Vacmaster VSD1801 Manual de usuario

www.vacmaster.com

Cleva North America, Inc.

Greenville, SC 29607

Made in China

Use & Care Guide

MODEL NO. VSD1801

18V 2-in-1 Cordless Stick Vacuum

(866) 384-8432

-2-

SECTION

Important Safety Instructions................................................................................................................3-5

Warranty…………....................................................................................................................................6

Technical Data

........................................................................................................................................6

Getting To Know Your Vacuum................................................................................................................7

General Assembly Instructions............................................................................................................8-11

Operating Instructions.......................................................................................................................11-13

Maintaining Your Vacuum................................................................................................................ 14-17

Troubleshooting................................................................................................................................18-19

TABLE OF CONTENTS

PAGE

Thank you for purchasing this Vacmaster® vacuum cleaner. With it you are

obtaining a high quality product that is engineered for optimal performance.

FOR YOUR SAFETY

Read and understand this manual before use.

Keep this manual and your sales check (receipt) in a safe place for future

reference.

-3-

IMPORTANT SAFETY INSTRUCTIONS

When using an electrical appliance, basic precautions should always be

followed, including the following:

READ ALL INSTRUCTIONS BEFORE USING THIS VACUUM CLEANER.

)DLOXUHWRIROORZWKHZDUQLQJVDQGLQVWUXFWLRQVPD\UHVXOWLQHOHFWULFVKRFN¿UH

and/or serious injury.

WARNING - To UHGXFHWKHULVNRI¿UHHOHFWULFVKRFNRULQMXU\

• Do not use outdoors or on wet surfaces.

• Do not allow to be used as a toy. Close attention is necessary when used by

or near children, pets or plants.

• Use only as described in this manual. Use only manufacturer’s recommended

attachments.

• Do not charge if charging adapter is damaged. If appliance is not working as

it should, has been dropped, damaged, left outdoors, or dropped into water,

return it to a service center.

• Do not pull or carry the charging adapter by cord, use cord as a handle,

close a door on cord, or pull cord around sharp edges or corners. Do not run

appliance over cord. Keep cord away from heated surfaces.

• Do not unplug by pulling on charging cord.

• Do not handle charger, including charger plug, and charger terminals with wet

hands.

• Do not put any object into openings. Do not use with any opening blocked;

NHHSIUHHRIGXVWOLQWKDLUDQGDQ\WKLQJWKDWPD\UHGXFHDLUÀRZ

 .HHSKDLUORRVHFORWKLQJ¿QJHUVDQGDOOSDUWVRIERG\DZD\IURPRSHQLQJV

and moving parts.

• Use extra care when cleaning on stairs.

 'RQRWXVHWRSLFNXSÀDPPDEOHRUFRPEXVWLEOHOLTXLGVVXFKDVJDVROLQHRU

use in areas where they may be present.

• Do not pick up anything that is burning or smoking, such as cigarettes,

matches, or hot ashes.

 'RQRWXVHZLWKRXWGXVWFXSRU¿OWHULQSODFH

• Prevent unintentional starting. Ensure the product does not operate before

connecting to hand vacuum, picking up or carrying the appliance. Carrying the

DSSOLDQFHZLWK\RXU¿QJHURQWKHVZLWFKLQYLWHVDFFLGHQWV

-4-

 5HFKDUJHRQO\ZLWKWKHFKDUJHUVSHFL¿HGE\WKHPDQXIDFWXUHU$FKDUJHUWKDW

LVVXLWDEOHIRURQHW\SHRIEDWWHU\SDFNPD\FUHDWHDULVNRI¿UHZKHQXVHGZLWK

another battery pack.

• Under abusive conditions, liquid may be ejected from the battery; avoid contact.

,IFRQWDFWDFFLGHQWDOO\RFFXUVÀXVKDIIHFWHGDUHDZLWKZDWHU,IOLTXLGFRQWDFWV

eyes, additionally seek medical help. Liquid ejected from the battery may cause

irritation or burns.

 'RQRWXVHDEDWWHU\SDFNRUDSSOLDQFHWKDWLVGDPDJHGRUPRGL¿HG'DPDJHG

RUPRGL¿HGEDWWHULHVPD\H[KLELWXQSUHGLFWDEOHEHKDYLRUUHVXOWLQJLQ¿UH

explosion or risk of injury.

 'RQRWH[SRVHDEDWWHU\SDFNRUDSSOLDQFHWR¿UHRUH[FHVVLYHWHPSHUDWXUH

([SRVXUHWR¿UHRUWHPSHUDWXUHDERYH&PD\FDXVHH[SORVLRQ

• Follow all charging instructions and do not charge the battery pack or appliance

RXWVLGHRIWKHWHPSHUDWXUHUDQJHVSHFL¿HGLQWKHLQVWUXFWLRQV&KDUJLQJ

LPSURSHUO\RUDWWHPSHUDWXUHVRXWVLGHRIWKHVSHFL¿HGUDQJHPD\GDPDJHWKH

EDWWHU\DQGLQFUHDVHWKHULVNRI¿UH

 +DYHVHUYLFLQJSHUIRUPHGE\DTXDOL¿HGUHSDLUSHUVRQXVLQJRQO\LGHQWLFDO

replacement parts. This will ensure that the safety of the product is maintained.

• Do not modify or attempt to repair the appliance or the battery pack except as

indicated in the instructions for use and care.

• Always turn off this appliance before connecting or disconnecting any

accessories.

• Do not charge the unit outdoors.

• Do not incinerate the appliance even if it is severely damaged. The batteries

FDQH[SORGHLQD¿UH

• For Household Use Only.

SAVE THESE INSTRUCTIONS

-5-

127( This equipment has been tested and found to comply with the limits

for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits

are designed to provide reasonable protection against harmful interference in

a residential installation. This equipment generates, uses and can radiate radio

frequency energy and, if not installed and used in accordance with the instructions,

may cause harmful interference to radio communications. However, there is

no guarantee that interference will not occur in a particular installation. If this

equipment does cause harmful interference to radio or television reception, which

can be determined by turning the equipment off and on, the user is encouraged to

try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

3URGXFW'LVSRVDO

This product contains an internal Lithium-ion battery pack formulated from

environmentally sensitive materials. This product must be disposed of properly

with due care for the environment. Do not dispose of product with household

garbage. Consult your local waste authority for information regarding available

recycling or disposal options.

WARNING

$Q\FKDQJHVRUPRGL¿FDWLRQVWRWKLVXQLWQRWH[SUHVVO\DSSURYHGE\WKHSDUW\

responsible for compliance could void the user’s authority to operate the

equipment.

-6-

FOR ONE YEAR from the date of sale, this product is warranted against defects

in material or workmanship when it is assembled, operated and maintained

according to all supplied instructions.

WITH PROOF OF SALE, a defective appliance will be replaced free of charge.

For warranty coverage details to obtain free replacement, visit the web page:

www.vacmaster.com or call (866) 384-8432.

 7KLVZDUUDQW\GRHVQRWFRYHU¿OWHUVZKLFKDUHH[SHQGDEOHSDUWVWKDW

can wear out from normal use within the warranty period.

• This warranty is void if this product is ever used for other than private

household purposes.

 7KLVZDUUDQW\JLYHV\RXVSHFL¿FOHJDOULJKWVDQG\RXPD\DOVRKDYHRWKHU

rights which vary from state to state.

TECHNICAL DATA

Cordless Vacuum Cleaner

Voltage: 18VDC

Battery Charger:

Model: YLS0241A-T210050

Input: 100-240V~50/60Hz 0.8A

Output: 21.0V 500mA

WARRANTY

-7-

GETTING TO KNOW YOUR VACUUM

Handle

Power Button

Speed Control Button

Folding Handle Button

Hand Vacuum Release Button

Hand Vacuum On/Off Button Hand Vacuum

Motorized Brush Powerhead

LED Headlights

Nozzle Release Button

2-In-1 Combination Tool

Combination Tool Storage

Charging Base

Charging Adapter

REPLACEMENT PARTS

Available online at www.vacmaster.com or call (866) 384-8432.

Item Part No.

Filter 561042108

Charging base 561042109

Combination Tool 561042111

Charging Adapter 561005107

Filter Basket 561042107

Brushroll 561042104

Hand Vacuum Handle

Filter

Filter Basket

Dust Cup

Dust Cup Release Button

-8-

1. Unfold the vacuum folding handle.

Put the vacuum folding handle upward, until there is a click from the folding

handle button.

2. Fit the end of the main body onto the neck of the motorized powerhead and

click into place.

GENERAL ASSEMBLY INSTRUCTIONS

$VVHPEO\,QVWUXFWLRQV

Click

-9-

3. Insert the hand vacuum into the slot on the bottom of main body, then press

the handle into locked slot and click into place.

4. Insert the top of the charging base into the bottom of the charging base and

lock into place.

5. Insert the charging connector into the charging port on the side of charging

base.





-10-

6. Plug the adapter into a wall outlet.

1RWH Use only the charger supplied with your cleaner to recharge.

7. Insert the 2-in-1 combination tool into the slot on the charging base for

convenient storage.

&KDUJLQJ,QVWUXFWLRQV

1. Before charging, make sure the cordless vacuum is turned OFF. With the

hand vacuum installed in the stick vacuum, insert the vacuum cleaner onto

the charger base as shown. Make sure the charging adapter is plugged into

an outlet.
