UWE ZS Series Manual de usuario
Intelligent Weighing Technology, Inc.
ZS Series
ELECTRONIC WEIGHING SCALE
OPERATION MANUAL
A Higher Level of Precision…
A higher Level of Performance™
1
INDEX
Installation 2
Specifications 3
Keyboard Layout & Functions 4
Internal Functions 6
Initial Setup 8
Instructions for Use 11
Error Codes / Troubleshooting 15
Daily Care & Maintenance 17
© Intelligent Weighing Technology, Inc. All rights reserved worldwide.
2
INSTALLATION
1. Check and make sure that the following accessories are
included:
Operation Manual X 1
ZS Scale X 1
Stainless Steel Platter X 1
Power Adaptor X 1
Contact your dealer if any item is missing.
2. Install stainless steel platter.
3. Power upthe scale:
Insert one 9V battery (not supplied) into the battery
compartment or apply the external power adaptor. The
power adaptor jack is inside the battery compartment.
Before plugging the power adaptor into the electricity
outlet, check and make sure the input voltage of the
power adaptor matches with the output voltage of the
outlet.
If they do not match, please do not plug in the adaptor
and contact your dealer for a replacement.
** When the power adaptor is being used, please remove
all the batteries from the battery compartment. Failure to
do so might cause a battery leak/explosion or damage to
the scale. Do not use any rechargeable battery. This
scale does not recharge any batteries.
3
SPECIFICATIONS
Model Capacity Division
ZS-600 600g/1lb 5.195oz 0.1g/0.005oz
ZS-3000 3000g/6lb 9.98oz 0.5g/0.02oz
ZS-6000 6000g/13.4lb.00oz 1g/0.05oz
Power
Source 9V battery or External Power Adaptor
Max. Zero
Range 2% of Rated capacity
Max. Tare
Range 100% of Rated capacity (Subtractive)
Weight
Units (Note
A) Metric (g), Avoirdupois (lb & oz) & Taiwanese (tg)
Operation
Environment 0o~40oC (32o~104oF), Non-condensed. R.H.≤85%
Specifications subject to change without notice
NOTE A:
To comply with the law of certain countries, Avoirdupois and
Taiwanese weight units may be disabled. Contact your dealer
for more information.
4
KEYBOARD LAYOUT & FUNCTIONS
OFF KEY
Press this key to turn scale off.
ON/ZERO KEY
Press this key to turn scale on or set weight to zero.
TARE KEY
Press this key to tare off the weight of a container.
MODE KEY
Press this key to switch between weight units.
5
KEYBOARD LAYOUT & FUNCTIONS
ZERO INDICATOR
This indicator appears to indicate zero weight status.
MINUS INDICATOR
This indicator appears to indicate negative weight values.
LO-BAT INDICATOR
When this indicator appears, change the battery.
WEIGHT INDICATOR
Displays the weight of the item placed on the scale.
NET INDICATOR
This indicator appears to indicate the tare function is in
operation and weight shown is net weight.
METRIC INDICATOR
This indicator appears to indicate the metric weight unit is
in use.
AVOIRDUPOIS UNITS INDICATOR
This indicator appears to indicate the avoirdupois weight
unit is in use.
6
INTERNAL FUNCTIONS
The scale is equipped with 13 internal functions, which are:
FUNCTION
NUMBER FUNCTION DESCRIPTION
Fun 0 For Qualified Technical Personnel Only
Fun 1 For Qualified Technical Personnel Only
Fun 2 Check Display Segment
Fun 3 Select Auxiliary Weight Units and offset value
Fun 4 Select Auto Power Off
**Fun 5 Select Rs-232 Baud Rate & Protocol
Fun 6 Select Digital Motion Filtering Function
**Fun 7 Select Serial Output Mode
**Fun 8 Select UTP Printout Format
(This function is UTP related)
Fun 9 Select Auto Tare Function
**Fun 12 Select Number Of Printout Copy
(This function is UTP related)
**Fun 15 Set and Send Date & Time Data to UTP
(This function is UTP related)
Fun 19 For Qualified Technical Personnel Only
** Only installed with RS232 option.
7
INTERNAL FUNCTIONS
Do not alter any parameters set in Fun 0, 1 & 19, which may
cause system instability, error, or non accurate weighing result.
If entered by mistake, press OFF immediately. Contact your
dealer for more information.
8
INITIAL SETUP
How to select internal functions
a. Turn scale off
b. Press and hold TARE, then press ON/ZERO
c. Scale displays Fun-0
d. Press TARE until scale displays the desired internal
function number
e. Press MODE to enter and trigger various setting values.
f. Press TARE to select
g. Scale displays the next internal function
h. Repeat d&efor next desired setting, or
i. Press TARE to save and restart scale, or
j. Press OFF to save without restarting
k. Pres ON to restart scale
Display Segment Check
Under this function, backlight (if equipped) functional
indicators and display segments will be lit up. Contact
your dealer if any display element is missing.
Select Auxiliary Weight Units
2 auxiliary weight units in addition to metric are available.
These are Avoirdupois and Taiwanese Units.
Under this function, scale displays capacity and division
followed by the selected weight unit on Weight Panel.
9
INITIAL SETUP
The example below 600.1 is the capacity and division of
ZS-600 (600g x 0.1g), which is used for illustration.
600.1 g(metric only)
600.1 g lb/oz (metric and Avoirdupois weight unit
enable)
6.0.0.1g lb/oz (metric, Avoirdupois and Taiwanese
weight units all enable)
Select Auto Power Off Function
5 parameters are available: -
0oFF (Auto Power Off Function disabled)
4oFF (Auto off when left idle for 4 min)
10oFF (Auto off when left idle for 10 min)
20oFF (Auto off when left idle for 20 min)
30oFF (Auto off when left idle for 30min)
** Under the Auto Power Off function mode, the scale will
turn off automatically when it is left idle for the selected
time.
