0113 T H -2382PAGE 1 OF 2

SCOUT PRO BALANCE SCALE

H-2382, H-2383

H-2384

OPERATING ISSUE RECOMMENDATIONS

No Display. 1. Make sure the AC Adapter is plugged in.

2. You may need to replace the batteries.

Battery Indicator is flashing. Replace batteries.

Incorrect weight reading. 1. Press the ON/ZERO OFF button with no weight on the

platform, then weigh item.

2. Recalibrate the balance.

Calibration procedures do not work. 1. Use correct masses.

2. See error codes note ERR4. (See Page 2)

Unable to display weight in a particular

weighing unit.

1. Use Units menu to set desired units ON.

2. Exit Hold or Totalize mode.

Balance readings unstable. Either move or shield the balance from external air

currents or vibration.

Error code is displayed. Review error code table and take appropriate action.

TROUBLESHOOTING

1- 800-295 -5510

uline.com

0113 T H -2382PAGE 2 OF 2

SCOUT PRO BALANCE SCALE

H-2382, H-2383

H-2384

ERROR CODES

ERROR CODE LIST RECOMMENDATIONS

Err 1 chEct

Invalid checksum data.

1. Cycle balance ON/OFF

2. Return balance for service

Err 2 LoAd

Overload (>cap+90d) or Underload.

1. Remove load

2. Make sure shipping lock is unlocked

3. Recalibrate

Err 4 WEIght

Incorrect calibration weight.

1. Use correct calibration weights

2. Check environmental conditions

Err 5 999999

Displayed value>99999.

1. Exit application

2. Rezero balance

Err 6 count

Parts counting error – balance exits parts

counting.

1. Exit application

2. Rezero balance

Err 8 FULL

RS232 buffer is full.

1. Cycle ON/OFF

2. Check RS-232 settings in balance and computer

Err 9 dAtA

Internal data error. The next button

press or a 5 second time-out causes the

balance to turn off.

1. Cycle ON/OFF

2. Return balance for servicing

1- 800-295 -5510

uline.com

πCHICAGO • ATLANTA • DALLAS • LOS ANGELES • MINNEAPOLIS • NYC/PHILA • SEATTLE • MEXICO • CANADA
