UTE UH2-44-SET Manual de usuario
UH2-44: 4x4 HDMI 2.0 HDBaseT Matrix Switcher
U.T.E. electronic GmbH & Co. KG www.ute.de
UH2-44: 4x4 HDMI 2.0 HDBaseT Matrix Switcher
U.T.E. electronic GmbH & Co. KG www.ute.de
Preface
Read this user manual carefully before using the product. Pictures shown in this
manual are for reference only. Different models and specifications are subject to real
product.
This manual is only for operation instruction, please contact the local distributor for
maintenance assistance. The functions described in this version were updated till
November, 2019. In the constant effort to improve the product, we reserve the right to
make functions or parameters changes without notice or obligation. Please refer to the
dealers for the latest details.
All product function is valid till 2019-11.
Trademarks
Product model and logo are trademarks of U.T.E. electronic GmbH & Co. KG.
Any other trademarks mentioned in this manual are acknowledged as the properties of
the trademark owner. No part of this publication may be copied or reproduced without
the prior written consent.
FCC Statement
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. It has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a commercial
installation.
Operation of this equipment in a residential area is likely to cause interference, in
which case the user at their own expense will be required to take whatever measures
may be necessary to correct the interference.
Any changes or modifications not expressly approved by the manufacture would void
the user’s authority to operate the equipment.
UH2-44: 4x4 HDMI 2.0 HDBaseT Matrix Switcher
U.T.E. electronic GmbH & Co. KG www.ute.de
SAFETY PRECAUTIONS
To ensure the best performance from the product, please read all instructions carefully
before using the device. Save this manual for further reference.
⚫Unpack the equipment carefully and save the original box and packing material for
possible future shipment.
⚫Follow basic safety precautions to reduce the risk of fire, electrical shock and injury
to persons.
⚫Do not dismantle the housing or modify the module. It may result in electrical shock
or burn.
⚫Using supplies or parts not meeting the specifications of product may cause damage,
deterioration or malfunction.
⚫Refer all servicing to qualified service personnel.
⚫To prevent fire or shock hazard, do not expose the unit to rain, moisture or install this
product near water.
⚫Do not put any heavy items on the extension cable in case of extrusion.
⚫Do not remove the housing of the device as opening or removing housing may
expose you to dangerous voltage or other hazards.
⚫Install the device in a place with fine ventilation to avoid damage caused by
overheat.
⚫Keep the module away from liquids.
⚫Spillage into the housing may result in fire, electrical shock, or equipment damage. If
an object or liquid falls or spills on to the housing, unplug the module immediately.
⚫Do not twist or pull by force ends of the optical cable. It can cause malfunction.
⚫Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to
the device before cleaning.
⚫Unplug the power cord when left unused for a long period of time.
⚫Information on disposal for scrapped devices: do not burn or mix with general
household waste, and please treat them as normal electrical wastes.
UH2-44: 4x4 HDMI 2.0 HDBaseT Matrix Switcher
U.T.E. electronic GmbH & Co. KG www.ute.de
Table of Contents
1. Product Introduction....................................................................................................1
1.1 Features ............................................................................................................2
1.2 Package List ......................................................................................................3
2. Panel Description........................................................................................................4
2.1 4x4 HDMI 2.0 HDBT Matrix Switcher UH2-44 ...................................................4
2.1.1 Matrix Switcher Front Panel.....................................................................4
2.1.2 Matrix Switcher Rear Panel .....................................................................5
2.2 4K60 HDMI2.0 HDBaseT Receiver....................................................................7
2.2.1 HDBT Receiver Front and Rear Panel.....................................................7
3. System Connection.....................................................................................................8
3.1 Usage Precaution ..............................................................................................8
3.2 System Diagram UH2-44...................................................................................8
4. Button Control.............................................................................................................9
4.1 Signal Switching ................................................................................................9
4.1.1 Switch an input to an output ....................................................................9
4.1.2 Switch an input to several outputs ...........................................................9
4.2 Panel Button Locking/Unlocking ......................................................................10
4.3 Status Information Inquiry................................................................................10
4.4 EDID Management ..........................................................................................11
4.4.1 Enter EDID management tab.................................................................11
4.4.2 To copy the EDID data from one HDBT output to one or several inputs 11
4.4.3 To copy the EDID data from one HDMI output to one or several inputs 12
4.4.4 To invoke the built-in EDID data ............................................................12
4.5 Audio Setting ...................................................................................................14
4.5.1 Audio Source Selection .........................................................................14
4.5.2 L+R Output Audio Volume Control.........................................................15
4.6 Preset Setting ..................................................................................................16
4.6.1 Save the current switching routing to a preset.......................................16
4.6.2 Recall a saved preset ............................................................................16
4.7 IP Address Inquiry............................................................................................17
UH2-44: 4x4 HDMI 2.0 HDBaseT Matrix Switcher
U.T.E. electronic GmbH & Co. KG www.ute.de
5. GUI Control...............................................................................................................18
5.1 Signal Switching ..............................................................................................19
5.2 Audio Setting ...................................................................................................20
5.2.1 Audio Source Selection .........................................................................20
5.2.2 L+R Output Audio Volume Control.........................................................21
5.3 Configuration ...................................................................................................22
5.3.1 Down-scaling.........................................................................................22
5.3.2 HDCP Setting ........................................................................................23
5.3.3 EDID Copy.............................................................................................24
5.3.4 EDID Setting..........................................................................................25
5.4 CEC Control ....................................................................................................26
5.4.1 Input Source Device Control..................................................................26
5.4.2 HDBT Output Device Control.................................................................27
5.4.3 HDMI Output Device Control .................................................................28
5.5 RS232 Control .................................................................................................29
5.6 Access Setting .................................................................................................30
5.7 Interface Setting...............................................................................................31
5.8 Network Setting ...............................................................................................32
5.9 GUI Upgrade ...................................................................................................33
6. IR Control..................................................................................................................34
6.1 IR Remote Control...........................................................................................34
6.2 IR Pass-through Control ..................................................................................35
6.2.1 Control Local Input Device from Remote ...............................................35
6.2.1.1. Control local input device through IR OUT port ..................35
6.2.1.2. Control local input device through IR ALL OUT port ...........36
6.2.2 Control Remote Output Device from Local ............................................37
6.2.2.1. Control remote device through IR IN port...........................37
6.2.2.2. Control remote device through IR ALL IN port....................38
7. RS232 Control ..........................................................................................................39
7.1 RS232 Control Connection ..............................................................................39
7.1.1 Control the Matrix Switcher from Local ..................................................39
UH2-44: 4x4 HDMI 2.0 HDBaseT Matrix Switcher
U.T.E. electronic GmbH & Co. KG www.ute.de
7.1.2 Control the Matrix Switcher from Remote ..............................................40
7.1.3 Control the Remote Third-party Device from Local................................41
7.1.4 Control the Local Third-party Device from Remote................................42
7.2 RS232 Control Software ..................................................................................43
7.3 RS232 Commands ..........................................................................................44
7.3.1 System Setting ......................................................................................44
7.3.2 Signal Switching ....................................................................................48
7.3.3 Audio Setting .........................................................................................50
7.3.4 HDCP Setting ........................................................................................52
7.3.5 EDID Management ................................................................................53
7.3.6 Third-party Device Control.....................................................................55
7.3.7 CEC Control ..........................................................................................56
7.3.7.1. Control the input source: ....................................................57
7.3.7.2. Control the output display device: ......................................57
8. Firmware Upgrade ....................................................................................................58
9. Specification .............................................................................................................59
9.1 Matrix Switcher UH2-44...................................................................................59
9.2 HDBaseT Receiver ..........................................................................................61
10. Panel Drawing ........................................................................................................63
11. Troubleshooting & Maintenance..............................................................................64
12. Customer Service ...................................................................................................65
UH2-44: 4x4 HDMI 2.0 HDBaseT Matrix Switcher
U.T.E. electronic GmbH & Co. KG 1 www.ute.de
1. Product Introduction
UH2-44-Set is a professional HDMI 2.0 HDBaseT matrix switcher Kit, which consists
of a 4x4 HDMI2.0 HDBaseT Matrix Switcher (UH2-44) four HDBaseT Receivers and
accessories.
The UH2-44 matrix switcher is a four-input by four-output HDBaseT and HDMI matrix
with HDCP 2.2 and up to 4K/UHD@60Hz video support.
It transmits 4K video to distances up to 40 meters (131 feet) and 1080p video to
distances up to 70 meters (230 feet) over a single CATx Ethernet cable.
The four HDBaseT outputs support 24V Power over Cable (PoC) feature, allowing the
receivers to draw their power from the matrix over the HDBaseT cable.
The UH2-44 matrix switcher features comprehensive EDID management and
advanced HDCP handing to ensure maximum functionality with a wide range of video
sources.
The matrix switcher not only supports bi-directional IR, RS232 extension but also has
IR, RS232, and TCP/IP control options.
The product provides performance in control and transmission, which could be used in
a number of different installation scenarios, for example, with computers, for
monitoring purposes, large screen displays, conference systems, television education,
bank security institutions, etc.
UH2-44: 4x4 HDMI 2.0 HDBaseT Matrix Switcher
U.T.E. electronic GmbH & Co. KG 2 www.ute.de
1.1 Features
⚫4x4 HDBaseT matrix switcher with audio matrix.
⚫Fully compliant with the HDMI 2.0 and HDCP 2.2.
⚫Supports HDMI resolution up to 4K@60Hz 4:4:4, HDR10.
⚫Features four mirrored HDMI outputs for four HDBaseT outputs, and the four HDMI
outputs support 4K to 1080p down-scaling.
⚫The four HDBaseT outputs support 24V PoC, allowing the receivers to draw their
power from the matrix switcher over the HDBaseT cable.
⚫Transmits 4K signal to the distance up to 131 feet (40 meters) and 1080p signal to
the distance up to 230 feet (70 meters) over a single CATx Ethernet cable.
⚫Supports audio matrix. Provides four digital SPDIF audio outputs and four analog
L+R audio outputs for HDMI input audio de-embedding and HDBaseT output audio
de-embedding. Moreover, the four digital SPDIF audio outputs supports ARC audio
output from receivers.
⚫Volume adjustment for analog L+R audio outputs.
⚫Supports comprehensive EDID management and advanced HDCP handling.
⚫Controllable via front panel buttons, RS232 local and pass-through, IR local and
pass-through, CEC, and TCP/IP (built-in GUI).
UH2-44: 4x4 HDMI 2.0 HDBaseT Matrix Switcher
U.T.E. electronic GmbH & Co. KG 3 www.ute.de
1.2 Package List
HDBaseT Matrix
Switcher
⚫1x UH2-44: 4x4 HDMI 2.0 HDBaseT matrix switcher
⚫2x Mounting Ears with 6 Screws
⚫4x Plastic Cushions with 4 Screws
⚫1x IR Receiver
⚫1x IR Remote
⚫1x RS232 Cable (3-pin to DB9)
⚫8x 3-pin Terminal Blocks
⚫1x Power Cord
HDBaseT Receiver
⚫4x HDBaseT Receivers
⚫8x Mounting Ears with 16 Screws
⚫16x Plastic Cushions
⚫4x 3-pin Terminal Blocks
⚫1x User Manual
Note: Please contact your dealer immediately if you found any damage or defect
in the components.
Tabla de contenidos
Otros manuales de Conmutador de matriz de UTE
