HT580 User Reference Guide

Version 1.0

HT580 User Reference Guide Unitech Electronic CO. LTD

NOTICE

1. Li-Ion Battery Pack

The HT580 Portable Terminal and the Li-Ion Battery Pack are packaged separately.

You will have to install the Battery Pack when you receive your terminal. Please

ensure that the Li-Ion Battery Pack is properly installed and fully charged prior to

initial use of the HT580.

2. USB Driver Installation

The HT580’s USB driver is located on the CD included in this package. To activate

USB, please install the driver rst.

HT580 User Reference Guide Unitech Electronic CO. LTD

Content

Chapter 1: Introduction

1.1 Overview....................................................... 4

1.2 Support........................................................ 4

1.3 Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

1.4 Technical Specications .......................................... 5

1.5 Product Illustration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

1.6 Battery Storage & Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

1.7 CommunicationCradle ........................................... 8

1.8 HT580 Communication with the Host . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

1.9 InterfacePort ................................................... 9

1.10 Pin Assignment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

1.11 Keypad. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

1.12 BarcodeScanningSpetrum ...................................... 10

Chapter 2: Operating the HT580

2.1 SettingSystem................................................. 11

2.1.1 DATE & TIME. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

2.1.2 DEVICE ....................................................... 11

2.1.3 MODEMINIT ................................................... 12

2.1.4 SUPERVISOR .................................................. 12

2.2 FORMCACHING ................................................ 12

2.3 RUN APG580 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

HT580 User Reference Guide Unitech Electronic CO. LTD

Chapter 1: Introduction

1.1 Overview

Thank you for choosing the HT580 from Unitech Electronic Co. Ltd. This Portable Data Collection

Terminal is one of the most user-friendly handheld terminals on the market - perfect for small retailers.

Developed under the C language, the HT580’s proprietary Operating System is capable of helping

you develop and run application programs specically designed by you for your own unique business.

Weighing only 150g (5.3 oz), the light weight of the HT580 is ideal for the long work days typical in a

retail environment. Despite its light weight, the HT580 is unusually robust - capable of sustaining 1.2

meter (4 foot) drops to a concrete oor.

We believe the HT580 will more than satisfy your own unique retail requirements. The HT580 stan-

dard package includes the HT580 terminal, communication cradle, adaptor, USB & RS232 Y cable,

holster, and strap. Additionally, two alternative types of communication/charging cradles - RS232 and

Modem - are offered as options.

1.2 Support

Unitech has professional support teams around the world to answer your questions or any related

technical issues. Should equipment problems occur, please contact one of our regional service centers

for a quick response. Our six regional service centers and their contact information can be found on

the websites provided below:

UTC (China) http://www.ute.com.cn

APAC (Taipei, Taiwan) http://www.unitech-adc.com

UTJ (Japan) http://www.unitech-japan.co.jp

UTA (North and South America) http://www.unitech-adc.com

UTI (Netherlands, UK) http://www.unitech-europe.nl

HT580 User Reference Guide Unitech Electronic CO. LTD

Model HT580

Dimensions 123mm x 55mm x 25mm (4.8” x 2.2” x 1.0”)

Weight 150g (5.3 oz)

Drop Specication 1.2M (4 foot) free drop to concrete oor

Display 128 x 64 pixels; 16 x 8 characters or 12 x 4 characters

Battery One 3.7V 600mAH Li-Ion battery

Environmental Sealing IP42

Operation Temperature 0°~50°C (32°~122° F)

Storage Temperature -20°~70°C (-4°~158° F)

Humidity 5% to 95% RH; not condensed

Electrostatic Discharge (ESD) 4 KV contact discharge

8 KV air discharge

Back-Lit Display Yes

Keypad 18 alphanumeric keys including one scan trigger

CPU ST UPSD3354DV

Operating System Proprietary (C Language)

Memory 1 MB for main program and data storage

Application Development EZ Job

Communication RS232 / USB1.1 / Bluetooth / Modem

Battery Life Up to 8 hours

Symbologies China Postal Code, Codabar, Code 32, Code 39, Code 93, Code

128, Interleaved 2 of 5, MSI, UPC/EAN

Buzzer Yes, over 75 dB

One LED Reading (green color)

1.3 Features

HT580 includes the following features:

Operating System: Proprietary

Memory: 1MB

Display: 128 x 64 pixels

Keypad: 18-key keypad

Data Capture: CCD

Communication: Bluetooth / RS232 / USB

1.4 Technical Specications

HT580 User Reference Guide Unitech Electronic CO. LTD

1.5 Product Illustrations

This section is designed to familiarize you with the HT580 and its cradle. For detailed explanations

on some of the functions, please refer to subsequent chapters.

Figure 1: HT580 Front View Figure 2: HT580 Back View

Figure 3: HT580 Top View Figure 4: HT580 Bottom View

Figure 5: HT580 Battery Position

Figure 6: HT580Charging/Communication

Cradle, Featuring 2 Types of Communication:

RS232 and modem

Figure 7: Modem Cradle Back View Figure 8: RS232 Cradle Back View

HT580 User Reference Guide Unitech Electronic CO. LTD

Figure 9: HT580 Communication/Charging Cable Figure 10: HT580 Li-Ion Battery

1.6 Battery Storage and Safety Precautions

Batteries should be stored at normal room temperature. Avoid placing them in any situation where ex-

plosion or damage could possibly occur. The Li-Ion batteries may lose their charge if not used for sever-

al months due to back up and internal resistance. If this happens, we suggest recharging prior to use.

Remove Main Battery

To remove the main battery, press down on the release button while pushing out the cover on the unit.

We suggest that the battery not be removed, if possible.

Charging

When starting to operate the HT580, the main battery must be fully charged before the rst use. The

HT580 is equipped with a 3.7V 600mAH Lithium-Ion battery. It takes 8 hours to fully charge the main

battery when empty. We suggest users recharge the battery regularly after long hours of use.

This icon shown in the menu indicates the current battery capacity status.

There are 2 ways to charge the main battery:

1. Mount the unit in the cradle and connect the power adaptor between the back of the cradle and

any power outlet.

2. Or, use the standard USB cable and connect it to your PC’s USB port.

Top

Bottom

HT580 User Reference Guide Unitech Electronic CO. LTD

1.7 Communication Cradle

The HT580’s battery can be charged by placing the HT580 into its charging/communication cradle -

part number: 5000-601558 (RS232) / 5000-601557 (Modem)

Positioning Terminal Into Cradle

1. Figure A - Proper Position

Front View

2. Figure B - Improper Position

Figure A shows the proper way to insert

your terminal while using the cradle to

transmit data or to charge.

Please note that the connector in the

bottom of the cradle may be damaged

if you use excessive force to insert the

terminal.

Figure B shows the improper way to

insert the terminal into the cradle.

Do not insert the terminal into the cradle

incorrectly. It will not function properly

and damage can occur.

Back View

HT580 User Reference Guide Unitech Electronic CO. LTD

Communication Cradle LED Icons

This LED light (Red) shows the power status of the cradle itself. An Illuminated light indicates

the cradle is charging. To identify if the terminal is fully charged, it may be necessary to check the

terminal LCD.

1.9 Interface Port

The HT580 communicates via the RS232 communication port located on the bottom of the unit.

You can connect the HT580 directly via the communication cable to your PC’s RS232 port for data

transfer, or connect via the cradle.

1.10 Pin Assignment

1.8 HT580 Communication with the Host

Pin Name Pin Name

1 US-POWER 7 DSR

2GND 8GND

3DC-IN 9 DTR

4 USB DP 10 TXD

5 CTS 11 RXD

6RTS 12 USB DP

USB client 1.1 connection through cable

RS232/Modem Cradle Communication

This LED light (Green) shows transmission status of the cradle itself. An Illuminated light indicates

that data is in transmission.

HT580 User Reference Guide Unitech Electronic CO. LTD

1.11 Keypad

The HT580 keypad consists of 18 rubber keys and one power key; the keypad is congured into three different

modes: Numeric mode, Command mode, and Alphabetic mode.

The keypad is congured in Numeric mode by default, Command mode when the light green CMD key is

selected, or Alphabetic mode when the blue ALPHA key is selected.

Keypad Description

[ ] To power on the unit press the power key.

The power key is on top right corner of the cover.

[ESC] Returns you back to the previous menu.

[MENU] Press [MENU] to scroll items you require.

[SCAN] Press [SCAN] to trigger scanning function or to perform

as the [ENTER] key while in [SETTING] mode.

[C] Press [C] to delete.

[ENTER] Press [ENTER] to save changes or to go to the next page.

[ALPHA] Press [ALPHA] to switch to Alphabet.

Any alphabetical character (printed in blue) can be activated with the ALPHA key.

[CMD] Press [CMD] to perform delimiters such as “#”, “$” etc.

Any delimiter (printed in green) can be activated with the CMD key.

1.12 Barcode Scanning Spectrum
