Tripp Lite G1010USB Manual de usuario

Tripp Lite

1111 West 35th Street

Chicago, IL 60609 USA

Telephone: +(773) 869 1234

E-mail: [email protected]

Model #: G1010USB

Digital UPS System with USB Charging Port- Battery backup and protection for computers, audio/video

components and home theater systems

Highlights

1000VA, line-interactive UPS system with 8 outlets provides reliable battery

backup, USB charging port, automatic voltage regulation, EMI/RFI noise

filtering, heavy-duty AC surge protection, coaxial line surge protection and

phone line surge protection

Large LCD status screen shows input voltage, battery capacity and

operational status at a glance (includes back-light and dimmer)

Versatile cabinet supports vertical or horizontal placement; LCD status screen

can be rotated to match

HID-compliant USB port connects to USB-equipped computers for safe,

automatic shutdown during extended blackouts

Maintains 120V nominal output over an input range of 89V to 139V

$200,000 Ultimate Lifetime Insurance (USA, Puerto Rico and Canada only)

for connected equipment

Description

Tripp Lite's G1010USB Line-Interactive Digital UPS System offers automatic voltage regulation, USB charging port, surge suppression, noise

filtering and long-lasting battery support for computers, peripherals, audio/video components and home theater systems.

Supports a 2.4GHz, 2GB RAM, 320GB HDD desktop computer with 20-inch LCD monitor for up to 60 minutes during power failures. Supports

DVR/Receiver Recording component for up to 180 minutes of recording time during power failures. Prevents equipment damage, data loss, viewing

interruptions, lost recordings and loss of component programming. Preserves expensive bulbs in DLP/LCD projectors and projection HDTVs by

supporting vital cooling fans during power failures.

Automatic voltage regulation (AVR) circuits adjust brownouts as low as 89V back to safe levels without draining battery power. Attractive black

cabinet supports horizontal (console) or vertical (tower) placement. Includes 4 battery-supported and protected outlets, plus 4 additional protected

outlets without battery support, for use with laser printers and other peripherals that don't require battery backup.

USB port enables optional safe, unattended system shutdown without data loss during extended power failures (USB cable included). PowerAlert

software available via free download from www.tripplite.com. HID-compliant USB interface enables full integration with built-in power management

and auto shutdown features of Windows and Mac OS X.

RJ11 phone line surge protection jacks protect modems, satellite receivers or other peripherals that use a standard dial-up/DSL phone connection.

HD-compatible 2.2 GHz coaxial jacks protect against surges on CATV, satellite or broadcast antenna connections.

Audible alarm and large LCD screen (orange LCD) indicate input voltage, line power status, battery capacity status, battery low/replace status and

voltage regulation status. LCD screen includes back light and dimmer.

1000VA/500W power-handling capacity. Offers 3 minutes battery runtime with a full load of 1000VA/500W and 10 minutes battery runtime with a half

load of 500VA/250W.

$200,000 Ultimate Lifetime Insurance for connected equipment (USA, Puerto Rico and Canada only).

Applications

Protects and support computers, peripherals, TVs, HDTVs (LCD, DLP, Plasma), A/V projectors (LCD, DLP), stereo & surround sound

receivers, DVD players/recorders, CD players/recorders, MP3 players, VCRs, DVRs (TiVo), cable /satellite receivers, video game consoles,

Media Center/home theater PCs and more.

Package Includes

G1010USB Digital UPS System

USB cable and phone cord

Owner's manual with warranty information

Features

LCD status screen with back light and dimmer indicates input voltage, battery capacity and a variety of operating conditions in real time.

LCD status screen can be rotated for easy viewing whether the UPS system is in vertical or horizontal position.

Uninterruptible Power Supply offers automatic voltage regulation, surge suppression, noise filtering and long-lasting battery backup.

USB charging port that delivers up to 750mA of charge current for use with cell phones, Smart phones, MP3 players and other devices that

are compatible with USB chargers.

Supports a 2.4 GHz, 2GB RAM, 320GB HDD desktop computer with 20-inch LCD monitor for up to 60 minutes during power failures.

Supports DVR/Receiver Recording component for up to 180 minutes of recording time during power failures. Prevents equipment damage,

data loss, viewing interruptions, lost recordings and loss of component programming. Preserves expensive bulbs in DLP/LCD projectors

and projection HDTVs by supporting vital cooling fans during power failures.

Automatic voltage regulation (AVR) circuits adjust brownouts as low as 89V back to safe levels without draining battery power.

Includes 4 battery-supported and protected outlets, plus 4 additional protected outlets without battery support, for use with laser printers

and other peripherals that don't require battery backup.

USB port and included cable enable safe, unattended shutdown during extended power failures.

HID-compliant USB interface enables full integration with built-in power management and auto shutdown features of Windows and Mac OS

PowerAlert UPS management software available as a free download from www.tripplite.com/software .

Single-line phone surge suppression protects standard dial-up/DSL phone connection.

1000VA/500 watt power handling capacity supports a variety of sensitive computer, home theater and other equipment.

3 minutes full load runtime (1000VA/500 watts), 10 minutes half load runtime (500VA/250 watts).

Attractive black cabinet adapts to vertical (tower) format or horizontal (console) format; 2U rack format requires an optional shelf, available

separately.

$200,000 Ultimate Lifetime Insurance (USA, Puerto Rico and Canada only) for connected equipment.

Specifications

OUTPUT

Frequency

compatibility

60 Hz

Output VA 1000

Output watts 500

Output nominal

voltage

120V AC

Output voltage

regulation

BATTERY MODE: PWM sine wave 115V +/-5%

Output frequency

regulation

LINE MODE: Passes line frequency of 60Hz +/-10% BATTERY MODE: Inverter output regulated to 60Hz +/-0.5Hz

Outlet quantity / type 8 NEMA 5-15R

INPUT

UPS Input cord

length (ft.)

6 ft / 1.8 m

UPS Input cord

length (m)

1.83

Recommended

Electrical Service

120V 15A

Maximum Input Amps

(A)

Input connection type NEMA 5-15P

Voltage compatibility

(VAC)

120

BATTERY

DC system voltage

(VDC)

Replacement battery

cartridge (internal

UPS battery

replacement)

RBC51

Battery Access Yes

Full load runtime 3 minutes (1000VA / 500W)

Half load runtime 10 minutes (500VA / 250W)

Typical battery

lifespan

4-6 years (depending on usage)

VOLTAGE REGULATION

Voltage regulation

description

Line-interactive voltage regulation corrects brownouts as low as 89V back to safe values

Brownout correction Brownouts as low as 89V are boosted by 14%

LEDS ALARMS & SWITCHES

Alarms Audible alarm indicates loss of utility power. Alarm can be silenced by pressing front panel mute button. Once

silenced, alarm will re-sound when approximately 2 minutes of runtime remain.

Switches Includes 2 front panel buttons - one main on/off power switch and one dual function mute / self test button. Also

includes dimmer control to adjust the brightness of the LCD status screen.

Front panel LEDs Front-panel LCD status screen with adjustable blue backlight offers continuous input voltage data, plus UPS status

information on power conditions, battery conditions, battery charge level and voltage regulation operation.

SURGE / NOISE SUPPRESSION

UPS AC suppression

joule rating

1038 joules

EMI / RFI AC noise

suppression

Yes

AC suppression

response time

Instantaneous

Dataline suppression Phone (Tel/DSL) and Coaxial

PHYSICAL

Shipping Dimensions

(HWD/in)

10.43 x 15.55 x 4.84 (unit carton)

Shipping Dimensions

(HWD/cm)

26.49 x 39.50 x 12.29

Shipping weight (lbs) 15.75

Shipping weight (kg) 7.14

Unit Dimensions

(HWD/in)

11.84 x 3.66 x 7.24

Unit Dimensions

(HWD/cm)

30.07 x 9.30 x 18.39

Unit weight (lbs) 15.50

Unit weight (kg) 7.03

Cooling method Convection

Material of

construction

ABS

Form factors

supported

Tower, desktop, console

ENVIRONMENTAL

Relative Humidity 0 to 95%, non-condensing

COMMUNICATIONS

WatchDog

compatibility

Yes, compatible with Tripp Lite's Watchdog system service to restore operation to locked equipment through soft

reboot of application / OS or hard power off/on reboot of connected equipment ideal for unattended kiosk

applications.

Network monitoring

port

USB (HID)

Software and cabling

included

USB cable and phone cord included. Free PowerAlert Software available via Web download

LINE / BATTERY TRANSFER

Transfer time from

line power to battery

mode

2-4 milliseconds

Low voltage transfer

to battery power

Switches to battery power as line voltage decreases to 89V or less, switches back to AC mode as line voltage

increases to 94V or higher

High voltage transfer

to battery power

Switches to battery mode as line voltage increases to 139V or higher, switches back to AC mode as line voltage

decreases to 135V or lower

SPECIAL FEATURES

Appearance New industrial cabinet with attractive black color scheme

CERTIFICATIONS

Certifications Tested to UL1778 (USA & Canada) by TUV and ETL; NOM (Mexico); FCC Class B (Emissions); FCC part 68 (US &

Canada); RoHS compliant

WARRANTY

Product Warranty

Period (Worldwide)

2-year limited warranty

Optional Coverage 3 Year: WEXT3-500-1500, 5 Year: WEXT5-500-1500

Connected

Equipment Insurance

(U.S., Canada &

Puerto Rico)

$200,000 Ultimate Lifetime Insurance

More information, including related products, owner's manuals, and additional technical specifications, can be found online at

www.tripplite.com/en/products/model.cfm?txtModelID=4848.

improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.
