usi UNA-P3 Manual de usuario
Product Line UMD (MPC)
Doc. NO.
CONFIDENTIAL Low ;Normal High
The information contained herein is the exclusive property of Universal Scientific Industrial Co., Ltd. and shall not be
distributed, reproduced, or disclosed in whole or in part without prior written permission of USI Co., Ltd.
Doc. Title
Originator
UNA-P3 (UNAPlus)/ UNA-L3 (UNA-
Lite)Function EVB User Guide
Max Shu
Date 2013.06.06
Version V1.1
The information contained herein is the exclusive property of Universal Scientific Industrial Co., Ltd. and shall not be distributed,
reproduced, or disclosed in whole or in part without prior written permission of USI Co., Ltd. 頁1
Revision Record
Version Revise content Date
1.1 Initial Release 2013.06.06
The information contained herein is the exclusive property of Universal Scientific Industrial Co., Ltd. and shall not be distributed,
reproduced, or disclosed in whole or in part without prior written permission of USI Co., Ltd. 頁2
Category
1. Illustration of Function EVB.................................................................3
2. General Mode.........................................................................................5
2‐1SettingofJumpers&Switches .........................................................................5
3. Settings for Download /Update Mode.................................................10
4. Advance Mode......................................................................................11
4‐1Moduleon/offControl...................................................................................11
4‐2VoltageSettings .............................................................................................11
4‐3UseExternalPowerSupplier .......................................................................... 12
4‐4CurrentMeasurement.................................................................................... 13
4‐5SettingsforSlide‐StyleSwitch(J42)................................................................ 13
4‐6PCMSignal..................................................................................................... 14
4‐6‐1PCMSignalPort(J24).................................................................................................................................... 14
4‐6‐2PCMLoopSettings........................................................................................................................................ 15
4‐6‐3ExternalI2CInterfacetoControlAudioCodec.............................................................................................. 16
4‐7UART0&UART1SignalPort(J23)................................................................... 17
4‐8WakeupControl ............................................................................................. 18
4‐8‐1USBMode..................................................................................................................................................... 18
4‐8‐2USB+UARTMode .......................................................................................................................................... 19
The information contained herein is the exclusive property of Universal Scientific Industrial Co., Ltd. and shall not be distributed,
reproduced, or disclosed in whole or in part without prior written permission of USI Co., Ltd. 頁3
User Guide for UNA PLUS Function EVB
1. Illustration of Function EVB
Figure. Layout of Function EVB
The information contained herein is the exclusive property of Universal Scientific Industrial Co., Ltd. and shall not be distributed,
reproduced, or disclosed in whole or in part without prior written permission of USI Co., Ltd. 頁4
Reference Type Description Support Non-Support
J8 USB Conn. Connect host PC or download firmware V
J7 Pin Header Select external power supplier (+)
(Default is ‘Open’.)V
J9 Pin Header Select external power supply (-)
(Default is ‘Open’.)V
SW1 On/off switch Module on/off control V
J55 Pin Header Module on/off control (Default is ‘Open’.)V
J15 Ant. Conn. Main antenna SMAConnector V
J16 Ant. Conn. AUX antenna SMAConnector V
U24 SIM 1 Conn. Connect SIM Card V
U21 SIM 2 Conn. Connect SIM Card V
J18 COM port 0 Debug Pin V
J19 COM port 1 Transmit/ ReceiveAT Command. V
J21 Pin Header Factory Test (Default is ‘Open’.)V
J23 Pin Header UART0 & UART1 signal connector
(Default is ‘Open’.)V
J30 Pin Header Factory Test (Default is ‘Open’.)V
J24 Pin Header PCM signal connector (Default is ‘Open’.)V
J56 Pin Header Wake up AP in AP sleep mode
(wake up AP) (Default is ‘Open’.)V
J54 Pin Header Wake up module in module sleep mode
(wake up modem) (Default is ‘Open’.)V
J2 Headset Conn. EAR PHONE & MIC V
J28 Audio Conn. Audio LINE-OUT V
J29 Audio Conn. Audio LINE-IN V
J42 Switch Conn. Slide-Style Switch. V
J52 Pin Header Factory Test (Default is ‘Open’.)V
J51 Pin Header Factory Test (Default is ‘Open’.)V
J57 Pin Header Factory Test (Default is ‘Open’.)V
J34 Pin Header Factory Test (Default is ‘Open’.)V
J35 Pin Header Factory Test (Default is ‘Open’.)V
J50 Pin Header Factory Test (Default is ‘Open’.)V
J22 Pin Header Factory Test (Default is ‘Open’.)V
J25 Pin Header Factory Test (Default is ‘Open’.)V
J26 Pin Header Factory Test (Default is ‘Open’.)V
The information contained herein is the exclusive property of Universal Scientific Industrial Co., Ltd. and shall not be distributed,
reproduced, or disclosed in whole or in part without prior written permission of USI Co., Ltd. 頁5
2. General Mode
2-1 Setting of Jumpers & Switches
Figure. Settings of general mode
Step1. Remove every jumper on the board.
Step2
Step3
Step4 Step5
Step6
Step7
Step8
The information contained herein is the exclusive property of Universal Scientific Industrial Co., Ltd. and shall not be distributed,
reproduced, or disclosed in whole or in part without prior written permission of USI Co., Ltd. 頁6
Step2. Keep ‘R19’and ‘R20’short.
Figure. Keep ’R19’and ‘R20’short.
Step3. For ‘SW1’, select 1-2. (Upper position)
Figure. For ‘SW1’, select 1-2.
Step4. For ‘J42’, eight switches should be in ‘OFF’position.
Figure. Switches in ‘OFF’position.
R19
R20
ON
OFF
The information contained herein is the exclusive property of Universal Scientific Industrial Co., Ltd. and shall not be distributed,
reproduced, or disclosed in whole or in part without prior written permission of USI Co., Ltd. 頁7
Step5. Insert SIM card.
Figure. Insert correctly SIM card.
Step6. Set up Antenna.
a. Connect bottom of mini card by U.FL cable as following photo.
Figure. Connect by U.FLcable.
b.Connect EVB and mini card by U.FL cable. Put mini card on EVB.
Figure. Connect mini card and EVB.
The information contained herein is the exclusive property of Universal Scientific Industrial Co., Ltd. and shall not be distributed,
reproduced, or disclosed in whole or in part without prior written permission of USI Co., Ltd. 頁8
b. Connect SMA antenna.
Figure. Connect antenna.
Step7. Set up Module.
a. By 30 degree angle, lean mini card and insert it on the socket, J4.
Figure. Insert mini card.
b. Press mini card until it is stuck by connector, J5.
Figure. Mini card is stuck.
The information contained herein is the exclusive property of Universal Scientific Industrial Co., Ltd. and shall not be distributed,
reproduced, or disclosed in whole or in part without prior written permission of USI Co., Ltd. 頁9
Step8. Connect computer by USB cable.
Recommended USB cable length is less than 60 mm.
Figure. Connect PC by USB cable.
