AppBot
User Manual Guide
WI-FI CONNECTIVITY ROBOT THROUGH THE INTERNET
Android English
Copyright ⓒ2016 Varram System Co., Ltd. All rights reserved.
The model name of this product is a registered trademark of
Varram System Co Ltd.
Besides, any trademark described in this document is the company's own
registered trademark.
Copyright of this document belongs to Varram System Co Ltd.
No part of this document may be duplicated, distributed,
reproduced and changed at will without an official permission from Varram
System Co Ltd.
Varram System Co Ltd made a maximum effort to verify completeness and
accuracy of the information mentioned in this document, however, we don't
guarantee this. A user is entirely responsible for the result of the document
used. Contents of this document are subject to change without prior notice
from Varram System Co Ltd.
Trademark
Restriction
Disclaimer
A use guide and warranty
This instrument suitable for electromagnetic waves for home use (B class) aims to use primarily at
home and can be used at any area.
As corresponding wireless equipment has the possibility of radio waves jamming, human safety-
related services cannot be given.
A guide and warranty
Manufacturer does not assume the responsibility of loss or radio/TV interference caused by
remodeling of this product without permission.
Such remodeling without permission invalidates not only the right of using of a user
but also quality warranty on the product.
Warning
• This product should be installed by an adult without fail.
• Please read carefully every guide of this Instruction Manual prior to use and observe the
operating guide and warning described on this Instruction Manual and product.
• Particularly the power supply cord should carefully be installed to a place where children do not
reach.
• Do not use the product in much humid environment such as bathtub, sink, washing machine
and wet basement, etc.
• This product was designed for indoor use.
• To prevent the product from overheating, neither expose the product to direct sunlight nor install
it near a stove, radiator and cooking utensils like a microwave oven or oven and other radiating
appliances such as audio amplifier, TV, etc.
• Be careful upon installation lest a building pillar or furniture intercept ventilation of the product.
• Use the power supply adaptor provided. Using an uncertified adaptor would damage the
product. A rated power supply for home use should be connected, used for the power supply
adaptor.
• Do not put a sharp and pointed object around the adaptor cable. The cable can be damaged.
• In case of inserting the adaptor in a wall outlet or pulling out, never hold the cableexposed part.
• Do not use an extension cable for the adaptor power supply cord. The cable can be entangled.
• Using other adaptor or power supply cable than provided cannot guarantee
performance of the product.
• This product needs a wireless router and the wireless router should have the internet connected.
AppBot
!
Before using appbot Riley
4
16
32
7
4
5
6
7
7
8
9
9
10
11
14
32
32
33
Get started
Appendix
Installation and network connection
Product features
Product and accessories
Each part name and function
Product specification
Specification
Product's external appearance
Installation
Caution
Installation of smartphone application
Execution
Caution
Product registration
Connecting
Reconnect
16
17
18
19
20
21
22
23
24
25
Application function explanation
Function confirmation
Streaming Quality Settings
Software and hardware Information
Face Tracking
Password Settings
Motion Detection
List of recorded videos
Options ON/OFF
Night Vision
Joystick Activation
• In case of protecting, observing children with this product, be careful
the product keeps away from the children hands.
• This product partially includes a component which has the possibility of
inducing difculty in breathing.
• Keep the product’s peripheral device and small-sized components out
of reach of children.
• This product cannot substitute human supervision duty on children.
• This product does not accompany function to notify the adult of the
children’s accidental and sudden movement and needs a regular check
and supervision control by a staff-member.
• This product should be used with an antenna or operated with other
antenna or a transmitter. To meet RF exposure specication, at least
20cm of distance between the antenna and user on this product should
be maintained.
AppBot
Contents
26
27
28
29
30
31
Stand Upright
2-way Audio Communication
Auto Docking and Charging
Battery Status
Screen Capture
Video Recording
Product features
Product and accessories
Each part name and
function
Product features
(1) Remote real time viewer
- It can be monitored through a smartphone anytime any where.
(All of WIFI, 3G/4G are possible)
(2) Convenient network setting
- Search a wireless router around after connecting the product
with smartphone and enter password then network setting is
done. any extra installation program and setting is not
necessary.
(3) Still shot saving
- An image transmitted can be saved as a photo.
(4) Video saving
- An image transmitted can be saved as a video.
(5) Full-duplex audio
- Full-duplex voice communication can be done with a
built-in speaker and microphone.
(6) Real time alarm
- Alarming to user when detecting motion
(7) One-touch standing up function
- When fallen, it can stand up only by touching the icon.
(8) Image recognition function
- It has function to recognize a face to be tracked.
(9) Night Vision
- Through using IR RED, it is visible in dark place.
(10) Automatic charging
- Appbot Riley automatically move to
charging station to charge (But, Robot should face to charging station)
4
AppBot
Getstarted
CHAPTER
01
appbotRILEY RechargerStation
PowerAdapter 5pinpowercable QuickGuide
Product and accessories CHAPTER 01 Get started
When buying the product, confirm whether all the items are contained in the product package.
Product features
Product and accessories
Each part name and
function
5
AppBot
Each part name and function
Product features
Product and accessories
Each part name and
function
6
AppBot
HeadPart IRLED
Camera
Microphone
Speaker
ON/OFFSwitch
Rechargingstaiondockingpart
ResetButton
MobilePart
ChargingStatus(Purple) FullChargeStatus(SkyBlue)NormalActivateStatus(blinking)
PowerOFFStatus(Red)PowerONStatus(Green) LowbatteryStatus(blinking)
(LEFTLED)Statusbycolor (RIGHTLED)Statusbycolor
CHAPTER 01 Get started
Please check each part's name and function.
Installation
Caution
Installationofsmartphone
application
Execution
Caution
Productregistration
Connecting
Reconnect
Installation
Caution
• Install a camera to a place where Wi-Fi signal is received and is free from interference.
• Avoid a moist place like where a humidifier is close to.
• Install to a place where there is no direct sunlight, strong light or dust and sight is clear.
• Do not install to a place where there are many obstacles.
• Use a piece of soft cloth when clean dust.
7
AppBot
Installationandexecution
CHAPTER
02
!
Installation > Installation of smartphone application CHAPTER 02 Installation and execution
01 Search "appbot RILEY" at the Apple Store of Google.
02 Install appbot RILEY.
03 App like the picture above is installed.
*Thisapplicationisprovidedforfree.
8
AppBot
Installation
Caution
Installationofsmartphone
application
Execution
Caution
Productregistration
Connecting
Reconnect
04 In a place where you cannot download it at the corresponding store, refer to the homepage.
Execution > Caution
9
AppBot
Installation
Caution
Installationofsmartphone
application
Execution
Caution
Productregistration
Connecting
Reconnect
Caution
• Depends on the internet communication environment, it is possible to fail to connect with wireless network.
• To know more about setting of network and password, try to contact to service operator or network administrator.
• Please do not access the unauthenticated network.
• Far from the router makes longer time to connect the network.
• If failed to connect to chosen wireless network, try to access to another wireless network.
• To know more about router or wireless connection, try to read router direction or contact to manufacture of router.
• Not only the reason of problem with robot but also problem with network can make connection delay and stop.
• Some of routers can occur the compatibility problem.
!
CHAPTER 02 Installation and execution
CHAPTER 02 Installation and execution
Execution > Product registration
10
AppBot
Installation
Caution
Installationofsmartphone
application
Execution
Caution
Productregistration
Connecting
Reconnect
01 After pressing power button for 1 second, green LED will be show, means it is ON. Turning OFF method is also same.
(When you start Riley for the first time, make sure press and hold "Power + Reset" Buttons at the bottom of RILEY for second.
02 LED (see arrow) turn from blue-purple-off-green (the whole process complete in 20 second when you hear ' I'm ready ' )
1
1
I'm ready!
NormalActivateStatusLED
PowerON PowerOFF
LowbatteryStatusLED
