Uniden App Cam 4K Bullet-S Manual de usuario

App Cam 4K

Bullet-S

Quick Start Guide

What’s in the Box

Screw Kit

1m Ethernet CableApp Cam 4K Bullet-S

Weatherproof Lid

Quick Start Guide

Mounting Template

General Introduction

NOTE:

out the camera included in the package and check out the details from

the correpsonding introduction above.

model of product.

NOTE:

out the camera included in the package and check out the details from

the correpsonding introduction above.

model of product.

Mount

Metal Case

Infrared Lights

Lens

Spotlight

Built-in Mic

Weatherproof Lid

Ethernet Port

Reset Button

Power Port (Optional)

* Press and hold for 10 seconds to restore the

camera to factory settings

Camera Connection

Before using the camera, please connect the camera to App Cam 4K NVR.

Connection Diagram

DC4 8V

AUDI O

OUTUSBHDMI VGA LAN

eSATA

3 5 7

4 6 8

11 13 1 5

12 14 1 6

ONOFFReset Button

DC Power

Network (LAN)

Note:

The camera should be powered with a Uniden App Cam 4K NVR (not included in the package).

Please set up the camera via the NVR interface.

Mount the Camera

Installation Tips

• Do not face the camera towards any light sources.

• Do not point the camera towards a glass window. Or, it may result in poor image quality

because of the window glare by infrared LEDs, ambient lights or status lights.

• Do not place the camera in a shaded area and point it towards a well-lit area. Or, it may

result in poor image quality. To ensure best image quality, the lighting condition for both

the camera and the capture object shall be the same.

• To ensure better image quality, it’s recommended to clean the lens with a soft cloth from

time to time.

• Make sure the power ports are not directly exposed to water or moisture and not blocked

by dirt or other elements.

• With IP weatherproof ratings, the camera can work properly under conditions like rain

and snow. However, it doesn’t mean the camera can work underwater.

• Do not install the camera at places where rain and snow can hit the lens directly.

Step 1

Drill holes in accordance with the

mounting hole template.

NOTE: Use the drywall anchors

included in the package if needed.

Installation Tips

Step 2

Install the mount base with the

mounting screws included in

the package.

NOTE: Run the cable through the

cable notch on the mount base.

Step 3

To get the best eld of view,

loosen the adjustment knob

on security mount and turn

the camera.

Step 4

Stiffen the adjustment knob to

lock the camera.

Camera is not turning on

If your camera is not powering on, please try the following solutions:

• Make sure your camera is powered properly. The camera should be powered by the Uniden App Cam 4K NVR

or a 12V power adapter.

• If the camera is connected to a PoE device as listed above, connect the camera to another PoE port and see

if the camera will power on.

• Try again with another Ethernet cable.

Infrared LEDs Stop Working

If the Infrared LEDs of your camera stop working, please try the following solutions:

• Enable infrared lights on Device Settings page via Uniden Solo App.

• Check if the Day/Night mode is enabled and set up auto infrared lights at night on Live View page via Uniden

Solo App.

• Upgrade the rmware of your camera to the latest version.

• Restore the camera to factory settings and check out the infrared light settings again.

Spotlight is not ON

If the spotlight on the camera is not on, please try the following solutions:

• Turn on the spotlight on the App Cam 4K NVR.

•• Restore the camera to factory settings and check out the spotlight settings via App CamK NVR again.

Troubleshooting

Video & Audio

Model App Cam 4K Bullet-S

Image Sensor 1/2.8” CMOS Sensor

Video Resolution up to 3840x2160 (8MP) 4K up to 25 fps

Video Compression H.265

Viewing Angle Horizontal: 87° Vertical: 44°

Night Vision Up to 30 Meters

Audio Two-way talk

Alerts Person detection; vehicle detection; motion detection

Network Ethernet One 10M/100Mbps; RJ45

Hardware

Spotlight 6500K/450 lumens

PoE IEEE 802.3af

DC Power Can be powerd by 12V/1A power adaptor

Storage Supports up to 256GB micro SD card, min class 10*

Other

Parameters

Temperature Operating Temperature : -10°C~+55°C

Operating Humidity 10% to 90%

Waterproof Level IP66 Weatherproof

Specications

*Note: When the camera is connected to the NVR, the SD Card storage option is not supported on the App

and the NVR itself. Only supports recording to fat32 SD Card when setup as a standalone camera.

Uniden App Cam 4K Bullet

Terms of Warranty: Uniden Aust warrants to the original retail purchaser only that the Uniden App Cam 4K Bullet

(“the Product”), will be free from defects in materials and craftsmanship for the duration of the warranty period,

subject to the limitations and exclusions set out below.

Warranty Period: This warranty to the original retail purchaser is only valid in the original country of purchase for a

Product first purchased either in Australia or New Zealand and will expire, as indicated below, from the date of original

retail sale.

Product 1 Year

Accessories 90 Days

If a warranty claim is made, this warranty will not apply if the Product is found by Uniden to be:

A. Damaged or not maintained in a reasonable manner or as recommended in the relevant Owner’s Manual;

B. Modified, altered or used as part of any conversion kits, subassemblies or any configurations not sold by Uniden

Aust;

C. Improperly installed contrary to instructions contained in the relevant Owner’s Manual

D. Repaired by someone other than an authorized Uniden Repair Agent in relation to a defect or malfunction

covered by this warranty; or

E. Used in conjunction with any equipment, parts or a system not manufactured by Uniden.

Important:

Satisfactory evidence of the original purchase is required for warranty service. Please refer to our Uniden

website for any details or warranty durations offered in addition to those contained below.

Warrantor:

The warrantor is Uniden Australia Pty Limited ABN 58 001 865 498 (“Uniden Aust”).

WARRANTY
