Tripp Lite PDUMH30HV Manual de usuario

Single Phase Metered PDU, 5/5.8kW 30A 208/240V,

2U Horizontal Rackmount, 16 C13 and 2 C19 outlets,

L6-30P input plug

MODEL NUMBER: PDUMH30HV

Description

Tripp Lite single phase Metered PDU / Power Distribution Units offer real-time local reporting of load level in

amps via built-in digital current metering. Enables visual monitoring of PDU output current to preserve proper

output balance and prevent circuit overloads as additional equipment is added. Offers reliable rackmount multi-outlet power distribution from any protected

UPS, generator or mains input power source. High quality design includes rugged all-metal housing and secure rackmount installation with included mounting

accessories.

Features

30A single phase 208/240V Metered Power Distribution Unit / PDU (Agency derated to 24A continuous)

Set of two lighted meters report PDU output current in amps for each 9 outlet load bank

Attached NEMA L6-30P 30A 208/240V input plug and 12ft / 3.6m cord

2U horizontal rackmount format installs in two rack spaces

18 output receptacles (16 C13, 2 C19)

Outlets are arranged in two 9 outlet load banks, each with separate 20A breaker and current metering

Mounting flanges support installation in 2 and 4 post racks, with additional support for wall-mount and under-counter installation formats

Cord retention brackets keep vital equipment plugs connected

Grounding lug

TAA Compliant Version Available - Order Tripp Lite PDUMH30HVTAA

Specifications

OVERVIEW

PDU Type Metered

Highlights

Metered single phase 30A

208/240V 2U horizontal

rackmount PDU

Two built-in meters report output

current in amps for each load

bank

Attached 12ft / 3.6m cord with

NEMA L6-30P input plug

18 total outlets (16 C13, 2 C19)

Reversible housing, 2U 208/240V

rackmount metered PDU

Applications

Ideal for network configurations

requiring a metered PDU

Package Includes

2U rack PDU

Mounting brackets

Plug retention plates

User manual

1 / 4

OUTPUT

Output Capacity Details 5kW (208V input), 5.8kW (240V input), 4.8kW (200V input); 30A maximum (agency de-rated to 24A continuous)

Frequency compatibility 50 / 60 Hz

Output nominal voltage 200-240V nominal, single phase

Overload protection Outlets are arranged in two 9 outlet load banks; each load bank is protected by a separate 20A circuit breaker

Outlet quantity / type 16 C13 and 2 C19 outlets

Outlet Type IEC-C13, IEC-C19

INPUT

PDU Input Voltage 200; 208; 240

Maximum Input Amps (A) 30

Maximum Input Amps (A) Details Agency de-rated to 24A continuous

PDU Plug Type NEMA L6-30P

Input cord length (ft.) 12

Input cord length (m) 3.65

Phase Single-Phase

LEDS ALARMS & SWITCHES

Switches n/a

PHYSICAL

Shipping Dimensions (HWD/in) 8 x 20.5 x 17

Shipping Dimensions (HWD/cm) 20.3 x 52.1 x 43.2

Shipping weight (lbs) 16.9

Shipping weight (kg) 7.7

Unit Dimensions (HWD/in) 3.5 x 17.5 x 12.5

Unit Dimensions (HWD/cm) 8.8 x 44.4 x 31.8

Unit weight (lbs) 13.7

Unit weight (kg) 6.2

Material of construction Steel

Style Rackmount

Form factors supported 2U rackmount; mounting accessories included

PDU Form Factor Horizontal (1U, 2U, etc)

ENVIRONMENTAL

2 / 4

Relative Humidity 0-95% non-condensing

CERTIFICATIONS

TAA Compliant Option TAA Compliant Version Available - Order Tripp Lite PDUMH30HVTAA

Certifications Tested to UL 60950-1 (USA, Canada), Class A (Emissions), NOM (Mexico), RoHS compliant

WARRANTY

Product Warranty Period (Worldwide) 2-year limited warranty

Related Items

Optional Products

Model Number Description Qty.

P004-002-13LA AC Power Extension Cable - C13 Left Angle to C14 - 2' 1

P004-002-13RA AC Power Extension Cable - C13 Right Angle to C14 - 2 ft. 1

P036-002-20LA 2-ft. 12AWG Heavy Duty Power cord (IEC-320-C19 to IEC-320-C20 Left Angle) 1

P036-002-20RA 2-ft. 12AWG Heavy Duty Power cord (IEC-320-C19 to IEC-320-C20 Right Angle) 1

P005-12N 1-ft. (12 in.) Heavy-Duty 14AWG Power Cord (IEC-320-C13 to IEC-320-C14) 1

P005-18N 1.5-ft. (18 in.) Heavy-Duty 14AWG Power Cord (IEC-320-C13 to IEC-320-C14) 1

P005-002 2-ft. Heavy-Duty 14AWG Power cord ( IEC-320-C13 to IEC-320-C14) 1

P004-002-5 5-Pack of 2-ft. 18AWG Power cord (IEC-320-C14 to IEC-320-C13) 1

P004-004 4-ft. 18AWG Power cord (IEC-320-C14 to IEC-320-C13) 1

P004-004-BL 4-ft. 18 AWG Power Cord (IEC-320-C14 to IEC-320-C13) with Blue Connectors 1

P004-004-GN 4-ft. 18 AWG Power Cord (IEC-320-C14 to IEC-320-C13) with Green Connectors 1

P004-004-RD 4-ft. 18 AWG Power Cord (IEC-320-C14 to IEC-320-C13) with Red Connectors 1

P004-004-YW 4-ft. 18 AWG Power Cord (IEC-320-C14 to IEC-320-C13) with Yellow Connectors 1

P004-006 6-ft. 18AWG Power cord (IEC-320-C14 to IEC-320-C13) 1

P004-006-2C13 6-ft. AC Power Extension Splitter Cable ( C14 to 2 x C13 ) 1

P005-006 6-ft. Heavy-Duty 14AWG Power cord (IEC-320-C13 to IEC-320-C14) 1

P005-006-BL 6-ft. Heavy-Duty 14AWG Power cord (IEC-320-C13 to IEC-320-C14) Blue Connectors 1

P005-006-GN 6-ft. Heavy-Duty 14AWG Power cord (IEC-320-C13 to IEC-320-C14) Green Connectors 1

P005-006-RD 6-ft. Heavy-Duty 14AWG Power Cord (IEC-320-C13 to IEC-320-C14) with Red Connectors 1

P005-006-YW 6-ft. Heavy-Duty 14AWG Power cord (IEC-320-C13 to IEC-320-C14) Yellow Connectors 1

P004-010 10-ft. 18AWG Power cord (IEC-320-C14 to IEC-320-C13) 1

P005-010 10-ft. Heavy-Duty 14AWG Power cord (IEC-320-C13 to IEC-320-C14) 1

3 / 4

P047-002 2-ft. 14AWG Heavy Duty Power cord (IEC-320-C19 to IEC-320-C14) 1

P047-004 4-ft. 14AWG Heavy Duty Power cord (IEC-320-C19 to IEC-320-C14) 1

P047-006 6-ft. 14AWG Heavy Duty Power cord (IEC-320-C19 to IEC-320-C14) 1

P047-010 10-ft. 14AWG Heavy Duty Power cord (IEC-320-C19 to IEC-320-C14) 1

P036-002 2-ft. 12AWG Heavy Duty Power cord (IEC-320-C19 to IEC-320-C20) 1

P036-006 6-ft. 12AWG Heavy Duty Power cord (IEC-320-C19 to IEC-320-C20) 1

P036-006-2C19 6-ft. AC Power Splitter Cable ( C20 to 2 x C19 ) 1

More information, including related products, owner's manuals, and additional technical specifications, can be found online at:

http://www.tripplite.com/sku/PDUMH30HV.

Specifications are subject to change without notice. Photos may differ slightly from final products.

4 / 4
