UM185US
User Manual
1
TABLE OF CONTENTS
CHAPTER 1
BEFORE USING UM185US
ABOUT THIS USER MANUAL............................................................4
PRODUCT OVERVIEW ......................................................................4
WHAT’S INSIDE THE PRODUCT PACKAGE .......................................4
INTRODUCTION TO U.S. CELLULAR UM185US WIRELESS USB
MODEM ...........................................................................................5
PRODUCT FEATURES........................................................................6
PRODUCT HANDLING ......................................................................7
CONFIGURATION .............................................................................7
CHAPTER 2
INSTALLING UM185US
PRECAUTIONS ...............................................................................10
RECOMMENDED SYSTEM REQUIREMENTS...................................10
INSTALLING SOFTWARE ...............................................................11
CHAPTER 3
SETUP
THE U.S. CELLULAR BROADBAND CONNECT SETUP
PROGRAM (WIN) ...........................................................................15
THE U.S. CELLULAR BROADBAND CONNECT SETUP
PROGRAM (MAC) ..........................................................................18
CHAPTER 4
USING U.S. CELLULAR BROADBAND CONNECT
FEATURES.......................................................................................24
GETTING STARTED .........................................................................25
CONNECTING .................................................................................26
ADDITIONAL FEATURES ................................................................28
THE FILE MENU..............................................................................30
THE VIEW MENU............................................................................30
THE TOOLS MENU..........................................................................31
THE OPTIONS MENU ......................................................................35
THE HELP MENU ............................................................................36
2
CHAPTER 5
REGULATORY AND SAFETY INFORMATION
REGULATORY NOTICES .................................................................40
OPERATING CONDITIONS .............................................................40
WARNINGS AND CAUTIONS .........................................................41
SAFETY PRECAUTIONS ................................................................42
CHAPTER 6
APPENDIX
GLOSSARY .....................................................................................46
SPECIFIC ABSORPTION RATES (SAR).............................................49
SAFETY INFORMATION FOR RF EXPOSURE...................................51
U.S. FEDERAL COMMUNICATIONS COMMISSION RADIO
FREQUENCY INTERFERENCE STATEMENT .....................................53
12 MONTH LIMITED WARRANTY ..................................................55
TABLE OF CONTENTS
ABOUT THIS USER MANUAL
PRODUCT OVERVIEW
WHAT’S INSIDE THE PRODUCT PACKAGE
INTRODUCTION TO WIRELESS UM185US
USB MODEM
PRODUCT FEATURES
PRODUCT HANDLING
CONFIGURATION
CHAPTER 1
BEFORE USING
UM185US
4
BEFORE USING UM185US
4
■
ABOUT THIS USER MANUAL
You will find all the information you need to install and
use the UM185US in this user manual. Before using the
UM185US, you must properly install the U.S. Cellular
®
Broadband Connect by closely following the installation
instructions.
INSTRUCTIONS
•
The software needed to install and configure your
UM185US USB device is already included on the device.
•
It is highly recommended that you read the safety
precautions described in this manual before using the
UM185US.
nThis User Guide is described for Windows-based users. User
interfaces may be slightly different for Macintosh.
■
PRODUCT OVERVIEW
Thank you for purchasing the U.S. Cellular Wireless
UM185US USB Modem. The UM185US is a 3G wireless device
that enables high-speed wireless communication from your
laptop or desktop computer. The UM185US is simple to
install and use.
■
WHAT’S INSIDE THE PRODUCT PACKAGE
The following items are included in the product package. If
any of the items listed below are missing, please contact the
retail location where you purchased the product.
•
UM185US Wireless USB Modem
•
Quick Start Guide
ABOUT THIS USER
MANUAL
5
BEFORE USING UM185US
■
INTRODUCTION TO U.S. CELLULAR UM185US
WIRELESS USB MODEM
The U.S. Cellular UM185US is designed for your laptop or
desktop computer’s USB port, which is available in most
models. The UM185US can be used to access the Internet,
your company’s intranet, or you can use it to send and
receive email. It is extremely useful when you are away from
the office, on the road, or wherever a wireline Internet
access is not readily available.
nBlue light: Connected to laptop or desktop computer and
detected to network
Red light: Connected to laptop or desktop computer but out
of service status
INTRODUCTION TO
UM185US USB MODEM
USB Connector
External Antenna
Booster Jack
(on the back side)
LED status
indicator *
6
BEFORE USING UM185US
■
PRODUCT FEATURES
•
Power management: The UM185US utilizes power
management and system overhead reduction functions
provided by the USB interface for maximum power
savings.
•
Antenna design: Efficient, innovative internal antenna
design optimizes data transfer rate and sensitivity to
network signals.
•
USB Modem that supports Type A USB Port interface.
•
Supports North American US_PCS, Wireless CDMA and
AWS bands.
•
Utilizes QUALCOMM QSC6085 chipset.
•
Supports 3G network technologies.
•
Maximum Data Rate: 3.1 Mbps download; 1.8 Mbps
upload.
•
Supports Windows XP, Vista and 7 systems with installed
host software and driver.
•
Compatible with Mac OS X 10.4.11, 10.5 or 10.6.
•
Provides U.S. Cellular Wireless Modem service.
•
The datacard cover automatically closes when you push
the designated point as displayed in the following figure.
•
When using the UM185US, please slide the black USB
cover UP for the best reception.
PRODUCT FEATURES
7
BEFORE USING UM185US
■
PRODUCT HANDLING
1
Do not put any adhesive label on the USB connector. It
may leave a sticky residue that can cause problems inside
the USB port.
2
The UM185US USB device should easily slide into the
USB port. Do not force the UM185US into the USB port
as it may cause damage to the modem and/or the port.
3
Keep the UM185US in a dry and clean place. (Storage
temperature: -22°F to 149°F [- 30°C to 65°C]).
Keep your device away from liquids, dust and excessive
heat.
■
CONFIGURATION
To use the UM185US, you should first install the software
included on the device and configure the UM185US USB
device. See the next section for more information on
software installation and USB device configuration.
PRODUCT HANDLING
8
MEMO
CHAPTER 2
INSTALLING
UM185US
PRECAUTIONS
RECOMMENDED SYSTEM
REQUIREMENTS
INSTALLING SOFTWARE
