PA690 Rugged Mobile Computer
- PA690 -
Quick Reference Guide
400853G Version 1.0
Copyright 2011 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd.
Copyright 2011 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd.
English Deutsch Español Français
中文(简体) 中文(繁體) 日本語 영어
PA690 Product Introduction & Accessory Kit
PA690 Terminal Manual CD
Stylus Battery
Elastic Stylus String Hand Strap
Power Adaptor Plugs
Copyright 2011 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd.
English Deutsch Español Français
中文(简体) 中文(繁體) 日本語 영어
PA690 Front and Right View
1 LED indicators 7 Power button
2 LCD touch screen 8 Universal connector
3A Microphone
3B Reset button 9 Scanner trigger button
4 Receiver 10 Mute button
5 Reset button 11 Camera button
6 Keypad 12 Memory card slot
Turning ON the PA690 for the First Time
After you have initially charged your device for about 16 hours, the device is
ready to be used. You can now start up your device where you’ll calibrate the
display, learn some basic stylus usage, and set up the system time zone,
date and time.
Powering-On Button
Turn ON your device by pressing the power button on the front panel.
4
1
2
3A
5
6
7
9
10
11
12
8
3B
Copyright 2011 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd.
English Deutsch Español Français
中文(简体) 中文(繁體) 日本語 영어
PA690 Rear and Left View
1 Barcode scanner window 7 Speaker
2 Headphone jack 8 5M/AF camera
3 Microphone 9 LED flash light
4 Battery compartment 10 Battery compartment tab
5 Antenna 11 Scanner trigger button
6 Stylus 12 Volume up/down
Installing the Battery
1. Open the battery compartment
cover by sliding the tabs on both
sides in the direction of the arrows
shown and lift the cover up.
Battery
Compartment
Tab
1
2
3
4
5
6
7
8
9
10
11
12
Copyright 2011 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd.
English Deutsch Español Français
中文(简体) 中文(繁體) 日本語 영어
2. Push up the backup battery switch
to the “ON position by using a
stylus to turn on the backup
battery.
3. Slide and position the battery
pack, making sure the battery
contacts are aligned with the
contacts in the compartment.
4. Pull the plastic tab until the battery
is placed in place.
5. Replace the battery compartment
cover, push down the tabs and
slide them back into place as
shown.
NOTE: Make sure the battery compartment cover is securely closed, or you
may be unable to turn ON the terminal.
Charging the Battery
CAUTION: Turn ON the backup battery switch before charging the battery.
Data you entered may not be properly stored until the built-in
backup battery has been adequately charged.
1. Press and hold the release button on both sides of the USB charging
cable and connect it to PA690 (1).
2. Plug the AC adapter cable into the power jack of the USB charging cable
(2).
Backup
Battery
Switch
Battery
Compartment
Contacts
Plastic Tab
Copyright 2011 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd.
English Deutsch Español Français
中文(简体) 中文(繁體) 日本語 영어
3. Plug the AC adapter cord into an electrical outlet (3).
Using the MicroSD memory card
1. Remove the two screws on the
MicroSD slot shield and remove
the shield.
2. Insert the MicroSD card with the notched corner
as shown.
Using the SIM card
The PA690 has a slot for GPRS SIM card inside the battery compartment.
CAUTION: Before installing the SIM card, please backup your data to
prevent data loss because of a low backup battery.
1. Remove the battery compartment cover and the main battery.
2. Slide the cover of the SIM card slot to the right to
release the latch.
Copyright 2011 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd.
English Deutsch Español Français
中文(简体) 中文(繁體) 日本語 영어
3. Pull open the cover with thumb.
4. Insert the SIM card into the cover with notched
corner up, and the contact side of SIM card faces
down.
5. Press down the cover on the slot, and then slide
the cover to the left to lock the SIM card.
6. Put the battery back into the battery compartment and replace the
battery compartment cover.
Keypads and Function Buttons
Numeric Keyboard Qwerty Keyboard
Key Description Key Description
Power key Escape key
Enter key Backspace key
Tab key Function key
Copyright 2011 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd.
English Deutsch Español Français
中文(简体) 中文(繁體) 日本語 영어
Key Description Key Description
Alpha key, toggle
between numeric and
alphabetic entry modes Windows key
~ Alphanumeric keys Hang-off key
Answer key Left cursor key
Right cursor key Up cursor key
Down cursor key
When PA690 boots, the default condition is Numeric Mode on. When you
toggle to Alpha Mode, the default condition is CAPS mode off. Please use the
alpha Key to toggle to CAPS.
Using Function keys
For Qwerty Keyboard
Key Description Key Description
+ Keypad backlight
toggling + Screen backlight
toggling
+Screen backlight
brightness decrease + Screen backlight
brightness increase
+ Softkey 2 + Softkey 1
+ END TALK + TALK
+ Scanner setting + Task manager execution
+ Device information + Power management
For Numeric Keyboard
Key Description Key Description
+ Calibration + Screen backlight toggling
+ Keypad backlight
toggling + Power management
+ Device information + Softkey 1
Copyright 2011 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd.
English Deutsch Español Français
中文(简体) 中文(繁體) 日本語 영어
Key Description Key Description
+ Softkey 2 + Screen backlight
brightness decrease
+ Screen backlight
brightness increase + TALK
+ END TALK + Task manager execution
+ Scanner setting
Using Alpha keys Alpha On
Key Alpha Off CAPS Off CAPS On
0 Space, @, $, “, 0 Space, @, $, “, 0
1 +, -, \, %, 1 +, -, \, %, 1
2 a, b, c, 2 A, B, C, 2
3 d, e, f, 3 D, E, F, 3
4 g, h, i, 4 G, H, I, 4
5 j, k, l, 5 J, K, L, 5
6 m, n, o, 6 M, N, O, 6
7 p, q, r, 7 P, Q, R, 7
8 t, u, v, 8 T, U, V, 8
9 w, x, y, z, 9 W, X, Y, Z, 9
# , ; ! . / , ; ! . /
