Installation Guide

Package contents

Your U.S. Robotics 56K PC Card Modem package contains the following items:

• U.S. Robotics 56K PC Card Modem

• RJ-11 phone cord (model USR0756-XJ only)

• RJ-11 jack-to-PC card connector cable (model USR0756-CB only)

• Quick Installation Guide

• Installation CD-ROM, which contains software and a User Guide for use

with your new modem

What you will need

You will need the following to install your U.S. Robotics 56K PC Card Modem:

• Notebook computer with an empty PC card slot

• Analog telephone line

Caution: The U.S. Robotics 56K PC Card Modem requires a standard

analog telephone line. Do not connect your modem to a digital

telephone line. Digital lines are commonly used in office buildings and

hotels. If you are unsure whether your line is analog or digital, ask your

network administrator, building management, or your local telephone

company.

Before You Begin: Preparing for installation

Note: U.S. Robotics recommends uninstalling any other modems that

are installed in your system and unplugging all telephone cords

connected to these modems. Refer to your previous modem's

documentation for instructions.

Write down your new modem's serial number, which is located on the white bar

code sticker on the modem and on the modem's box, in the space below. If you

ever need to call our Technical Support department, you will need the serial

number and the model number to receive assistance. If you need to get

assistance or download drivers from the Web site, you will need the product ID.

Model Number Product ID Serial Number

0756 USR0756-XJ

USR0756-CB

Eclipse Book English.book Page 3 Wednesday, November 5, 2003 11:55 AM

Installing the U.S. Robotics 56K PC Card Modem

Note: For computers that are running Windows NT 4.0, go to the section

entitled “Windows NT4.0 Installation” on page 6.

Step One: Install the modem.

Turn off your computer. Insert the modem into the PC card slot in your computer.

The top of the modem has an arrow indicating which end should be inserted into

the computer. Make sure that the modem is firmly seated in the PC card slot.

Step Two: Connect the phone cord.

• PC cards with model number USR0756-XJ

have an XJACK®connector. Push in on the

XJACK connector to pop it out of the PC

card. Connect one end of a standard RJ-11

phone cord to the XJACK connector and

the other end to an analog telephone wall

jack. Refer to this illustration:

• PC cards with model number USR0756-CB

do not have an XJACK connector and use

an RJ-11 jack-to-PC card connector cable.

Connect the PC card connector to the

modem and the RJ-11 connector to an

analog telephone wall jack. Refer to this

illustration:

• To connect to a telephone system outside North America, use an

adapter that is appropriate for the country you are in.

Step Three: Install the drivers.

Note: If at any time during the installation you are prompted to select

the location of your installation drivers, select the CD-ROM drive where

the Installation CD-ROM is loaded (D:\ for example).

Note: Windows 2000 and XP users must be logged in using an account

with administrative privileges before attempting to install the modem

drivers. Windows XP Home Edition users have administrative privileges

by default.

Eclipse Book English.book Page 4 Wednesday, November 5, 2003 11:55 AM

Windows XP

Turn on your computer. When the Found New Hardware Wizard detects your

modem, insert the Installation CD-ROM into your CD-ROM drive. Windows

should automatically find the driver for your modem. (If not, select Install the

software automatically (Recommended) and click Next.) Select your U.S.

Robotics modem description and click Next. If a Hardware Installation message

box appears, click Continue Anyway*. Click Finish to complete the installation.

* U.S. Robotics has thoroughly tested this driver in conjunction with the supported hardware and has

verified compatibility with Windows XP.

Windows 2000

Turn on your computer and log in. Insert the Installation CD-ROM into your CD-

ROM drive. If the License Agreement window appears, click No. After Windows

detects your modem, you must update the driver.

Click Windows Start, Settings, and Control Panel. Double-click the System icon

and select the Hardware tab. Click Device Manager and double-click Modems to

expand the Modems key. Double-click Standard PCMCIA Card Modem from the

list. Click the Driver tab and click Update Driver.

When the Upgrade Device Driver Wizard appears, click Next. Select Search for a

suitable driver for my device (recommended) and click Next. Select CD-ROM

drives and click Next. When the driver is found on your CD-ROM drive, click Next.

A Digital Signature Not Found warning may appear. If it does, click Yes**. Click

Finish to complete the installation.

** U.S. Robotics has thoroughly tested this driver in conjunction with the supported hardware and has

verified compatibility with Windows 2000.

Windows Me

Turn on your computer. When the Add New Hardware Wizard appears, insert the

Installation CD-ROM into your CD-ROM drive. Select Automatic search for a

better driver (Recommended) and click Next. Click Finish to complete the

installation.

Windows 98

Turn on your computer. When the Add New Hardware Wizard appears, insert the

Installation CD-ROM into your CD-ROM drive and click Next. Select Search for

the best driver for your device (Recommended) and click Next. Select CD-ROM

drive and click Next. Click Finish to complete the installation.

Windows 95

Turn on your computer. When the Update Device Driver Wizard detects your

modem, insert the Installation CD-ROM into your CD-ROM drive and click Next.

Windows will find the installation file on your CD-ROM. Click Finish to complete

the installation.

Eclipse Book English.book Page 5 Wednesday, November 5, 2003 11:55 AM

Windows NT 4.0 Installation

Note: Windows NT 4.0 users must be logged in using an account with

administrative privileges before attempting to install the modem

drivers.

Note: Do not insert your modem in the PC card slot of your notebook

computer until you complete the following installation procedure.

Turn on your computer. After you log in, insert the Installation CD-ROM into your

CD-ROM drive. Click Windows Start, Settings, and then Control Panel. Double-

click the Ports icon. Click Add. Select the next free COM Port Number (default

setting) and click OK. Click Don’t Restart Now. Click Close in the Ports window.

In the Control Panel window, double-click the Modems icon. Select Don't detect

my modem. I will select from a list and click Next. Click Have Disk. Type D:\ in

the dialog box. (If your CD-ROM drive uses a different letter, type that letter in

place of D.) Click OK. Select your U.S. Robotics modem description and click

Next. Select the COM port that was added above and click Next. Click Finish to

complete the installation. Close any open windows and shut down your

computer. Insert the modem into the PC card slot, connect the phone cord, and

turn on your computer.

Congratulations! You have completed the installation of your

U.S. Robotics 56K PC Card Modem. Now register your modem.

1. Insert the Installation CD-ROM into your CD-ROM drive. The Installation CD

window should automatically appear. If the License Agreement window

appears, click Yes.

If the Installation CD window does not appear, click Windows Start and

then Run. Type D:\setup.exe in the “Run” dialog box. (If your CD-ROM drive

uses a different letter, type that letter in place of D.)

2. Select Support, Registration & Warranty, and then click the URL under

Registration. Follow the on-screen instructions to complete the registration

of your modem. You may also register online at www.usr.com/productreg

Note: For information about installing the modem in Windows 3.1,

DOS, or Linux operating systems, refer to the User Guide on the

Installation CD-ROM included with your modem.

Eclipse Book English.book Page 6 Wednesday, November 5, 2003 11:55 AM

Would you like to install the JetSetter software?

Note: You must install JetSetter software in order to use this modem in

countries outside the United States.

JetSetter software allows you to select the country where you plan to use your

modem and automatically configures the modem for that country's telephone

system to ensure compatibility and best performance.

1. Insert the Installation CD-ROM into your CD-ROM drive. The Installation CD

window should automatically appear. If the License Agreement window

appears, click Yes.

If the Installation CD window does not appear, click Windows Start and

then Run. Type D:\setup.exe in the “Run” dialog box. (If your CD-ROM drive

uses a different letter, type that letter in place of D.)

2. Select Software, JetSetter, and then Install. Follow the on-screen

instructions to complete the installation of the JetSetter software.

Would you like to install the Classic PhoneTools software?

Classic PhoneTools software allows your computer to perform the functions of a

fax machine, answering machine, and speakerphone all in one application.

(Answering machine and speakerphone capabilities are only available with voice

modems.) You can also use Classic PhoneTools to connect to another computer,

electronic bulletin board service (BBS), or office network using terminal

emulation.

1. Insert the Installation CD-ROM into your CD-ROM drive. The Installation CD

window should automatically appear. If the License Agreement window

appears, click Yes.

If the Installation CD window does not appear, click Windows Start and

then Run. Type D:\setup.exe in the “Run” dialog box. (If your CD-ROM drive

uses a different letter, type that letter in place of D.)

2. Select Software, PhoneTools, and then Install. Follow the on-screen

instructions to complete the installation of the Classic PhoneTools

software.

Note: Additional software may also be included on the Installation CD-

ROM. You can install this software in the same manner that is described

above.

Eclipse Book English.book Page 7 Wednesday, November 5, 2003 11:55 AM

Troubleshooting

Having trouble with your modem? Try these basic

troubleshooting steps first!

Verify that the phone cord is installed correctly.

The phone cord should be plugged into the XJACK®connector or PC card

connector on the modem and into the telephone wall jack. Use the phone

cord included in your modem’s box, if possible.

Verify that the modem was installed correctly.

Make sure that your modem is physically installed correctly in your

computer. You must press the modem in firmly so that it is seated properly

in the PC card slot.

Next, make sure that the modem’s drivers have been installed correctly.

Follow the instructions for your operating system:

Windows XP (Classic View): Click Windows Start and then Control Panel.

Double-click the Phone and Modem Options icon.

Windows XP (Category View): Click Windows Start, Control Panel, Network

and Internet Connections, and then Phone and Modem Options.

Windows 2000: Click Windows Start, Settings, and then Control Panel.

Double-click the Phone and Modem Options icon.

Click the Modems tab. You should see a description of your new

U.S. Robotics modem and a COM port setting. If you do not see a

description of your modem, see the Note at the end of this section.

Make sure that your new U.S. Robotics modem is selected and click

Properties. Click the Diagnostics tab. Click Query Modem. You should see a

series of commands and responses from the modem. This means that the

installation was successful.

If you do not see commands and responses, shut down and restart your

computer. To determine whether your modem is functioning properly,

repeat the steps above. If your modem is still not working, refer to the

additional troubleshooting steps in this guide.

Windows Me, 98, and 95: Click Windows Start, Settings, and then Control

Panel. Double-click the Modems icon. In the Modems Properties screen,

you should see a description for your new U.S. Robotics modem. If you do

not see a description of your modem, see the Note at the end of this section.

Eclipse Book English.book Page 8 Wednesday, November 5, 2003 11:55 AM

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Módem de US Robotics

US Robotics

US Robotics SureConnect 9001 Manual de usuario

US Robotics

US Robotics Courier USR3510 Manual de usuario

US Robotics

US Robotics Courier V.Everything 3CP3453 Manual de usuario

US Robotics

US Robotics 56K USB MODEM - QUICK REV 2.0 Manual de usuario

US Robotics

US Robotics COURIER 56K BUSINESS MODEM - QUICK FOR... Manual de usuario

US Robotics

US Robotics USR5635 Manual de usuario

US Robotics

US Robotics 56K SERIAL CONTROLLER FAXMODEM Manual de usuario

US Robotics

US Robotics USR5699C Manual de usuario

US Robotics

US Robotics 56K SERIAL CONTROLLER FAXMODEM Manual de usuario

US Robotics

US Robotics 56K INTERNAL VOICE FAXMODEM - QUICK FOR WINDOWS REV... Manual de usuario

US Robotics

US Robotics 3CP5699A Manual de usuario

US Robotics

US Robotics USR9001 Manual de usuario

US Robotics

US Robotics USR802972B-OEM Manual de usuario

US Robotics

US Robotics USR5686D Manual de usuario

US Robotics

US Robotics 56 K SOFTMODEM - COMMAND REFERENCE REV 1 Manual de instalación

US Robotics

US Robotics USR5699B Manual de usuario

US Robotics

US Robotics Courier V.34 Manual de usuario

US Robotics

US Robotics Sportster Manual de usuario

US Robotics

US Robotics 56K SERIAL CONTROLLER FAXMODEM Manual de usuario

US Robotics

US Robotics COURIER HST Manual de usuario

US Robotics

US Robotics 56K SERIAL CONTROLLER FAXMODEM Manual de usuario

US Robotics

US Robotics 5630b Manual de usuario

US Robotics

US Robotics USR5638 Manual de usuario

US Robotics

US Robotics 5686 Manual de usuario

Manuales populares de Módem de otras marcas

Davicom

Davicom DM562AP Manual de usuario

EpiValley

EpiValley TATA indicom SXC-1080 Manual de usuario

Zte

Zte WiMAX Manual de usuario

Intelimax

Intelimax MA-2060 Manual de usuario

SMC Networks

SMC Networks D3CM1604V Manual de uso y cuidado

Telstra

Telstra Wi-Fi 4G Advanced Pro X Manual de usuario

Thrane&Thrane

Thrane&Thrane imarsat EXPLORER 300 Manual de usuario

Samsung

Samsung AceLink SAM-335A Manual de usuario

Enfora

Enfora Enabler-G Guía de configuración rápida

iRZ

iRZ ATM2-232 Manual de usuario

Zhone

Zhone 6310 Manual de usuario

Paradyne

Paradyne Hotwire 7976 Manual de usuario

MaxTech

MaxTech Plug & Play Internal Voice/FAX/Data/SVD... Manual de usuario

Zte

Zte MF823 Manual de usuario

Four-Faith

Four-Faith F1403 Manual de usuario

Sierra Wireless

Sierra Wireless AIRLINK MP595W Manual de usuario

Gemtek

Gemtek WiMAX WIXFBR-103 Manual de usuario

Zoom

Zoom 1070 Series Manual de usuario
