Vantrue Element 1 Manual de usuario

English/Espanol/日本語/中文 Element 1

User Manual

122mmX130mm

70g

Smart Cube

Voice-controlled Dashcam

Hey, find us here:

www.vantrue.net/contact facebook.com/vantrue.live

CONTENTS

ÍNDICE

Installation

Instalación

取り付け方法

安装及使用说明

125

119

156

Warranty & Support

Garantía y soporte

保証とアフターサービス

售后服务

118

155

Specifications

Especificaciones

仕様

产品规格参数

Camera Overview

Descripción de la cámara

ドラレコの概要

机身部件说明

122

135

Basic Operation

Operación básica

基本操作

功能亮点

121

What’s in the box?

¿Qué hay en la caja?

同梱内容

盒内物品清单

- 1 -

1.What'sinthebox?

J. CPL Filter

Optional Accessories

A.Vantrue E1

Dash Cam

D. Type C Data Cable

(3.3ft, for transferring

files only)

G. Warning Stickers

C. Car Charger with

Built-in Type C Cable

(11.5ft)

F. Electrostatic stickers

I. User Manual

B.GPS Adhesive

Mount

E. Wireless Remote

Control

H.Crowbar

- 2 -

2. Camera Overview

NO. DescriptionName

During video recording, long press to turn off the

screen, short press to stop video recording and

enter standby mode; you can confirm the

selected option in the menu; when playing back

files, you can play/pause files

1 Microphone

3Button

Serial Number Serial number for warranty registration.

Records clear audio with the video footage.

1 2

13 15

ENENENEN

- 3 -

4 During video recording and standby, long press

to quickly enter parking mode, and short press to

turn on/off the microphone; in menu settings,

long press to scroll through menu options, and

short press to display the next menu option;

during file browsing, long press to scroll to display

file, short press to display the next file; in playback

mode, short press to pop up the delete file menu

Button

5 Button

SD Card Slot

Speaker

During video recording and standby mode,

long press to turn on/off WiFi

Mount Port Connects to Type C cable or car charger for

external power supply

Supports Micro SD Card up to 512GB in FAT32,

Class 10

Button Power ON/OFF; long press to turn on/off the dash

cam; short press during recording to enter event

recording mode; short press to capture pictures

during event recording

Delivers sound during video playback.

Front Camera Front facing camera for video recording road

Events

For connecting mountsMount Interface

Power Port Connects to Type C cable or car charger for

external power supply；connects the data cable

for data transfer

Short press to restart the camera.Reset Button

Screen 1.54" LCD Screen

- 4 -

DescriptionLED Status

15 Camera is recordingBlinking green light

Steady green light Instandbystatus

ENEN

Screen Overview

2560x1440P 30FPS

MP/H

00:00:37

08-22-2022 14:09:07

120

Loop recording off

Loop recording for 1 min

Loop recording for 3 mins

Loop recording for 5 mins

G-Sensor OFF

G-Sensor ON

Remote control is connected

GPS Signal Connecting

GPS Signal Locked

Voice Assistant

Parking Mode

Recording Time

(Current Clip)

Recorded Driving Speed

(KMH or MPH)

Mic is ON

Mic is OFF

No memory card inserted

Memory card inserted

00:00:37

Current Date

and Time Time Lapse On

Collision Detection ON

Motion Detection ON

1080P Low Bitrate Recording ON 15FPS

720P Low Bitrate Recording ON 15FPS

Low Framerate Parking Mode

Video Resolution

Icons for Indicating Buttons

WiFi ON

WiFi Connected

WiFi OFF

- 5 -

Before using this card, please follow the steps below to format it properly:

If the camera is recording, please press the icon to pause the

recording, then press the icon to enter the menu, then enter “System”,

select the" Format SD Card " , and confirm to format the memory card

until it prompts "Formatted successfully."

3. Installation

3.1 Installing a Memory Card (Recommended: Vantrue U3 high-speed micro

SD card).

Please insert a memory card (memory card capacity: 32GB-512GB, card

speed: U3/Class10/A2). The dashcam has certain requirements on the

card speed of the memory card. For reliable operation, we recommend

using a VANTRUE SD card(sold separately).

Memory Card Installation: There is an icon indicating the insertion

direction of the memory card. Please push the memory card into the

card slot according to the direction indicated by this icon, until a "click"

sound is heard in the card slot, indicating that the memory card is

inserted properly.

- 6 -

We recommend formatting the card once a month to ensure normal

operation of the dash cam.

Do not remove or insert the memory card during recording to avoid

losing important videos.

Please do not use bad cards or low-speed cards on the dash cam, as

it is easy to stop or lose the recording due to a failure of the memory

card.

Before formatting the memory card, please check the emergency

video folder in the SD card to see if there are any videos that need to

be saved separately, so as not to delete important videos by mistake.

REMINDER:

After inserting the memory card, if the screen prompts "Card error, please

format" (please note that the recorder does not record at this time),

please directly press the button to enter the menu and start the

formatting process.

REMINDER:

ENEN
