Unitech User Manual

More information available at POSMicro.com

Unitech Electronics Co., Ltd

Created

by Yukiko PA960 Operation

Manual V2.3 Page 1 of 144

PA960 Operation Manual

Author: Yukiko Goh

Date Created: 10 November, 2003

Last Update: 29 June 2004

Unitech Electronics Co., Ltd

Created

by Yukiko PA960 Operation

Manual V2.3 Page 2 of 144

Table of Contents

Chapter 1 Introduction 5

Chapter 2 Unitech’s Application 6

2.1 Bootmode 6

2.2 Chatter 8

2.3 DeviceInfo 11

2.4 Flash Manager 12

2.5 GetVK 14

2.6 I/O Card Control 14

2.7 KeyTracARM 17

2.8 Scan2Key 18

2.9 UniPing 20

2.10 Scanner Settings 22

2.11 Virtual Keys 36

2.12 RegFuncKey 38

Chapter 3 Tools and Applications under “Windows” 41

3.1 ActiveNet 41

3.2 Aironet Client Utility 45

3.3 Calibration 48

3.4 MS DOS Prompt Command 49

3.5 Load New Firmware 51

3.6 MSTSC 52

3.7 Net 54

3.8 NICTT 56

3.9 NICUPDATE 60

3.10 Pegterm 61

3.11 pmail 65

3.12 pvbload 68

3.13 pword 68

3.14 rapisrv 68

3.15 rasdemo 69

3.16 repllog 69

3.17 Taskman 71

3.18 visadm 72

Unitech Electronics Co., Ltd

Created

by Yukiko PA960 Operation

Manual V2.3 Page 3 of 144

3.19 wceload 74

3.20 WMAGS46 74

Chapter 4 Control Panel 83

4.1 Communications 83

4.2 Date/Time 86

4.3 Display 87

4.4 Input Panel 89

4.5 Keyboard 92

4.6 Mouse 94

4.7 Network Configuration 95

4.8 Owner 97

4.9 Password 99

4.10 Power 100

4.11 Regional Settings 102

4.12 Stylus 105

4.13 System 106

4.14 Volume & Sounds 108

Chapter 5 Available Function Keys 111

5.1 Func + Esc 111

5.2 Func + Up Arrow 112

5.3 Func + Down Arrow 112

5.4 Func + TAB 112

5.5 Func + 6 113

5.6 Func + 7 113

5.7 Func + 8 114

5.8 Func + 9 115

Chapter 6 OtherApplications 116

6.1 Remote Networking 116

Chapter 7 RF Connection, GPRS and Bluetooth 121

7.1 RF Connection – Cisco Aironet 121

7.2 RF Connection – Lucent Orinoco (Agere System) 124

7.3 RF Connection -- Symbol 126

7.4 RF Connection – Built in RF card model 126

7.5 GPRS – Sierra Wireless Aircard750 138

Unitech Electronics Co., Ltd

Created

by Yukiko PA960 Operation

Manual V2.3 Page 4 of 144

7.6 GPRS – Option Globe Trotter 132

7.7 Bluetooth -- Socket 139

Unitech Electronics Co., Ltd

Created

by Yukiko PA960 Operation

Manual V2.3 Page 5 of 144

Chapter 1 Introduction

This operation manual aims at instructions of using Unitech’s applications, some

useful application programs under “Windows” folder, setting application under

“Control Panels” and available function keys in WinCE 3.0 OS.

* Based on Firmware Version: V2.01.08

Unitech Electronics Co., Ltd

Created

by Yukiko PA960 Operation

Manual V2.3 Page 6 of 144

Chapter 2 Unitech’s Application

This chapter introduces some Unitech’s made applications which are embedded in the

firmware. These applications offer additional facilities and usage to the user besides

standard WinCE applications.

Unitech’s Made Applications

1. Bootmode

2. Chatter

3. DeviceInfo

4. Flash Manager

5. GetVK

6. I/O Card Control

7. KeyTracARM

8. Scan2Key

9. UniPing

10. Scanner Setting

11. Virtual Keys

12. RegFuncKey

2.1 Bootmode

Path: My computer/Windows/Bootmode.exe

This tool allows you to perform warm boot or update OS when it is necessary.

Warm Boot

1. Double tap “Bootmode”.

Unitech Electronics Co., Ltd

Created

by Yukiko PA960 Operation

Manual V2.3 Page 7 of 144

2. Tap “Warm Boot”. The system will be restart.

Note: If you press and hold “Å” key then tap “Warm Boot”, the terminal will be

cold started. (Caution: Please backup any important data before you perform

cold start)

Update OS

1. Double tap “Bootmode”. Tap “Update OS”.

Unitech Electronics Co., Ltd

Created

by Yukiko PA960 Operation

Manual V2.3 Page 8 of 144

2. Update OS window pops up. The registry will be restored to default. Proceed

anyway? Tap “Yes”.

3. System will be restarted and enter bootloader screen. Insert your CF card with OS

image file. Select “2” to update OS.

2.2 Chatter

Path: My computer/Windows/Chatter.exe

This tool allows you to capture and scan barcode automatically in a time interval and

at the same time, send the scanned data to your host by wireless network connection.

1. Insert the wireless network card into your terminal and make the setting.

2. Install Chat Server program in your PC/notebook. (You can get this program from

Unitech)

3. After install, double click the chat server in your PC/notebook. Set the channel.

(Default is 0), click “OK”.

Unitech Electronics Co., Ltd

Created

by Yukiko PA960 Operation

Manual V2.3 Page 9 of 144

4. Double tap “Chatter” on your terminal.

5. In Chatter Setup, under “Handle”, enter a name.

6. Under “Server”, enter the IP address of your host.

7. Under “Channel”, enter the channel (This channel must be the same as the chat

server’s channel)

8. Tap “OK”.
