Ublox EVK-M8 Manual de usuario

2. Setup

1. Download and install the EVK-M8 software (and docu-

mentation) from www.u-blox.com/evk-search.

See installation notes on the back of this card.

2. Connect the unit to a PC. Options:

• USB: Connect via USB port (G). The USB driver

installs automatically when the device is

connected to a PC; internet connection required.

• UART: Connect via RS232 (F). Set switch (B) to I2C.

• SPI / I2C compliant DDC: Connect the pins (C).

Set switch (B) to either SPI or I2C.

NOTE: Press RST (E) after setting switch (B).

3. Provide power to the device at all times, either via USB

on the back (G) or the V5 IN pin (D) on the front.

4. Connect the GNSS antenna to the evaluation unit (A)

and place the antenna in a location with an unobstruct-

ed view of the sky. For best performance, use an active

antenna or external LNA (when connecting to a GNSS

simulator).

5. Start the u-center GNSS evaluation software and se-

lect the corresponding COM port and baud rate.

Quick Start for EVK-M8 kits

UBX-13003205 - R04

1. Overview

3. Kit includes

• EVK-M8 unit

• USB cable

• Active GPS / GLONASS / BeiDou antenna with a 3 m cable

5. Interfaces

The EVK-M8 can be used to evaluate all interfaces avail-

able on u-blox M8 chips and modules. The evaluation unit

provides a USB connector for communication and powering

the device, as well as a UART connector for connecting to

the COM port of your PC.

SPI and the I2C-compliant DDC interfaces are designed to

enable communications with a host CPU.

7. More information

NOTE: Refer to recommendations in the EVK user guide

when using the EVK-M8 with a GNSS simulator.

For more information about the EVK-M8, contact your

nearest u-blox support:

www.u-blox.com/contact-technical-support

UBX-13003205 - R04

4. Installation

Notes for downloading the EVK-M8 software package and

running the installation:

• An Internet connection is required

• Supported Windows operating systems: Windows 7

onwards (x86 and x64 versions)

• Download the u-center evaluation software

• Run the u-center installer executable le and follow the

installer instructions

• When the installation is complete, you will nd a

u-center menu under the Windows Start button,

All Programs > u-blox

6. u-center

The u-center GNSS evaluation software provides a powerful

tool for evaluation, performance analysis and conguration

of u-blox positioning products.
