Unitech MS120 Manual de usuario

Contents

Setup Procedures …………… 2

Batch Setup …………… 3

Bar Code Setup Menu …………… 4

1 Device Selection and Default

…………… 4

2 Beep and Delay …………… 6

3 Keyboard Wedge …………… 8

4 RS232 Serial Setting …. 10

5 Scanner ………….. 12

6 Data Format ………..… 14

7 Symbologies(I): Code 39/I2 of 5/

S2 of 5/Delta Distance

Code/Code 32 ..………… 16

8 Symbologies(II): Code 128 /

MSI / Code 93 / Codabar /Label

Code ………….. 18

9 Symbologies(III): UPC/EAN

………….. 20

Function Code for PC .… 22

Function Code for MAC …. 24

Function Code for IBM Terminal

………..… 26

Full ASCII Table ………….. 28

Test Chart …………………... 34

Setup Procedures

1) Locate a group that contains the

parameters to be changed.

2) Scan the “Enter Group” label. The

Reader will sound 3 beeps to indicate

that setup is in progress.

3) Scan the label representing the

parameter to be changed.

4) Scan the labels representing the

parameter values.

5) Repeat the above two steps, if

necessary, to change the parameters in

the same group.

6) Scan the “Exit” label to end the

group currently selected. The Reader

will sound 2 beeps.

7) Repeat the procedure for other

groups, if needed, which include the

parameters to be changed.

Batch Setup

Having configured a scanner, you may

duplicate the settings of the scanner

(master) to the others. You can do this

by producing a set of custom setup

labels derived from the master scanner

and scanning these labels by other

scanners.

The following label is called “dump

settings” label. Scan that label, the

settings of a scanner will dump to the

screen as one or several ASCII

string(s). Printing the string(s) into bar

code labels in Code 39, you get the

batch setup labels to duplicate other

scanner.

Dump Settings

Bar Code Setup Menu

1 Device Selection and Default

Enter Group 1

Group Default

Factory Default

Exit

Keyboard Wedge Reader

Device

ID Device Type

00 IBM PC/XT

01 IBM PC/AT, PS/2 mod 40, 60,

80 etc.

02 IBM PS/2 MOD 25, 56, 70, 90

19 IBM 5550-5P

20 IBM 5550-6P

08 IBM 3196/3197 122 Keys

10 IBM 3476/3477 122 Keys

09 IBM 3179/3471/3472

11 IBM 3486/3487

06 Keyboardless Wedge

03 Macintosh ADB bus

RS-232 Reader

Device

ID Device Type

04 RS232 Serial Decoder

Wand Emulation Reader

Device

ID Device Type

05 Wand Emulation (Native Mode)

07 Wand Emulation (Code 39 Mode)

2 Beep and Delay

Enter Group 2

Group Default

F5 (%VE)

Exit

Beep Tone

(On Decoding): A1

0None 3High

1Low 4Low to High

2Medium 5High to Low

Beep Tone

(On ACK): A2

0None 3High

1Low 4Low to High

2Medium 5High to Low

Inter-Character

Delay: A3

01 ms 320 ms

15 ms 450 ms

210 ms 5100 ms

Inter-Block Delay:

010 ms 3500 ms

150 ms 41 second

2100 ms 55 seconds

3 Keyboard Wedge

Enter Group 3

Group Default

Review

Exit

Function Code:

0Off 1On

Upper/Lower

Case: B2

0Lower Case 1Upper Case

Function Code:

0US

1UK

2Swiss

3Swedish

4Spanish

5Norwegian

6Italian

7German

8French

9Alt Key Mode

4 RS232 Serial Setting

Enter Group 4

Group Default

Review

Exit
