Unitech PT600 Manual de usuario

USER’S GUIDE

PORTABLE DATA COLLECTION

TERMINAL

PT600

DOCUMENT NUMBER: 350600-0010

NOTICE

The unit is equipped with a NiMH

battery pack, however it may not

be powered on due to

discharging of the battery by

putting in storage for a period of

time.

In the case of above situation

happened, plug in an 9V AC-DC

adapter and recharge the NiMH

battery pack about 14~16 hours

or put into cradle about 2.5 hours

with 12V AC-DC adapter before

using the unit. (please refer to

chapter 2.4 for charging

reference)

Table of Content

Page

Chapter 1 Introduction.......................................... 1

1.1 Technical Specification................................ 2

1.2 Interface Ports ............................................. 8

1.3 Using the Keyboard ..................................... 9

1.4 Triggering Scanner Module.......................... 11

1.5 Application Development Environment........ 12

1.6 Optional Charging/Communication Cradle... 13

Chapter 2 Power System....................................... 14

2.1 Power Supply...............................................14

2.2 Power Low Indication...................................14

2.3 Battery Replacement ...................................15

2.4 Recharging the Battery Pack.......................17

2.5 Storage and Safety Precautions..................18

Chapter 3 Operation.............................................. 19

3.1 Ready Mode.................................................19

3.2 User Mode and System Commands ............20

3.3 Configure the Terminal in SET command....22

3.4 Upload/Download by ESC command...........24

Chapter 4 Built-in Application:FormCaching...... 25

4.1 Specification of FormCaching......................25

4.2 How to Create a FormCaching.....................26

4.3 How to Run FormCaching............................26

4.4 Default Settings of FormCaching.................27

-1-

Chapter 1 Introduction

The PT600 Portable Data Terminal, referred as PDT hereafter, with

integrated laser scanner or pen scanner is a rugged, compact and

lightweight hand-held data collection terminal with good reliability,

flexibility and maintainability. Its compact size and form makes it even

fits in your packet. The PDT incorporates a DOS-based system and

provides users a PC compatible environment to develop and use the

device. This terminal is well suited for transportation, warehouse

distribution, retail management, asset tracking and many other data

collection applications.

Top View Right side View Back View

Bottom View

-2-

1.1 Technical Specification

SOFTWARE PROGRAMMING TOOLS

Language Assembly, C language (MSC, Turbo C, Visual C)

JobGen Plus A Windows-based transaction program generator

JobGen Pro A Dos-based transaction program generator

FormCaching A built-in program generator

CPU/MEMORY

CPU 16-bit 8088 compatible microprocessor CPU

Memory 512KB to up of 4.5MB SRAM

Flash ROM 256K with DOS-based system

Keyboard 26 alphanumeric rubber keys with one laser trigger

switch

Buzzer Volume adjustable by software

Real time clock System date and time

Display 100x65 pixel graphic backlit LCD with selection

between 12-column by 4-line in 8x16 font and 16-

column by 8-line in 6x8 font by menu setup or system

call

BARCODE SYMBOLOGY

Barcode reading UPC-A/E, EAN-8/13, Codabar, Code128, Code39,

Code39 with full ASCII, ITF, China postal code,

Interleave 2 of 5, EAN128

PHYSICAL AND ENVIRONMENT

Dimensions 176mm(L) x 52mm/62mm(W) x 27mm/35mm(H)

Weight Approximately 240g with battery pack

Temperature Operation: 0°C ~ 50°C (32°F ~ 122°F)

Storage: -20°C ~ 70°C (-4°F ~ 158°F)

Humidity 4 ~ 95% RH non-condensing

-3-

COMMUNICATION

Interface One EIA RS232C with miniature DIN-9p male

connector, Support TX/RX, CTS/RTS, GND,

up to 57.6Kbps (default value is 19.2 Kbps)

One IR port, Support TX/RX, from 19.2 to 57.6 Kbps

Handshaking Xon/Xoff or CTS/RTS

Protocol None or Multi-protocol

File Transfer Build-in Kermit server or Multi-protocol

POWER SUPPLY

Operation 2AA size NiMH @ 1.2V, 1500mah

Both of them are store in detachable battery pack

Backup One lithium CR2032 backup battery

Power manager Low power consumption and warning on power low for

operating/backup battery

Power input AC/DC adapter @ 9VDC/500mA

DOCKING STATION

Interface One serial infrared interface for data communication via

PT600

One RS485 port for RS485 multiple stations

networking

One RS232 port for point-to-point communication to

host computer

Power charging Soft-contact charging pads to main unit and spare

battery

Quick charging for typical 2.5 hours

Power input AC/DC adapter @ 12VDC/1A

Operation System

•MS-DOS compatible system

•Reads all major bar code symbologies auto-

discriminated

•Menu-driven user configuration interface

•Software adjustable beeper volume and LCD

contrast

•System resumes from the last turn-off point.

-4-

•Built-in power-on self test and diagnostic program

•Host command remote control

Integrated Laser Diode Scanner

•Scan rate 36 scans/sec

•Skew Tolerance ±65°from normal

•Pitch Angle ±55°of normal

•Power consumption 60mA typ.@5V

Integrated clip-on Pen Scanner

•Resolution 0.12mm(5mil)

•Dept of field 0.1mm(0.04inch)

•Scan rate 5-200 cm/sec

•Reading Angle 45°~ 135°

•Print Contrast Ratio 0.5 min

Diagram shown with a Built-in Integrated Laser scanner

65°

Barcode

Label

Scan Beam

55°

Barcode

Label

Scan Beam

Pitch Angle

Skew Tolerance

Top view of PDT Right side view of PDT

-5-

Depth of Field diagram

-6-

-7-

Diagram shown with a clip-on pen scanner

45° 45°
