OWNER’S MANUAL

TRINITY DOUBLE-SIDED MOBILE BIN RACK

Model # TXK-1701

Everything in its place.®

Your TRINITY Double-Sided Mobile Bin Rack should include the following parts. Please inspect

box contents to ensure you have received all components.

If you are missing any parts, need assistance with assembly or have questions, please contact

TRINITY Customer Service: 800.985.5506 or customerservice@trinityii.com. Parts can also be

requested online at www.trinityii.com (Help & More, Contact Us).

A Phillips head screwdriver is required.

BOTTOM SHELF (1)

w/ CASTERS

TOP SHELF (1)

B C

HANGING BAR

SUPPORT (1)

POST (2)

W/ SCREWS

LARGE

SCREW (20)

HANGING BAR (7)

PARTS LIST

POST SUPPORT (4)

SPLIT

WASHER (20)

FLAT

WASHER (20)

SMALL

SCREW (7)

SMALL BIN (64)

MEDIUM BIN (30)

ASSEMBLY INSTRUCTIONS

Secure a diagonal POST SUPPORT(D)

to each side of the POSTS (C) with the

LARGE SCREWS (G), SPLIT

WASHERS (H) and FLAT WASHERS (I).

Screw one end of each diagonal POST

SUPPORT (D) into the POST (C) and the

other end into the BOTTOM SHELF (A).

Insert both POSTS (C) into the BOTTOM

SHELF (A). Make sure that the screws on

the POSTS (C) are facing INWARD, and

that the “UP” sticker end of the POST (C)

is at the top. Line up the nuts on the

POSTS (C) with the holes on the side of

the BOTTOM SHELF (A). Insert a LARGE

SCREW (G) through SPLIT WASHER (H)

then FLAT WASHER (I) and hand fasten

to nut on the POSTS (C). Loosely secure

both POSTS (C). Do NOT tighten

completely until STEP 4.

STEP 1

STEP 2

H (6) I (6)

C (2)

A (1)

G (6)

D (4) H (8) I (8)

G (8)

Phillips

ASSEMBLY INSTRUCTIONS

Loosen the screws on the inside of both

POSTS (C) so that the HANGING

BARS (E) can be inserted. Starting with

the lowest BAR (E), insert all BARS (E)

in the same direction.

The "L" (left) stickers on the HANGING

BARS (E) indicate proper positioning

so that the HANGING BAR SUPPORT

(F) can be properly installed in Step 5.

Slide the HANGING BARS (E) in, and

then down as shown. Tighten the

screws on both POSTS (C).

STEP 3

E (7)

Slide the TOP SHELF (B) onto the top of

both POSTS (C) and secure it with the

LARGE SCREWS (G), SPLIT

WASHERS (H) and FLAT WASHERS (I)

on both sides.

Tighten all LARGE SCREWS (C),

including LARGE SCREWS (C) at the

bottom of POSTS (C) from STEP 1.

STEP 4

B (1) H (6) I (6)

G (6)

ASSEMBLY INSTRUCTIONS

Attach the HANGING BAR SUPPORT (F)

to the HANGING BARS (E) with the

SMALL SCREWS (J). The HANGING

BAR SUPPORT (F) should be flush

against the HANGING BARS (E), and the

U-shaped channel should be facing out.

The "UP" sticker indicates proper

positioning.

STEP 5

J (7)

Secure each BIN (K+L) in place

by pressing one thumb against

the inside back of the BIN (K+L)

and press firmly onto the

HANGING BAR (E) until the

back lip of the BIN (K+L)

catches the top of the

HANGING BAR (E). Be sure to

place the rows of BINS (K+L)

from the bottom up. The

SMALL BINS (K) belong on the

top (4) HANGING BARS (E),

while the MEDIUM BINS (L)

belong on the bottom

HANGING BARS (E).

Note: Do NOT load items into

BINS (K+L) before hanging on

Rack.

STEP 6

F (1)

L (30)

K (64)

SERVICE PARTS LIST –TXK-1701

Part Number Description Part Number Description

1) PBK-03-015-3614 Top Shelf 8) ZSV-99-002-3010 Non-locking Caster

2) PBK-04-016-4475 Post 9) PBK-03-016-3620 Bottom Shelf

3) ZBK-01-004-0615 Large Screw 10) PBK-13-005-3375 Hanging Bar

4) XSV-01-020-0608 Split Washer 11) PBK-19-002-3725 Hanging Bar Support

5) XSV-01-019-0612 Flat Washer 12) ZBK-01-004-0410 Small Screw

6) PBK-19-001-0900 Post Support 13) XOR-21-007-0403 Small Bin

7) ZSV-99-004-3010 Locking Caster 14) XGR-21-007-0605 Medium Bin

TRINITY Customer Service provides the following replacement parts:

WARNINGS

1. Read and understand all instructions. Failure to follow all instructions may result in

injury and/or damage.

2. The warnings, cautions, and instructions discussed in this manual cannot cover

all possible conditions or situations that may occur. The user must always be

aware of their environment and ensure that they use the product in a safe and

responsible manner.

3. Do NOT modify the product in any way. Unauthorized modification may impair the

function and/or safety of the product, and may affect the life of the product.

4. Check for damaged parts. Before using this product, carefully check that all parts are

in good condition, and that the product will operate properly and perform its intended

function. Check for damaged parts and any other conditions that may affect the

operation of this product. Replace damaged or worn parts, and never use this product

with a damaged part.

5. Store the bin rack in a secure place out of the reach of children when not in use.

6. If storing the bin rack for a long time, unload the bins to prevent cracking over

time.

7. Do NOT overload the product.

CARE AND MAINTENANCE

•Avoid harsh, abrasive cleaners, and other corrosive chemicals.

•Do not use scouring pad for cleaning.

•Keep the bins, shelves and rack dry, clean, and free from oil and grease.

•Use only identical replacement parts for the bin rack. Parts that may be suitable for

one tool may create a risk of injury when used with another tool.

Small Bin capacity 2 lb

Medium Bin capacity 4 lb

Total weight capacity 330 lb

Thank you for purchasing a TRINITY Double-Sided Mobile Bin Rack. In order to register your

product and receive streamlined customer service, please fill out the following Product

Registration Form and (1) fax the form to 310.347.4134 (2) complete the Product Registration

Form online at www.trinityii.com or (3) scan and email the form to

customerservice@trinityii.com. Include a copy of your original receipt with your submission.

First Name: Last Name:

Address:

City: State: Zip Code:

Email Address: Phone:

Product Model #: TXK-1701 Purchase Date: / /

Location of Purchase:

Please rate the importance of each feature (1=least important; 10=most important)

Quality Price Size/Capacity Appearance Other

How did you hear about our product?

Magazine Ad Catalog Salesperson Word of Mouth

Internet Store Display Other

Marital Status: Single Married

Household Income: Below $50,000 $50,000-$150,000 $150,000+

Education: High School College Graduate School

Primary Residence: Own Rent

Comments/Suggestions:

PRODUCT REGISTRATION
