de usuario

STG global

STG global TANVAC HDV3000 Manual de usuario

Shark

Shark ROTATOR PRO COMPLETE NV550 Series Manual de usuario

Factory

Factory M3340 Manual de usuario

Shop-Vac

Shop-Vac VN92 SERIES Manual de usuario
