UNITED UHC-862 Manual de usuario
CONVECTOR HEATER
USER INSTRUCTIONS
Model: UHC-862
IMPORTANT Read these instructions fully before using the heater.
Retain these instructions for future reference.
ASSEMBLY OF THE HEATER
Before using the heater, the feet (supplied
separately in the carton), must be fitted to the
unit. These are to be attached to the base of
the heater using the 4 screws provided,
taking care to ensure that they are located
correctly in the bottom ends of the heater side
moldings
SAFETY INSTRUCTIONS (to be read before operating the heater)
Do not use the heater unless the feet are correctly attached.
Ensure the power supply to the socket into which the heater is
plugged is in accordance with the rating label on the heater and that
the socket is earthed.
Keep the mains lead away from the hot body of the heater.
Do not use this heater in the immediate surroundings of a bath, a
shower or a swimming pool.
Never place the heater where it may fall into a bathtub or other water
container.
Do not use outdoors.
Do not cover or obstruct any of the heat outlet grilles or the air intake
openings of the heater.
Do not place the heater on carpets having a very deep pile.
Always ensure that the heater is placed on a firm level surface.
Ensure that the heater is not positioned close to curtains or furniture
as this could create a fire hazard.
Do not position the heater in front of, or immediately below, a wall
socket.
Do not insert any object through the heat outlet or air intake grilles of
the heater.
Do not use the heater in areas where flammable liquids are stored or
where flammable fumes may be present.
The appliance is not intended for use by young children or infirm
persons without supervision.
Young children should be supervised to ensure that they do not play
with the appliance.
Always unplug the heater when moving it from one location to
another.
Do not use the heater if the power cord is damaged. If the power
cord is damaged it must be replaced by a recognized service agent or
other qualified person.
The appliance in not intended for use by person (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person responsible
for their safety.
Do not cover. If covered, there is the risk of overheating or even fire.
In order to avoid a hazard due to inadvertent resetting of the thermal
cutout, this appliance must not be supplied through an external
switching device, such as a timer, or connected to a circuit that is
regularly switched on and off by the utility.
-Children of less than 3 years should be kept away unless
continuously supervised.
-Children aged from 3 years and less than 8 years shall only switch
on/off the appliance provided that it has been placed or installed in its
intended normal operating position and they have been given
supervision or instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children aged from 3
years and less than 8 years shall not plug in, regulate and clean the
appliance or perform user maintenance.
-CAUTION- Some parts of this product can become very hot and
cause burns. Particular attention has to be given where children and
vulnerable people are present.
OPERATION OF THE HEATER
NOTE:- It is normal when the heaters are turned on for the first time
or when they are turned on after having not been used for a long
period of time the heaters may emit some smell and fumes. This will
disappear when the heater has been on a short while.
Choose a suitable location for the heater, taking into account the
safety instructions above.
Insert the plug of the heater into a suitable
socket.
Turn THERMOSTAT KNOB fully in a clockwise
direction to the maximum setting.
Turn on the heating elements by means of
HEATER SWITCHES on the side panel. Turn
on the heating elements by means of
HEATER SWITCH on the side panel. You
may obtain three heating settings
(750/1250/2000W) by turning the heater
switch knob in a clockwise direction.
When the desired room temperature has been
reached, the thermostat knob should be turned
slowly anti-clockwise until the thermostat is
heard to click off and the lights on the element
switches are seen to go out. After this the heater will keep the air
temperature in the room at the set level by switching on and off
automatically.
PROTECTION AGAINST OVERHEATING
− An additional fitted safety thermostat protects the heater against
overheating and switches it off automatically. The service lamp
then goes out.
− If the device switches itself off, disconnect the mains plug from
the socket. The heater is ready for service again after a short
cooling-off phase (approx.15 minutes). Plug the mains plug
back into the socket.
− If this repeats itself, first check whether the thermostat switch is
set correctly or if objects hinder the heating operation.
CLEANING THE HEATER
Always un-plug the heater from the wall socket and allow it to cool
down before cleaning.
Clean the outside of the heater by wiping with a damp cloth and buff
with a dry cloth. Do not use any detergents or abrasives and do not
allow any water to enter the heater.
STORING THE HEATER
When the heater is not used for long periods of time, it should be
protected from dust and stored in a clean dry place.
Note: this appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or lack
of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a person
responsible for their safety.
Children should be supervised to ensure that they do not play with the
appliance.
When replacing old appliances with new ones, the retailer is legally
obligated to take back your old appliance for disposals at least free of
charge.
NOTICE ABOUT RECYCLING
Your product is designed and manufactured with
high quality materials and components which can
be recycled and reused.
This symbol means that electrical and electronic
equipment, at their end-of-life,
should be disposed of separately from your
household waste. Please dispose of this equipment at
your local community waste collection/ recycling centre.
In the European Union there are separate collection systems for used
electrical and electronic products.
Please help us to conserve the environment we live in!
DECLARATION OF CONFORMITY
Herewith, Amiridis-Savvidis S.A. states that this product, complies
with the requirements of below directives:
EMC-Directive: 14 / 30 / EU
Low Voltage Directive: 14/ 35 / EU
CE Marking: 93 / 68 / EEC
RoHS Directive: 11 / 65 / EU
The detailed declaration of conformity can be found at
www.united-electronics.gr
Exclusive importer in Greece:
Amiridis – Savvidis S.A.
87A, 17th Noemvriou str, P.C. 55534
Thessaloniki – Greece
T: +302310944944 | F: +302310944940
www.amiridis-savvidis.gr
