TYAN P1103 Manual de usuario

P1103/P1103B

Version 1.00

this manual may be reproduced or translated without prior written consent from

MiTAC Computer Corp.

Trademark

All registered and unregistered trademarks and company names contained in

this manual are property of their respective owners including, but not limited to

the following.

TYAN®is a trademark of MiTAC Computer Corporation.

Broadcom®is a trademark of Broadcom Corporation.

Notice

Information contained in this document is furnished by MiTAC Computer

Corporation and has been reviewed for accuracy and reliability prior to printing.

MiTAC assumes no liability whatsoever, and disclaims any express or implied

warranty, relating to sale and/or use of TYAN®products including liability or

warranties relating to fitness for a particular purpose or merchantability. MiTAC

retains the right to make changes to product descriptions and/or specifications

at any time, without notice. In no event will MiTAC be held liable for any direct

or indirect, incidental or consequential damage, loss of use, loss of data or other

malady resulting from errors or inaccuracies of information contained in this

document.

http://www.tyan.com

Federal Communication Commission (FCC)

Notice for the USA

Compliance Information Statement (Declaration

of Conformity Procedure) DoC FCC Part 15: This

device complies with part 15 of the FCC Rules

Operation is subject to the following conditions:

1) This device may not cause harmful interference;

2) This device must accept any interference received including

interference that may cause undesired operation. If this equipment

does cause harmful interference to radio or television reception, which

can be determined by turning the equipment off and on, the user is

encouraged to try one or more of the following measures:

– Reorient or relocate the receiving antenna.

– Increase the separation between the equipment and the receiver.

– Plug the equipment into an outlet on a circuit different from that of

the receiver.

Consult the dealer on an experienced radio/television technician for

help.

Notice for Canada

This apparatus complies with the Class B limits for radio interference as

specified in the Canadian Department of Communications Radio

Interference Regulations. (Cet appareil est conforme aux norms de

Classe B d’interference radio tel que specifie par le Ministere Canadien

des Communications dans les reglements d’ineteference radio.)

Notice for Europe (CE Mark)

This product is in conformity with the Council

Directive 89/336/EEC, 92/31/EEC (EMC).

CAUTION: Lithium battery included with this board. Do not puncture,

mutilate, or dispose of battery in fire. There will be danger of explosion if

battery is incorrectly replaced. Replace only with the same or equivalent

type recommended by manufacturer. Dispose of used battery according

to manufacturer instructions and in accordance with your local regulatio-

-ns.

http://www.tyan.com

Contents

Before you begin… ..............................................................................4

Chapter 1: Instruction .......................................................................... 5

1.1 - Overview ....................................................................................................... 5

1.2 - Product Features ........................................................................................... 5

1.3 - Software Specifications ................................................................................. 6

Chapter 2: P1103 Dual Port GbE NIC Installation..............................7

2.1 - Board Image.................................................................................................. 7

2.2 - Card Parts, Jumpers and Connectors ........................................................... 8

2.3 - Tips on Installing P1103/P1103B in Chassis ............................................... 11

2.4 - LED Color Definition .................................................................................... 12

2.5 - Finishing Up ................................................................................................ 12

Appendix: P1103B Bypass Function................................................ 13

Technical Support..............................................................................31

http://www.tyan.com

Before you begin…

Check the box contents!

The retail motherboard package should contain the following:

1 x P1103/P1103B LAN Card (with full height bracket)

1 x Half-height bracket

1 x P1103 Quick reference guide

1 x TYAN®Driver CD

http://www.tyan.com

Chapter 1: Instruction

1.1 - Overview

This Dual Port GbE NIC card P1103/P1103B based on Broadcom dual port

GbE transceiver, is a generic of 4 x PCI-E 1.1 card providing 2 GbE copper

interfaces with RJ45 connectors.

P1103/P1103B has a cut through option which provides LAN1 to LAN 2 cutting

through when system power down or is controlled by system software.

Remember to visit TYAN®’s website at http://www.tyan.com, where you can find

information on all TYAN®products with FAQs, online manuals and updated

drivers, etc.

1.2 - Product Features

P1103/P1103B offers the following features:

zTriple speed 1000Mbps (1000Base-T), 100 Mbps (100Base-Tx) and 10

Mbps (10Base-T) operation.

zNway auto negotiation automatic sensing and switching between 1Gbps full

duplex and 100/10 Mbps operations half duplex or Full Duplex.

zHost Interface standard support

zHost Interface PCI-Express 4X Lane (Version 1.0a).

zHigh performance, reliability, and low power use in Broadcom 5715 /5714 /

5704 dual integrated MAC + PHY and SERDES chip controller.

zHardware acceleration that can offload tasks from the host processor. The

controllers can offload TCP/UDP/IP checksum calculations and TCP

segmentation.

zJumbo Frame (9KB).

z802. X flow control.

zStatistics for SNMP

zRJ-45 female connectors.

zLEDs indicators for link/Activity/Bypass Mode status.

zPriority queuing-802.1p layer 2 priority encoding.

zVirtual LANs-802.1q VLAN tagging.

zIndependently copper Gigabit Ethernet channels support two Gigabit

Ethernets (1000Base-T)/Fast Ethernet (100Base-Tx)/Ethernet (10Base-T).

zUltra deep, 64 KB packet buffer per channel lowers CPU utilization.

http://www.tyan.com

P1103B also offers the following Bypass functions:

zBypass Ethernet ports on Power Fail, System Hangs or Software Application

Hangs.

zSoftware programmable Bypass or Normal or Disconnect Mode.

zOn Board Watch Dog Timer Controller.

zSoftware programmable time out interval.

zSoftware Programmable WDT Enable / Disable.

zProgrammable state (Bypass mode or Normal mode or Disconnect mode) at

Power down (S5) or Power up or Driver load.

zEmulates standard NIC

zIndependent Bypass operation in every two ports.

1.3 - Software Specifications

The P1103 supports the following operating systems:

9Windows XP x86/x64; Windows 2003 R2 x86/x64; Windows 2008 x64 SP2;

Windows Vista x64

9RHEL 5.3 x86/x64

9SLES 10 SP2 x64, SLES 11 SP2 x86/x64

9Cent OS 5.2 x64, Cent OS 5.3 x86/x64

9Solaris 10 u7

http://www.tyan.com

Chapter 2: P1103 Dual Port GbE NIC Installation

2.1 - Board Image

P1103:

P1103B:

http://www.tyan.com

2.2 - Card Parts, Jumpers and Connectors

Jumpers & Connectors

Jumper/Connector Function

J1 Reserve for Watch Dog Timer

J2/J4 Relay Source Select

J3 FPGA_PROGRAM

J5 PTC_MODE Select

J6 JTAG

JP1 RCC_SMBus Connector

JP2 ATTN_BTTN

SW1 Address Switch

LAN1/LAN2 RJ-45 for 10/100/1000 Base T Port

Note:

A. ▲indicates Pin 1.

B. J1, J2/J4, J3, J5, J6 and SW1 are reserved for bypass

function.

C. This diagram is representative of the latest LAN card

revision available at the time of publishing. The card you

receive may not look exactly like the above diagram.

http://www.tyan.com

Jumper Placement

J1: Reserve for Watch Dog Timer (for P1103B Bypass function)

Pin 1 2 3 4 5

Signal WDT NC WDT_

P_CHE

PTC_CT

J2/J4: Relay Source Select (for P1103B Bypass function)

Pin J2 Pin1 J2 Pin2 J4 Pin1 J4 Pin2

J2 Pin_1

J4 Pin_1 Signal RELAY_

PIN6

V_RL_R

ESET GND RELAY_PIN1

J3: FPGA_PROGRAM

Pin 1 2

Pin_1 Signal FPGA_PROGRAM GND

J5: PTC_Mode Select (for P1103B Bypass function)

Pin 1 2

Pin_1 Signal PTC_MODE GND

J6: JTAG (for P1103B Bypass function)

Pin 1 2 3 4 5 6

Signal FPGA

_TMS

FPGA

_TDI

FPGA

_TDO

FPGA

_TCK GND VCC

http://www.tyan.com

JP1: RCC_SMBus Connector

Pin 1 2 3

Pin_1 Signal RCC_SDA GND RCC_SCL

JP2: ATTN_BTTN

Pin 1 2

Pin_1 Signal ATTN_BTTN# GND

LED Action Indicator

LED Description

LED1 Wake Event

LED2 PCIE Attention Indicator

LED3 Data Link Status LED

LED4 PCIE Connector Power Indicator

LED5 Physical Layer Status LED

LED6

PTC function Status LED

4 Hz blink: Pass Thru module normal

1 Hz blink: Pass Thru module in Watch Dog timer mode

LED7

Watch Dog timer Status LED

(Keep light when Watch Dog timeout event happen; Blink once

when receive Watch Dog trigger signal, only available when Watch

Dog Timer Enable)

LED8

SYS Status LED

S5,Off

S5 -->Power ON : Blinking once

Driver load: Keep light

LED9 FPGA Configuration Indicator

Note: LED6/7/8/9 are for P1103B Bypass function.

SW1: Address Switch (for P1103B Bypass function)

Switch1 Switch2 Switch3 Switch4 SMBus

Address

ON ON ON x 0x40

ON ON OFF x 0x42

ON OFF ON x 0x44

ON OFF OFF x 0x46

OFF ON ON x 0x48

OFF ON OFF x 0x4A

OFF OFF ON x 0x4C

OFF OFF OFF x 0x4E
