Chapter 1

Introduction

Overview

The S1832DL Tiger 100 is a quality, high performance mainboard

designed for dual Intel Pentium II microprocessors. This mainboard

utilizes the Intel 440BX AGPset and can support CPU speeds of

233MHz through 450MHz, and host bus speeds of 66MHz to 100MHz.

The S1832DL mainboard, with built-in AGP slot, provides high perfor-

mance capabilities that are ideal for a wide range of demanding appli-

cations such as CAD, CAM, CAE, desktop publishing, 3D animation,

and video production.

This integrated system board achieves high reliability with numerous

features and yet is small enough to be supported in an ATX form

factor. Some of the features included are onboard dual channel PCI

PIO, Bus Master IDE and UltraDMA/33, onboard floppy controller,

and onboard high speed I/O.

Flexibility and expandability have been designed into the Tiger 100.

With I/O and drive controller support built onboard, the one AGP slot,

chapter 1

Introduction

http://www.tyan.com

INTRO

five PCI and two ISA slots (one shared, seven usable slots) are free

for numerous add-on expansion cards.

Remember to take a look at TYAN Computer’s web site located at

http://www.tyan.com. There you can find information on all of TYAN’s

products along with FAQs, distributors list, drivers, and BIOS setting

explanations.

Icons

In order to help you navigate this manual and set up your system, we

have added several icons to our format.

This icon alerts you to particularly important details regard-

ing the setup or maintenance of your system. This icon

often appears next to information that may keep you from

damaging your board or system. While we will often point out the most

vital paragraphs in a chapter, you should always read every word in the

text. Failing to do so can lead to exasperation and expense.

Wherever possible, we have included step-by-step instruc-

tions for setting up your system, which are indicated by

this icon. However, it is in your best interest to read an

entire section (and perhaps the entire manual) before you begin to

fiddle with your motherboard.

While we have alerted you to potential dangers in several

places in the manual with this icon, these warnings should

not be regarded as the whole of your safety regimen. Never

forget that computers are electrical devices, and are capable of deliver-

ing a shock. Prevent damage to yourself and to your board: always

ensure that your system is turned off and unplugged whenever you are

working with it, and that you are equipped with a static safety device.

important!

procedure

warning

http://www.tyan.com

Chapter 1

Introduction

HardwareSpecifications/Features

Processor Information •Two SEC slots (Slot One type).

•66 to 100MHz BIOS selectable bus

support.

•Pentium II 233-450MHz.

•Supports Celeron CPU (single only).

Chipset Information •Intel 440BX AGPset.

•Intel PIIX4e controller.

•National 309 Super I/O chipset.

Voltage and Power •ATX power supply connector.

Information •+12V power source for DC fan

onboard.

•3.3V DRAM support.

•Utilizes GTL+ bus to reduce power

consumption and EMI.

Main Memory •Up to 1024MB onboard.

•Four 168-pin DIMM sockets.

•Supports 100MHz SDRAM with

SPD.

System Management •National LM79 and LM75

ASICs with onboard alarm for

monitoringtemperature, supply

voltages, and fan speed.

•Intel LANDesk Client Manager

software

•Chassis intrusion detection capable.

Expansion Slots •One 32-bit AGP slot.

•Five 32-bit PCI Bus Master slots.

•Two 16-bit ISA slots.

http://www.tyan.com

INTRO

•One shared, seven usable slots.

Physical Dimensions •ATX design.

•12 inches x 9.8 inches.

•Requires Intel Venus compatible I/O

shield.

BIOS Information •AMI Plug and Play flash BIOS.

•Deep Green, Energy Star, ACPI,

Year 2000, and PC98 compliant.

•Soft power-down, multiple boot

options.

•Win98/NT5 ready, DMI 2.0

compliant.

•PCI 2.1, APM 1.1 compliant.

Disk Drive & System I/O •Two PCI bus mastering EIDE

channels.

•Supports EIDE CD-ROMs.

•PIO Mode 3 & 4 (up to 17MB/sec

DTR).

•UltraDMA/33 bus mastering mode

(up to 33MB/sec DTR).

•Support for two floppy drives (up to

2.88MB).

•Two serial ports (16550 UARTs).

•One ECP/EPP parallel port.

•One IR (InfraRed) I/O interface port.

•Two USB rev 1.2 (universal serial

bus) connectors.

•One PS/2 mouse connector.

•One PS/2 keyboard connector.

Warranty •3 year manufacturer’s warranty.

http://www.tyan.com

Chapter 1

Introduction

SoftwareSpecifications

OS •Operates with MS-DOS, Windows

3.x, Windows for WorkGroup 3.x,

Windows95, Windows 98, Windows

NT, OS/2, Novell Netware, Solaris,

and SCO Unix.

Information presented in this publication has been carefully checked for

reliability. However, no responsibility is assumed for inaccuracies. The

information contained in this document is subject to change without

notice.

Technical Support

If a problem arises with your system, you should turn to your dealer for

help first. Your system has most likely been configured by them, and

they should have the best idea of what hardware and software your

system contains. Hence, they should be of the most assistance. Further,

if you purchased your system from a dealer near to you, you can

actually bring your system in to them to have it serviced, instead of

attempting to do so yourself (which can have expensive consequences).

If your dealer is unable to assist you,

try our web page, http:// www.tyan.com

user newsgroup, alt.comp.periphs.mainboard.tyan

technical support phone line, (510) 440-8808

or e-mail address [email protected]

http://www.tyan.com

ReturningMerchandiseforService

During the warranty period, contact your distributor or system vendor

FIRST for any product problems. This warranty only covers normal

customer use and does not cover damages incurred during shipping or

failure due to the alteration, misuse, abuse, or improper maintenance of

products.

For Resellers Only:

A receipt or copy of your invoice marked with the date of purchase is

required before any warranty service can be rendered. You can obtain

service by calling the manufacturer for a Return Merchandise Authori-

zation (RMA) number. The RMA number should be prominently

displayed on the outside of the shipping carton and the package should

be mailed prepaid, or hand-carried to the manufacturer. TYAN will pay

to have the board shipped back to you.

Trademarks

AMIBIOS is a trademark of American Megatrend Incorporated.

Windows is a trademark of Microsoft Corporation.

IBM, PC, AT, PS/2 are trademarks of IBM Corporation.

INTEL, Pentium II, Celeron are trademarks of Intel Corporation.

S1832DL Tiger 100 are trademarks of TYAN Computer Corporation.

All other trademarks are the property of their respective companies.

INTRO

http://www.tyan.com

Chapter 2

Board Installation

chapter 2

Board Installation

Unpacking

The mainboard package should contain the following:

·S1832DLmainboard

·One IDE 40-pin cable

·One 34-pin floppy cable

·User’s manual

·Two retention modules

·One Tyan System Management & Driver CD

Installation

You are now ready to install your mainboard. The mounting hole

pattern of the S1832DL matches the ATX system board specifications.

Your chassis should be that of a standard ATX mainboard form factor.

http://www.tyan.com

How to install our products right...the first time.

What’s the first thing I should do?

The first thing you should do is read this user’s manual. It contains

important information which will make configuration and setup much

easier.

The next step is to properly ground yourself. First, unplug the power

from your computer case and then touch the metal casing of the power

supply or any metal part on the computer case. This will discharge any

electricity from your body. Take the motherboard out of the cardboard

box and static bag, holding it by its edges, and place it on a grounded

anti-static surface, component side up. Inspect the board for damage.

DO NOT APPLY POWER TO THE BOARD IF IT HAS BEEN

DAMAGED!

Press down on any of the socket ICs if it appears that they are not

properly seated (the board should still be on an anti-static mat). Do not

touch the bottom of the board. Remember, don’t take any electronic

device out of its protective bag until you are ready to actually install it

into the computer case. If you don’t discharge yourself and you zap the

motherboard or adapter card, problems may not arise immediately

because electrostatic discharge damage, unlike physical damage, causes

the device to fail over time.

Installthemotherboardinto your case.

Follow the instructions provided by the case manufacturer for proper

installation guidelines. TYAN recommends that you use only one screw

to hold down the motherboard. The rest of the mounting holes should be

used for the plastic standoffs. If your case does not have a hole for a

standoff, simply cut off the bottom of the plastic standoff so that the flat

portion rests on the metal. The adapter cards and the screws holding

them down will keep your board flat. The fastening screw should not

short any of the traces on the motherboard. Make certain that you do

not overtighten the screw, as it will damage the motherboard and

possibly break internal traces in the surrounding area. The hole you

important!

procedure

INSTALL

Otros manuales para S1832DL

Tabla de contenidos

Otros manuales de Placa madre de TYAN

TYAN

TYAN THUNDER LE S2510 Manual de usuario

TYAN

TYAN S7120 Manual de usuario

TYAN

TYAN THUNDER 2400 Manual de usuario

TYAN

TYAN TRINITY GC-SL Manual de usuario

TYAN

TYAN TRINITY KT Manual de usuario

TYAN

TYAN Thunder n3600W S2935 Manual de usuario

TYAN

TYAN M4985 Manual de usuario

TYAN

TYAN S7056 Manual de usuario

TYAN

TYAN S7020 Manual de usuario

TYAN

TYAN THUNDER I7505 Manual de usuario

TYAN

TYAN Tempest i5100X Manual de usuario

TYAN

TYAN Thunder K8WE S2895 Instrucciones de instalación y funcionamiento

TYAN

TYAN S8812 Manual de usuario

TYAN

TYAN TAHOE AT Manual de usuario

TYAN

TYAN TOMCAT N3400B Manual de usuario

TYAN

TYAN Thunder n3600M (S2932) Manual de usuario

TYAN

TYAN Tempest i5000PX S5380 Manual de usuario

TYAN

TYAN TIGER K8W Manual de usuario

TYAN

TYAN Tigercub 100 S1894 Manual de usuario

TYAN

TYAN TOMCAT I810E Manual de usuario

TYAN

TYAN S1832DL Manual de usuario

TYAN

TYAN THUNDER K8S Manual de usuario

TYAN

TYAN S8228 Manual de operación y mantenimiento

TYAN

TYAN TRINITY 371 Manual de usuario

Manuales populares de Placa madre de otras marcas

DFI

DFI SD170 Manual de usuario

ASROCK

ASROCK ROMED8-2T Manual de usuario

Asus

Asus P2L97A Manual de usuario

Winmate

Winmate IC70 Manual de usuario

Asus

Asus MES-B Manual de usuario

Grantech

Grantech SYS8F377VGGA-3OMN Manual de usuario

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manual de usuario

Gigabyte

Gigabyte GA-9IVDT Manual de usuario

Texas Instruments

Texas Instruments ADS8372EVM Manual de usuario

Commell

Commell MS-C73 Manual de usuario

IBT Technologies

IBT Technologies MB860 Manual de usuario

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manual de usuario

Biostar

Biostar M7VIT Bravo Instrucciones de funcionamiento e instalación

Intel

Intel D33217CK Manual de usuario

Asus

Asus F1A55-M LX PLUS R2.0 Manual de usuario

EPC

EPC EPC9147C Manual de usuario

Asus

Asus EX-B760M-V5 D4 Manual de usuario

EPOX

EPOX MU-8KHA0010 Manual de usuario
