UNICORECOMM UM960 Manual de usuario

UM960 User Manual

WWW.UNICORECOMM.COM

Data subject to change without notice.

UM960

GPS/BDS/GLONASS/Galileo/QZSS

All-constellation Multi-frequency

High Precision RTK Positioning Module

INSTALLATION AND OPERATION

USER MANUAL

UM960 User Manual

Revision History

Version

Revision History

Date

R1.0

First release

Sep., 2022

Legal Right Notice

This manual provides information and details on the products of Unicore Communication, Inc.

(“Unicore”) referred to herein.

All rights, title and interest to this document and the information such as data, designs, layouts

contained in this manual are fully reserved, including but not limited to the copyrights, patents,

trademarks and other proprietary rights as relevant governing laws may grant, and such rights

may evolve and be approved, registered or granted from the whole information aforesaid or any

part(s) of it or any combination of those parts.

Unicore holds the trademarks of “和芯星通”,“UNICORECOMM” and other trade name, trademark,

icon, logo, brand name and/or service mark of Unicore products or their product serial referred

to in this manual (collectively “Unicore Trademarks”).

This manual or any part of it, shall not be deemed as, either expressly, implied, by estoppel or

any other form, the granting or transferring of Unicore rights and/or interests (including but not

limited to the aforementioned trademark rights), in whole or in part.

Disclaimer

The information contained in this manual is provided “as is” and is believed to be true and

correct at the time of its publication or revision. This manual does not represent, and in any

case, shall not be construed as a commitments or warranty on the part of Unicore with respect

to the fitness for a particular purpose/use, the accuracy, reliability and correctness of the

information contained herein.

Information, such as product specifications, descriptions, features and user guide in this

manual, are subject to change by Unicore at any time without prior notice, which may not be

completely consistent with such information of the specific product you purchase.

Should you purchase our product and encounter any inconsistency, please contact us or our

local authorized distributor for the most up-to-date version of this manual along with any

addenda or corrigenda.

UM960 User Manual

iii

Foreword

This document describes the information of the hardware, package, specification and the use of

Unicore UM960 modules.

Target Readers

This document applies to technicians who possess the expertise on GNSS receivers.


I
Contents
1Introduction............................................................................................1
1.1 Key Features.....................................................................................................................2
1.2 Key Specifications ...........................................................................................................2
1.3 Interfaces .........................................................................................................................4
2Hardware................................................................................................5
2.1 Dimensions ......................................................................................................................5
2.2 Pin Definition....................................................................................................................7
2.3 Electrical Specifications..................................................................................................9
2.3.1 Absolute Maximum Ratings........................................................................................9
2.3.2 Operational Conditions..............................................................................................10
2.3.3 IO Threshold ...............................................................................................................10
2.3.4 Antenna Feature.........................................................................................................10
3Hardware Design ..................................................................................11
3.1 Antenna Feed Design ....................................................................................................11
3.2 Grounding and Heat Dissipation ..................................................................................12
3.3 Power-on and Power-off ..............................................................................................12
4Production Requirement .......................................................................13
5Packaging ............................................................................................15
5.1 Label Description...........................................................................................................15
5.2 Product Packaging ........................................................................................................15







UM960 User Manual

UC-00-M34 EN R1.0 Introduction 1

1Introduction

UM960 is a new generation of GNSS high precision positioning RTK module from

Unicore. It supports all constellations and multiple frequencies, and can simultaneously

track BDS B1I/B2I/B3I + GPS L1/L2/L5 + GLONASS L1/L2+Galileo E1/E5a/E5b + QZSS

L1/L2/L5 + SBAS. The module is mainly used in UAVs, lawn mower, handheld device,

high precision GIS, precise agriculture, and intelligent drive.

UM960 is based on NebulasⅣTM, a GNSS SoC which integrates RF-baseband and high

precision algorithm. Besides, the SoC integrates a 2 GHz dual CPU, a high speed floating

point processor and an RTK co-processor with 22 nm low power design, and it supports

1408 super channels and realizes 20 Hz RTK positioning output. All these above enable

stronger signal processing.

UM960 features a compact size of 16.0 mm × 12.2 mm. It adopts SMT pads, supports

standard pick-and-place and fully automated integration of reflow soldering.

Furthermore, UM960 supports interfaces such as UART, I2C, which meets the

customers’ needs in different applications.

Figure 1-1 UM960 Module

Reserved interface, not supported currently.

2 Introduction UC-00-M34 EN R1.0

1.1 Key Features

High precision, compact size and low power consumption

Based on the new generation GNSS SoC -NebulasIVTM, with RF-baseband and high

precision algorithm integrated

16.0 mm × 12.2 mm × 2.6 mm, surface-mount device

Supports all-constellation multi-frequency on-chip RTK positioning solution

Supports BDS B1I/B2I/B3I + GPS L1/L2/L5 + GLONASS L1/L2 + Galileo E1/E5b/E5a

+ QZSS L1/L2/L5 + SBAS

All constellations and multiple frequencies RTK engine, and advanced RTK

processing technology

Independent track of each frequency, and 60 dB narrowband anti-jamming

Advanced function of jamming detection

1.2 Key Specifications

Table 1-1 Technical Specifications

Basic Information

Channels

1408 channels, based on NebulasIVTM

Constellations

GPS/BDS/GLONASS/Galileo/QZSS

Frequency

GPS: L1C/A, L2P(W), L2C, L5

BDS: B1I, B2I, B3I

GLONASS: L1C/A, L2C/A

Galileo: E1, E5b, E5a

QZSS: L1, L2, L5

Power

Voltage

+3.0 V~ +3.6 V DC

Power Consumption

440 mW（Typical）

Performance

Positioning Accuracy

Single Point

Positioning (RMS)

Horizontal: 1.5 m

Vertical: 2.5 m

DGPS (RMS)

Horizontal: 0.4 m

Vertical: 0.8 m

RTK (RMS)

Horizontal: 0.8 cm + 1 ppm

Vertical: 1.5 cm + 1 ppm

UM960 User Manual

UC-00-M34 EN R1.0 Introduction 3

Observation Accuracy（RMS）

BDS

GPS

GLONASS

Galileo

B1I/ L1C/A /G1/E1 Pseudorange

10 cm

B1I/ L1C/A /G1/E1 Carrier Phase

1 mm

B2I/L2P/G2/E5b Pseudorange

10 cm

B2I/L2P/G2/E5b Carrier Phase

1 mm

B3I/L5/E5a Pseudorange

10 cm

B3I/L5/E5a Carrier Phase

1 mm

Time Accuracy (RMS)

20 ns

Velocity Accuracy (RMS)

0.03 m/s

Time to First Fix (TTFF)

Cold Start < 30 s

Initialization Time

< 5 s (Typical)

Initialization Reliability

> 99.9%

Data Update Rate

20 Hz Positioning

Differential Data

RTCM 2.3, RTCM3.x, CMR

Data Format

NMEA-0183; Unicore

Physical Specifications

Package

24 pin LGA

Dimensions

16.0 mm × 12.2 mm × 2.6 mm

Environmental Specifications

Operating Temperature

-40 °C~ +85 °C

Storage Temperature

-55 °C~ +95 °C

Humidity

95% No condensation

Vibration

GJB150.16A-2009; MIL-STD-810F

Shock

GJB150.18A-2009; MIL-STD-810F

Functional Ports

UART x 3

I2Cx 1

Reserved interface, not supported currently.

4 Introduction UC-00-M34 EN R1.0

1.3 Interfaces

UM960

SAW

Filter

TCXO

RESET_N

EVENT

PPS

I2C

UART1/2/3

LNA

ANT1_IN

RTC

Nebulas IV

CLOCK

RTK_STAT/LAN_EN

GNSS

Interface

PMU

Figure 1-2 UM960 Block Diagram

RF Part

The receiver gets filtered and enhanced GNSS signal from the antenna via a coaxial

cable. The RF part converts the RF input signals into the IF signal, and converts IF

analog signal into digital signals required for NebulasIV chip.

NebulasIV SoC

NebulasIV is UNICORECOMM’s new generation high precision GNSS SoC with 22 nm low

power design, supporting all constellations, multiple frequencies and 1408 super

channels. It integrates a 2 GHz dual CPU, a high speed floating point processor and an

RTK co-processor, which can fulfill the high precision baseband processing and RTK

positioning independently.

1PPS

UM960 outputs 1 PPS with adjustable pulse width and polarity.

Event

UM960 provides 1 Event Mark Input with adjustable frequency and polarity.

Reset (RESET_N)

Active LOW, and the active time should be no less than 5 ms.

UM960 User Manual

UC-00-M34 EN R1.0 Hardware 5

2Hardware

2.1 Dimensions

Table 2-1 Dimensions

Symbol

Min.(mm)

Typ. (mm)

Max. (mm)

15.80

16.00

16.50

12.00

12.20

12.70

2.40

2.60

2.80

0.90

1.00

1.10

0.20

0.30

0.40

1.40

1.50

1.60

1.00

1.10

1.20

0.70

0.80

0.90

3.20

3.30

3.40

2.90

3.00

3.10

1.30

1.40

1.50

0.99

1.00

1.10

0.72

0.82

0.92

0.99

1.00

1.10
