Universal Remote Control KP-900i Manual de usuario
Operating Your System
With The KP-900i Wireless
Keypad/Remote
This remote control was
Custom Programmed for you by:
For questions about your Custom Programming call:
Custom Programming of a complex home theater and/or a multi-room
system is one of the most challenging tasks within an audio/video instal-
lation. It involves an intimate knowledge of how the components interact
and exact details on the proper sequences of control.
Only a Complete Control dealer has the requisite experience and training
to quickly and effectively customize a remote control for true automated
operation.
Congratulations on your choice!
KP-900i Owners Manual © 2008-2013 Universal Remote Control, Inc.
Front Cover Photo courtesy of Stone Glidden, King of Prussia and
Doylestown, PA
www.stoneglidden.com
The information in this owner’s manual is protected by the copyright laws of the
United States and other countries. No part of this manual may be copied or
reproduced in any form without prior written consent from Universal Remote
Control, Inc.
UNIVERSAL REMOTE CONTROL, INC. SHALL NOT BE LIABLE FOR OPERATIONAL,
TECHNICAL OR EDITORIAL ERRORS/OMISSIONS MADE IN THIS MANUAL.
The information in this owner’s manual may be subject to change without prior
notice.
Complete Control is a registered trademark of Universal Remote Control, Inc.
Entertainment Made Simple is a trademark of Universal Remote Control, Inc.
All other brand or product names are trademarks or registered trademarks of
their respective companies or organizations.
Universal Remote Control, Inc.
500 Mamaroneck Avenue, Harrison, NY 10528
Phone: (914) 835-4484 Fax: (914) 835-4532
TABLE OFCONTENTS
Introduction 1
Custom Labeled Buttons 1
Optional RF “No Rules” Operation 2
Relocating the Wall Bracket 3
Installing Batteries 3
Programming the KP-900i 4
Selecting a New “Activity” 5
Using the KP-900i to Control an “Activity” 6
Displaying the Setup Screen 7
Selecting from the Setup Screen 7
Setting the LCD 8
Light Settings 10
Sound Volume 10
System Settings 11
Version Information Displays 11
Factory Default 12
Limited Warranty Statement 13
End User Agreement 15
Specifications 16
Contact Universal Remote Control 16
Regulatory Information to the user 17
Warning 18
Notes: Your Activities 19
Page 1
KP-900i OWNERS MANUAL
Congratulations!
You’ve purchased a unique wireless control. The KP-900i can be used as both
a wall mounted keypad and as a hand-held remote control. The KP-900i
achieves a magnificent combination of power and flexibility, simplifying and
automating operation of even the most complex home theater system.
Wall Mounted Keypad and Hand-Held Remote Control
Once the wall bracket is securely installed on the wall, simply place the
KP-900i into the bracket. Magnets snap the KP-900i into place. To use as
a hand-held remote control, grasp the KP-900i from the top edge and pull
it away from the bracket.
One Touch Multi-Colored Backlighting
Press any button to backlight the screen and the hard buttons.
Integrated Sound Signaling
The KP-900i incorporates a small speaker for beeps. Anytime you press
a button, the KP-900i signals that it has understood your command with
a beep sound.
Custom Labeled Buttons
The KP-900i is equipped with a bright, easy to read LCD screen which
labels the six buttons to the right of the screen. These button labels change
based on what you are watching or listening to. Thus, if you have selected
Watching TV, you will see a list of buttons that are useful to that activity,
while if you select DVD, the buttons will control the DVD.
Pressing the MAIN button displays
the Main Menu pages of the KP-900i.
When you select one of the activi-
ties listed, the entire functionality of
all the buttons changes to operate
the selected device.
Page 2
KP-900i OWNERS MANUAL
Optional RF “No Rules” Operation
In combination with a Complete Control RF Base Station, the KP-900i can
control your system without being in line-of-sight of the equipment. On the
wall or off, that means that you never need to point the KP-900i.
The MSC-400, the MRF-350i and the MRF-260i RF base stations are compati-
ble with the KP-900i. All incorporate RF addressing. RF addressing gives you
the ability to control equipment locations throughout your home, even if they
are concealed in other rooms or are behind closed doors.
3.The base station routes IR commands to the correct IR
Flasher.
2.The RFX-250i RF Sensor can be freely
positioned for optimal reception.
1.The KP-900i sends radio waves
in every direction, so you don’t
have to point the remote any
more!
4. Self-adhesive “Flashers” affix to the
Infrared sensors on the front panels of your
components. The Flashers relay commands
to components. The flashers plug in to the
base station’s rear flasher line outputs via
their 10 foot cables. Uniquely, URC base
stations can also connect to rear panel IR
Inputs via their adjustable IR Line Outputs.
Page 3
KP-900i OWNERS MANUAL
Relocating the Wall Bracket
A professional installer has the expertise and materials to mount the KP-
900i to any kind of wall material. The KP-900i includes a wall bracket, four
screws and four plastic caps to conceal the screwheads. The included
screws may not be appropriate for your walls.
Before making a hole in your wall, gather the family and evaluate the best
height. Like a thermostat, the KP-900i should be at comfortable eye level
for most of the family, typically between 54” to 62” from the floor to the
top of the bracket (60” is typical).
Use a bubble level and a pencil to draw a line on the wall, then hold the
bracket in place. Screw in the four screws and cover the screw heads with
the included self adhesive caps.
Metal discs in the bracket and magnets in the keypad keep the KP-900i
securely in place, yet make it easy to remove when you need a hand-held
remote control.
Installing Batteries
There are two battery compartments on the rear of the KP-900i. Each
compartment holds two AAA batteries for a total of four AAA batteries.
Open each battery cover by pressing the release and pulling back the
cover on the back of the control. Remove the cover.
Observe the + and - polarity indicators on the batteries.
Place a battery into the compartment with the positive (+) terminal facing
the bottom of the KP-900i. Slide the battery up into the top position and
insert the second battery into place.
Now, replace the battery cover by inserting the hinged end in first, then
snapping the cover back into place.
Repeat the process with the second battery compartment.
Page 4
KP-900i OWNERS MANUAL
Programming the KP-900i
The KP-900i is programmed via a Windows PC equipped with a USB port
(programming cable included), using our proprietary software, KP-900i
Editor and the included programming cable. You can download KP-900i
Editor from our website:
www.universalremote.com
However, to fully automate an audio/video system the programmer must
have a detailed knowledge of each component, you the user (and your
preferences) and how the system is connected and operated. We highly
recommend that you use a professional audio/video installer to program
your KP-900i so you will be able to enjoy all the benefits of the KP-900i
as well as one touch operation via macros.
Page 5
KP-900i OWNERS MANUAL
Selecting a New “Activity”
The KP-900i’s MAIN button displays the activities you can control with
your KP-900i. When you want to listen to the radio or to a CD, touch the
MAIN button and select what you would like to listen to.
Your installer will have programmed the button you pressed to totally con-
figure your system to watch or listen to whatever you selected. Now the
screen will change, and all of the LCD buttons will be reconfigured to
give you full control of your system while watching or listening to your
selection!
Press the PAGE button to see any other available choices.
PAGE DISPLAY
At the bottom of the LCD screen, the
page display informs you if there are
other pages of buttons available.
Optionally, your installer may have
programmed two groups of activities
(i.e Watch and Listen). To access
either group, simply touch the
MAIN button again. The MAIN but-
ton cycles the display from Watch to
Listen, then back to Watch.
When you press the MAIN button,
you can see the most frequently used
activities in your system.
Page 6
KP-900i OWNERS MANUAL
The LCD button
labels describe
special features
for this activity.
Using the KP-900i to Control an “Activity”
Once you’ve selected a new activity, the KP-900i displays the title of the
activity at the top of the screen. Below the title, the LCD displays the cus-
tomized names of any special features you need for the activity. All the
hard buttons of the KP-900i have now changed to functions optimized for
this activity.
The Title displays
what activity you
can control.
Each activity can
have many pages of
LCD labeled but-
tons. At the bottom
of the LCD the
page number is dis-
played.
All of the KP-900i’s hard buttons change their function and now control the selected activity.
Press the PAGE but-
ton to use the other
pages of LCD
labeled buttons.
Page 7
KP-900i OWNERS MANUAL
Displaying the Setup Screen
You can adjust the settings of the KP-900i whenever you like by pressing and
holding both the MAIN and the SELECT buttons at the same time for three
seconds. When you do, the screen will change to the SETUP screen. If you
do not press any button on the SETUP screen within 30 seconds, the KP-900i
will time out and automatically return to normal operation. You can return to
normal operation before that by pressing the MAIN button.
Selecting from the Setup Screen
Simply touch the button for the setting you’d like to adjust:
At the same time, press and
hold both the MAIN button
and the SELECT button.
When the SETUP screen
appears, you can release the
two buttons.
LCD - The appearance of the
screen.
LIGHT - The timing of the LCD
and Button Backlighting
SOUND - The volume of the
beeps.
SYSTEM - The battery low
warning.
VERSION - No adjustments are
possible. Displays factory info.
FACTORY - Erases current con-
figuration permanently and
installs a factory test file.
