V-TAC 8663 Manual de usuario
2
YEARS
WARRANTY
*
INSTRUCTION MANUAL
GLASS HEATER
Please scan the QR code to access
the manual in multiple languages.
MULTI-LANGUAGE MANUAL
QR CODE
Table of Contents
INSTRUCTIONS: USING THE DEVICE
PRODUCT FEATURES
MINIMUM DISTANCE PLACEMENT OF THE DEVICE & NOTES
TRANSPORTATION
TROUBLESHOOTING
STORAGE & MAINTENANCE
INTRODUCTION & WARRANTY
INSTALLATION INSTRUCTIONS (FOOT ASSEMBLY)
PRODUCT COMPOSITION/ PART NAME
PACKAGING CONTENTS
6
7
7
APPLICATION & NOTES 8
8
9
11
11
12
13
MULTI-LANGUAGES 15
14
SAFETY WARNINGS & CAUTION 3
SAFETY WARNINGS & CAUTION
Please ensure to read all the safety warnings and instructions before using the product. Failure to follow the same
may result in electric shock/ fire/ serious injury.
• Please keep the manual handy for future references. You may also contact [email protected] for a pdf
version of the manual.
• Incorrect operation and improper handling can lead to faults on the device and injuries to the user
• Remove the packaging and make sure that the appliance is intact. If in doubt, do not use it and contact our
Technical team at [email protected]. Packaging materials (plastic bags, polystyrene, staples etc.) must be
kept out of the reach of children as they could be hazardous.
3
Indicates a potentially hazardous condition
that, if not avoided, may result in death or
serious injury.
WARNING SYMBOLS USED
WARNING!
This symbol indicates dangers to the life
and health of persons due to hot surface.
WARNING OF HOT SURFACE
SYMBOLS USED
CAUTION SYMBOLS USED
DO NOT COVER SYMBOLS USED
This marking indicates that this product
should not be disposed of with other
household wastes
This symbol located on the device indicates that it is prohibited to place objects (such as towels,
clothes etc.) above or directly in front of the device.
In order to avoid overheating and fire hazards, the heater must not be covered.
Caution, risk of electric shock.
ENGLISHENGLISH
• This appliance must only be used for the purpose for which it has been manufactured, i.e. for additional electrical
heating in rooms. Any other use is considered improper and therefore dangerous. The manufacturer is not respon-
sible for any damage caused by improper, incorrect or unreasonable use.
• If the appliance is faulty and/or operating incorrectly, switch it off without tampering with it. If the above is
disregarded, the safety of the appliance may be compromised.
• Before you put the plug into the socket, please check that the type of current and mains voltage correspond to
the instructions on the name plate/sticker on the appliance.
• Do not immerse the unit or mains plug in water or other liquids. Risk of electric shock! However, if this should
occur, remove the mains plug immediately and then have the unit checked by an expert before using it again.
• Ensure that the mains cable does not hang over sharp edges or allow it to become trapped.
• If the supply cord is damaged, it must be replaced by the manufacture, its service agent or similarly qualified
persons in order to avoid a hazard.
• The power cord on this appliance must NOT be replaced by the user. If the cord is damaged or requires replace-
ment, contact qualified personnel only.
• Ensure that all electric cables outside of the device are protected from damage (e.g. caused by animals). Never
use the device if electric cables or the power connection are damaged!
• This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory
or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards involved.
• Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without
supervision.
• Ensure to keep the suction grille clean.
• Children of less than 3 years should be kept away unless continuously supervised.
• Children aged from 3 years and less than 8 years shall only switch on/off the appliance provided that it has been
placed or installed in its intended normal operating position and they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards involved.
4
ENGLISH
• Children aged from 3 years and less than 8 years shall not plug in, regulate and clean the appliance or perform
user maintenance.
• This appliance is not a toy! Keep away from children and animals. Do not leave the device unattended during
operation.
• Do not use the device in small rooms if persons are present who cannot leave the room independently and who
are not under constant supervision.
• Do not use the device in potentially explosive rooms.
• Do not use the device in aggressive atmosphere.
• Ensure the device is setup in an upright and stable position.
• After cleaning the device, allow the device to dry out. Do not use the device when wet.
• Do not touch the device with wet or damp hands or feet.
• Do not expose the device to directly squirting water.
• Do not use the device near sources of water such as baths, showers or swimming pools. Risk of electric shock!
• Never insert any objects or limbs into the device.
• Do not cover or transport the device during operation.
• Do not remove any safety signs, stickers or labels from the device. Keep all safety signs, stickers and labels in
legible condition.
• Do not sit on the device.
• Check accessories and connection parts for possible damage prior to every use of the device. Do not use any
defective devices or device parts.
• Ensure to insert the mains plug into a properly secured mains socket.
• In order to avoid overheating, it is advisable to unwind the entire length of the power cord.
• Before cleaning or carrying out maintenance on the device, care or repair work on the device, disconnect it from
the electrical mains by removing the plug from the electrical outlet.
• Switch off the device and remove the plug from the electrical outlet when not in use.
• Defective power cables pose a serious health risk!
• During the installation of the device ensure the minimum distance between the wall and objects is minimum
50CM to 100CM.
5
ENGLISH
INTRODUCTION & WARRANTY
• To reduce the risk of fire, keep textiles, curtains, or any other flammable material a minimum distance of 1m
from the air outlet.
• Make sure that the air inlet and outlet are not obstructed.
• Do not place the device on combustible ground.
• Before maintenance, cleaning or transporting the device allow the device to cool down completely.
• Do not obstruct the ventilation or heat dispersion openings.
• Do not use the appliance immediately below a fixed power outlet.
• In order to avoid overheating, do not cover the heater.
• The heater must not be used if the glass panels are damaged.
• The heater must not be located immediately below a socket outlet.
• To reduce the risk of fire, keep textiles, curtains, or any other flammable material a minimum distance of 1m
from the air outlet.
• Keep the appliance away from hot objects (e.g. Hotplates) and open flames.
CAUTION: Some parts of this product can become very hot and cause burns. Particular attention has to be given
where children and vulnerable people are present.
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions
carefully before starting the installation and keep this manual handy for future reference. If you have any anoth-
er query, please contact our dealer or local vendor from whom you have purchased the product. They are trained
and ready to serve you at the best. The warranty is valid for 2 years from the date of purchase. The warranty
does not apply to damage caused by incorrect installation or abnormal wear and tear. The company gives no
warranty against damage to any surface due to incorrect removal and installation of the product. This product is
warranted for manufacturing defects only.
NOTE: This product is only designed for use inside well insulated rooms or for occasional use
6
ENGLISH
7
ENGLISH
PRODUCT FEATUERS
PACKAGING CONTENTS
1. Touchscreen control panel
2. LCD Display
3. Infrared Remote control
4. Feet with lockable swiveling wheels.
5. Timer from 1 to 24 hours to turn on/off as
per desired time.
6. Self-resetting thermostat and thermal fuse
7. Noiseless heating element
8. Temperature setting from 15°C-35°C.
9. Tempered glass panel
10. Splash water protected (IP 24)
11. Cable length 1.5M (EU Plug)
SKU 8663 8664
UNIT COLOR WHITE BLACK
POWER (WATTS) 2000W 2000W
TEMP RANGE 15°C - 35°C 15°C - 35°C
TIMER RANGE 1 Min - 24 Min 1 Min - 24 Min
INPUT VOLTAGE
CURRENT 8.7A 8.7A
PLUG TYPE EU EU
CABLE LENGTH 1.5 Meters 1.5 Meters
REMOTE DISTANCE 6 Meters 6 Meters
DIMENSION (LxWxH) 830x260x520mm 830x260x520mm
NET WEIGHT (Kgs) 7.7 7.7
GROSS WEIGHT (Kgs) 9.2 9.2
AC:220-240V, 50/60Hz
TECHNICAL SPECIFICATION
2 Foot With 4 Wheels
and 4 Screws Remote Control Instruction Manual
Glass Convector Heater
MODE
TEMP
TIMER
°C
+_
INSTALLATION INSTRUCTIONS (FOOT ASSEMBLY)
NOTES
1. Carefully unpack the box and remove the device and accessories.
Place the device (glass convector heater) on a protected surface.
Ensure the feet is properly fixed on the device.
2. Please check if all the articles are included and there is no
damage seen.
APPLICATIONS
1. Note: This product is only designed
for use inside well insulated rooms or
for occasional use.
2. The device must only be used in
closed rooms.
8
ENGLISH
Please ensure you have all the accessories (included) foot and screws
to assemble on the device
1. Please make sure the device is not connected to power.
2. Carefully place the device (glass convector heater) down (as
shown below) on a protected surface. Ensure the tempered glass
surface is facing downwards.
3. Using the ST4*12*3 screws install the feet on the device (glass
convector heater). Ensure the feet is properly fixed on the device.
4. Carefully lift the device up to its position. You can now move and
place the device in the desired location you choose.
NOTE: Using the lock feature on the brakes you can park the device
on the location to ensure its stability.
°C
+_
PRODUCT COMPOSITION/ PART NAME
9
ENGLISH
FIGURE 1
A
D
B
C
E
F
A B C D E F
LCD Display With Touch
Panel(Refer to Page 10 for
more details)
Swiveling Wheels Foot Locakable swiveling
wheels ON/OFF Switch Temperature Sensor
°C
+_
PRODUCT COMPOSITION/ PART NAME
10
ENGLISH
Power ON/OFF
Power ON/OFF
Mode
Mode
Temperature
Temperature
Display
Timer
+ Button
Timer
+ Button - Button
- Button
°C
+_
FIGURE 2
