TruHearing Flyte RIE Manual de usuario

User Guide Flyte RIE

User Guide Flyte BTE

400846011US-17.10-Rev.A.indd 1 02-10-2017 14:46:59

Hearing instrument type designations for models included in this user guide are: BRIE, FCC ID: X26BRIE,

IC: 6941C-BRIE. Please see page 7 for list of models referring to all types.

Statement:

This device complies with part 15 of the FCC rules and ICES-003 of the ISED rules. Operation is subject

to the following two conditions:

1. This device may not cause harmful interference

2. This device must accept any interference received, including interference that may cause undesired

operation

Note: This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to part 15 of the FCC rules and ICES-003 of the ISED rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruc-

tions, may cause harmful interference to radio communications. However, there is no guarantee that inter-

ference will not occur in a particular installation. If this equipment does cause harmful interference to radio

or television reception, which can be

determined by turning the equipment off and on, the user is encouraged to try to correct the interference

by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from the one in which the receiver is con-

nected.

• Consult the dealer or an experienced radio/TV technician for help.

• Changes or modiﬁcations can void the user´s authority to operate the equipment.

400846011US-17.10-Rev.A.indd 2 02-10-2017 14:46:59

The products are in compliance with the following regulatory requirements:

• In EU: the device conforms to the Essential Requirements according to Annex I of Council Directive

93/42/EEC for medical devices (MDD).

• GN Hearing A/S declares that the radio equipment type(s) LO85 and LO90 is/are in compliance with

Directive 2014/53/EU (RED).

• The declaration of conformity may be consulted at www.declarations.resound.com/

• In US: FCC CFR 47 Part 15, subpart C.

• Other identiﬁed applicable international regulatory requirements in countries outside the EU and US.

Please refer to local country requirements for these areas.

• In Canada: these hearing aids are certiﬁed under the rules of ISED.

• Japanese Radio Law and Japanese Telecommunications Business Law Compliance. This device is

granted pursuant to the Japanese Radio Law (電波法) and the Japanese telecommunications Business

Law (電気通信事業法) This device should not be modiﬁed (otherwise the granted designation number

will become invalid

This device operates in the frequency range of 2.4 GHz - 2.48 GHz.

This device includes an RF transmitter that operates in the range of 2.4 GHz - 2.48 GHz.

Maximum RF output power transmitted is up to 0 dBm.

Intended use

Generic air-conduction hearing instruments are wearable sound-amplifying devices intended to compen-

sate for impaired hearing. The fundamental operating principle of hearing instruments is to receive, amplify,

and transfer sound to the ear drum of a hearing impaired person.

400846011US-17.10-Rev.A.indd 3 02-10-2017 14:46:59

Prescription use of a Tinnitus Sound Generator (TSG) hearing instrument

The TSG module should be used as prescribed by your doctor, audiologist or hearing healthcare profes-

sional. In order to avoid permanent hearing damages, the maximum daily usage depends on the level of

the generated sound.

Should you develop any side effects from using the sound generator, such as dizziness, nausea, head-

aches, perceived decrease in auditory function or increase in tinnitus perception, you should discontinue

use of the sound generator and seek medical evaluation.

The target population is primarily the adult population over 18 years of age. This product may also be used

with children 5 years of age or older. However, children and physically or mentally challenged users will re-

quire training by a doctor, audiologist, hearing healthcare professional or the guardian for the insertion and

removal of the hearing instrument containing the TSG module.

Important notice for prospective sound generator users

A tinnitus masker is an electronic device intended to generate noise of sufﬁcient intensity and bandwidth to

mask internal noises. It is also used as an aid in hearing external noises and speech.

Good health practice requires that a person with a tinnitus condition have a medical evaluation by a licensed

physician (preferably a physician who specializes in diseases of the ear) before using a sound generator.

Licensed physicians who specialize in diseases of the ear are often referred to as otolaryngologists, otolo-

gists or otorhinolaryngologists.

400846011US-17.10-Rev.A.indd 4 02-10-2017 14:46:59

Introduction

Congratulations on the purchase of your new hearing instruments. The innovative sound technology and

design, combined with the customised device programming selected by your hearing care professional, will

make hearing a more enjoyable experience. Hearing instruments will enable you to hear sounds that you

may not have heard in years because of your hearing loss. Practice and a positive attitude are important in

learning to use hearing instruments. Your hearing instruments have been adjusted according to your indi-

vidual hearing loss and needs. Some people adjust quickly to wearing hearing instruments in their ears and

hearing new sounds; other people may need more time.

Please read this manual carefully in order to wholly beneﬁt from the use of your hearing instruments. With

proper care, maintenance, and usage, your hearing instruments will aid you in better communication for

many years. Ask your hearing care professional if you have any questions.

400846011US-17.10-Rev.A.indd 5 02-10-2017 14:46:59

Hearing instrument model:

Model 62: Battery size 13

Receiver tube length:

Dome size:

Left serial number:

Right serial number:

400846011US-17.10-Rev.A.indd 6 02-10-2017 14:46:59

Receiver-in-the-ear (RIE) hearing instruments of type BRIE with FCC ID X26BRIE, IC number

6941-BRIE and size 13 battery are available in the following variants:

FL962-DRW UP, FL962-DRW HP, FL962-DRW MP, FL962-DRW LP

FP962-DRW-UP, FP962-DRW-HP, FP962-DRW-MP, FP962-DRW-LP

FL762-DRW UP, FL762-DRW HP, FL762-DRW MP, FL762-DRW LP

FP762-DRW-UP, FP762-DRW-HP, FP762-DRW-MP, FP762-DRW-LP

The identiﬁcation number for the BRIE device models can be found at location “14” as indicated in the il-

lustrations on page 10.

400846011US-17.10-Rev.A.indd 7 02-10-2017 14:46:59

Contents

Statement: .............................2

Intended use ...........................3

Prescription use of a Tinnitus Sound Generator

(TSG) hearing instrument ..................4

Important notice for prospective sound

generator users..........................4

Introduction.............................5

Contents ...............................8

Getting started .........................11

SmartStart ............................ 11

Inserting/Replacing the battery.............11

Low battery indicator ....................13

Low battery indicator when paired with

wireless accessories only .................13

Sport lock .............................14

Inserting/Removing hearing instruments......14

Program and Multi-Function buttons ........16

Flight mode* (Wireless models only) . . . . . . . . . 19

Telephone use..........................20

Listen to radio or TV .....................21

Using hearing instruments with iPhone®,

iPad®, and iPod touch® ...................21

Cellular phones .........................21

PhoneNow ............................22

Telecoil (optional)........................24

Tele-loop systems .......................24

Direct audio input (optional) ...............24

Connecting/Disconnecting audio boots ......25

Care and maintenance ...................26

Daily maintenance.......................27

The receiver tube .......................28

Cleaning the receiver tubes and domes ......28

Cleaning RIE or molds ...................28

Changing wax guard for receiver tube .......29

How to apply domes.....................30

Using hearing instruments with smart

phone apps............................31

General precautions .....................31

400846011US-17.10-Rev.A.indd 8 02-10-2017 14:46:59

General warnings .......................32

Tinnitus Sound Generator (TSG) module .....34

Intended use for the TSG module ...........34

User instructions for the TSG module ........34

Using TSG with smart phone apps ..........36

The scientiﬁc concepts that form the basis for

the device .............................36

Technical Speciﬁcations ..................37

TSG warnings ..........................38

TSG precautions........................38

TSG warning to hearing healthcare

professionals...........................39

Battery warning information ...............40

Hearing instrument expectations ...........41

Warning to hearing aid dispensers (US Only) ..42

Important notice for prospective

hearing aid users (US Only)................42

Children with hearing loss (US Only) ........43

Troubleshooting Guide ...................44

Technical data..........................48

Warranty and repairs ....................52

Temperature test, transport and

storage information ......................52

400846011US-17.10-Rev.A.indd 9 02-10-2017 14:46:59

9, 10

714

13 15

11 12

1. Receiver tube

2. Receiver Open Dome

3. Receiver Tulip Dome

4. Receiver Power Dome

5. RIE mold

6. Sports lock

7. Battery compartment

8. Receiver

9. Push button

10. Volume Control (optional)

11. LP receiver tube

12. MP receiver tube

13. HP receiver tube

14. Model, and serial number (in battery chamber)

15. UP Receiver/Mold

62 models (type BRIE)

400846011US-17.10-Rev.A.indd 10 02-10-2017 14:47:13
