Vantec FireWire 400 Manual de usuario

Upgrade to FireWire800 !

FireWire

3-Port FireWire 800/400 PCI Host Card

USER’S MANUAL

FireWire

Included

Low

400

FireWire

Included

Low

Package Contents :

13-Port FireWire 800/400 PCI Host Card

2Low Profile Bracket

3Driver CD

4User’s Manual

TRADEMARKS

MS-DOS,Microsoft, Windows NT/2000/ME/XP/Vista are trademarks of Microsoft Corporation.

Apple, Macintosh and Mac are trademarks of Apple Computer.

*All other third-party brands and names are the property of their respective owners.

Low Profile Bracket

User’s

Manual

USER’S MANUAL

400

FireWire

Included

Low

Driver CD

1. Introduction................................................................................................................02

2. Specifications / Features ................................................................................03

3. System Requirements / Parts Layout..................................................04

4. Installation

3-Port FireWire 800/400 PCI Host Card

4.1 Hardware Installation ..................................................................................................05

4.2 Driver Installation .........................................................................................................08

5. Warranty / Contact.................................................................................................10

Table of Contents :

Introduction

Take advantage of the high-speed FireWire 800

with Vantec’s 3-Port FireWire 800/400 PCI Host

Card. It allows you to easily add two FireWire 800

(IEEE1394b) as well asone FireWire 400 ( IEEE1394a )

ports to your PC or MAC® offering speeds up to

800 Mbps. Download, edit, and connect DV

ca m c ord e r , digital camera , hard drive and

daisy - chain up to 63 devices. Compatible with

Windows®98SE/ME/2000/XP/Vistaand MAC®OSX10.4

or higher, the Vantec 3-Port FireWire 800/400 PCI

Host Card is the choice for your FireWire needs.

1. Introduction :

FireWire 800/400

3-Port FireWire 800/400 PCI Host Card

Specifications/Features

2. Specifications / Features :

Features :

• Two FireWire 800(1394b) ports

• One FireWire 400(1394a) port

• PCI 2.2 compliant and works in 32/64-bit PCI slot

• Support data transfer rates of 100, 200, 400, and 800 Mbps

• Built-in 4-Pin power connector for reliable power output

• Low profile bracket included for low profile chassis

• Supports Hot-Swap and Plug & Play

• RoHS compliant

Specifications :

• Model: UGT-FW100

• Bus Type: 32-Bit 33 MHz PCI v2.2

• Port Type: 2 FireWire 800(1394b) Ports

1 FireWire 400(1394a) Port

• OS Support: Windows® 98SE/ME/2000/XP/Vista

MAC® OS V10.4 or higher

FireWire 800(1394b) Ports

FireWire 400(1394a) Port

IEEE

1394a

1394 b

System Requirements / Parts Layout

3. System Requirements / Parts Layout :

FireWire 800(1394b) Ports

FireWire 400(1394a) Port

Parts Layout:

PC Users Mac Users

Gold contact pins

• Mac G3 processor & greater

• Mac OS V10.4 or higher

• 128MB RAM or higher

• PCI slot that complies with PCI Specification

Rev.2.0 or above

• Intel Pentium III or higher compatible

processor

• Microsoft Windows 98SE / ME / 2000 / XP

/ VISTA

• 128MB RAM or higher

• PCI slot that complies with PCI Specification

Rev.2.0 or above

4.1. Hardware Installation :

PC Users

(1) Turn off your computer and disconnect all

external peripheral devices and cables, i.e.

power cord, network cable, monitor, etc.

(2) Remove your computer’s cover.For most

standard PC’s, there are screws that will

need to be unseated before you can

remove the computer’s cover, and these

screws are usually located at the rear of

the computer, along theedge of the cover.

However, placement of these screws and cover

attachment may vary by manufacturer, so

please refer to your computer system’s

manual for specific details.

(3) Once you have removed the cover, you will

need to locate the PCI slots on the motherboard.

The PCI slots are generally located in the back

of the computer, with the slots built into the

side-wall of the computer ( please refer to

your computer system’s manual for the

exact location of your PCI slots or refer to the

Installation

4. Installation :

diagram in this manual – the Vantec FireWire

800 PCI Card may be installed in either a 32 or

64-bit PC card slot). If necessary, you may

need toI remove the expansion slot cover,

Installation

4. Installation :

(4) Take the Vantec FireWire PCI Card out of its

anti-static bag and push the card into the empty

PCI card slot. The card should be mounted with

the circuitry facing down. This is the only

way to mount the card, so if you are having

problems inserting the card into the PCI slot,

make sure that it is oriented correctly. Be sure that

the gold contact pins of the PCI card are seated

completely inside your computer’s PCI slot.

Be aware that it may take some force to get

the card fully seated in the slot.

(5) Once the PCI card is seated correctly, tighten

with a screw, and, if necessary, replace any

peripherals that you removed in Step 3.

(6) Now you are ready to put the computer’s

cover back on and reconnectallof your

externalperipheral devices and cables.

(7) Power on your computer. After the start up

procedure has finished, you should be able

to connect devices through the available

FireWire ports.

and you may also need to remove any add-in

boards which may block the access to the

PCI slots.

Installation

4. Installation :

(1) Turn off your computer and disconnect all

external peripheral devices and cables, i.e. power

cord, network cable monitor, etc.

(2) Remove your computer’s cover by pulling the

latch on the side, and gently lower the side of the

computer onto a flat, non-abrasive surface.

(3) Once you have removed the cover, you will need

to locate the PCI slots on the motherboard. The

PCI slots are generally located in the back of the

computer, with the slots built into the side-wall

of the computer (please refer to your computer

system’s manual for the exact location of your

PCI slots). Ifnecessary, you may need to remove

the expansion slot cover, and you may also need

to remove any add-in boards which block access

to the PCI slots.

(4) Take the Vantec FireWire PCI Card out of its

anti-static bag and push the card into the empty

PCI card slot. The card should be mounted with

the circuitry and three FireWire connectors facing

down. This is the only way to mount the card, so

if you are havingproblems inserting the card into

the PCI slot, make sure that it is oriented correctly.

Be sure that thegold contact pinsof the PCI card

are seated completely inside your computer’s PCI

slot. Be aware that it may take some force to get

the card fully seated in the slot.

Mac Users

(5) Once the PCI card isseated correctly, tighten with a

screw, and, if necessary, replace any add-in boards

that you removed in Step 3.

(6) Now you are ready to put the computer’s cover back

on and reconnect all of your external peripheral

devices and cables.

(7) Power on your computer. After the start up procedure

has finished, you should be able to connect devices

through the available FireWire ports.

PCI Slots in Apple G3/G4

Installation

4. Installation :

4.2. Driver Installation :

Windows 2000/XP/Vista :

An automated driver installation process will

begin upon the detection of the new PCI card

and an embedded driver will be loaded. You

may be prompted to restart your computer.

Windows 98 :

(1) After the installation of PCI Card. Enter

Windows 98 and an “Add New Hardware

Wizard” dialog will appear. Click “NEXT”.

( Figure 4.2-A )

(2) Select "Search for the best driver for your

device." ( Figure 4.2-B )

(3) Check the box under the search. Press browse,

select the X:\UGT-FW100/Driver/win 98

of the CD-ROM and press “NEXT”. X is the

path for your CD-ROM drive. Please make

sure that your path is set correctly.

( Figure 4.2-C )

PC Users

( Figure 4.2-A )

( Figure 4.2-B )

( Figure 4.2-C )

X:\UGT-FW100/Driver/win 98
