TRENDnet TI-IG60 Manual de usuario

TI-IG30/TI-IG60

Quick Installation Guide

English

1. Before You Start

2. Quick Reference

3. Hardware Installation

4. Additional information

Table of Content

ENGLISH

FRANÇAIS

DEUTSCHEESPAÑOL

РУССКИЙ

1. Before You Start

2. Quick Reference

Package Contents

ŸTI-IG30/TI-IG60

ŸQuick Installation Guide

ŸRemovable terminal block

ŸDIN-rail mount

ŸWall mount kit

Minimum Requirements

ŸExisting network

ŸPower Supply (TI-S12048)

TV-IP450PI TI-S12048

TEG-S80g

ENGLISHFRANÇAISDEUTSCHE

ESPAÑOLРУССКИЙ

3. Hardware Installation

The PoE+ injector can be placed on a desktop, wall, or mounted to a DIN-Rail.

DIN-rail Mounting Instructions

1. Attach the DIN-Rail mount to the PoE+ injector.

2. Position the unit in front of the DIN-Rail and hook the mount bracket over the top of the rail.

3. Rotate the fiber converter downward towards the rail to lock it into place. You will know it is

secure when you hear the click.

Mounting the unit Releasing the unit

4. To remove the unit, pull down to clear the bottom of the DIN-Rail and rotate up, away from

the rail.

ENGLISH

FRANÇAIS

DEUTSCHEESPAÑOL

РУССКИЙ

Wall Mounting Instructions

1. Attach the wall mount plates to PoE+ injector.

2. Mount the switch.

Safety Note

ŸTurn off the power before connecting any module or wire. The correct power supply voltage

(48 - 56 V DC) is listed on the product label. Check the voltage of your power source to make

sure that you are using the correct part. Do NOT use voltage greater than 48 - 56 V DC, the

product label.

ŸCalculate the maximum possible current in each power wire and common wire. Observe all

electrical codes dictating the maximum current allowable for each wire size. If the current

surpasses the maximum ratings, the wiring could overheat, causing serious damage to your

equipment.

ENGLISHFRANÇAISDEUTSCHE

ESPAÑOLРУССКИЙ

3. Connect a network source and devices to the switch. Check the LEDs to confirm the

connections are established. Your installation is completed.

Applying Power

1. Connect the power supply (sold separately) to the included terminal block (as shown below)

and secure with the screws.

Note: Polarities must match.

2. Attach the terminal block to the unit, connect the neutral wire to the ground, and supply power

to the power adapter.

+V1- +V2-

ENGLISH

FRANÇAIS

DEUTSCHEESPAÑOL

РУССКИЙ

4. Additional information

DIP Switch (TI-IG60 ONLY)

2 pair 30w

4 pair 60w

Dip 1

Mode A End-Span is selected (Default)

Mode B Mid-Span is selected

Dip 2

High power 36w

IEEE802.3 at 30w

Reserved (default)

Reserved

Dip 3

Dip 4

Res

OFF

Directives:

Low Voltage Directive 2006/95/EC

EMC Directive 2004/108/EC

RoHS Directive 2011/65/EU

REACH Regulation (EC) No. 1907/2006

TRENDnet hereby declare that the product is in compliance with the essential requirements and

other relevant provisions under our sole responsibility.

This product is herewith confirmed to comply with the Directives.

Product Information:

Product Name:

Model Number: TI-IG30 / TI-IG60

Trade Name: TRENDnet

Hardened Industrial 30 Watt Gigabit PoE+ Injector

Hardened Industrial 60 Watt Gigabit PoE+ Injector

Safety EN 60950-1: 2006 + A11: 2009 + A1: 2010 + A12: 2011 + A2: 2013

EMC

Person responsible for this declaration.

Date: August 2, 2015

Title: Director of Technology

Place of Issue: Torrance, California, USA

Name: Sonny Su

Signature:

TRENDnet, Inc.

20675 Manhattan Place

Torrance, CA 90501 USA

Manufacturer’s Name and Address

EN 55022: 2010 + AC: 2011 Class A

AS/NZS CISPR 22: 2009 + A1:2010 Class A

EN 55024: 2010

CISPR 22: 2008 + Is1: 2009 + IS2: 2010 + Corr: 2012 Class A

Limited Warranty

TRENDnet warrants its products against defects in material and workmanship, under normal use and service.

Specific warranty periods are listed on each of the respective product pages on the TRENDnet website.

Garantie Limitée

TRENDnet garantit ses produits contre les problèmes de matériel ou de fabrication, dans des conditions normales

d'utilisation et de service. Les périodes de garanties précises sont mentionnées sur chacun des pages produits

du site web de TRENDnet.

Eingeschränkte Garantie

TRENDnet gewährt eine Garantie für seine Produkte im Falle von Material- und Bearbeitungsdefekten, bei

normaler Verwendung und Wartung. Spezielle Garantiezeiträume werden auf jeder Produktseite auf der Website

von TRENDnet genannt.

Garantía limitada

TRENDnet garantiza que sus productos carecen de defectos en el material y la fabricación, en condiciones de uso

y funcionamiento normales. Los periodos específicos de garantía figuran en cada una de las páginas de producto

del sitio web de TRENDnet.

Ограниченная гарантия

Компания TRENDnet предоставляет гарантию на свои изделия от дефектов материалов и сборки при

нормальном использовании и обслуживании. Конкретные гарантийные сроки указаны на странице

каждого продукта на сайте компании TRENDnet.

Garantia Limitada

A TRENDnet garante seus produtos contra defeitos de material e mão de obra sob condições normais de uso e

serviço. Os períodos de garantia específicos estão listados em cada uma das páginas dos respectivos produtos

no site da TRENDnet.

Piiratud garantii

TRENDneti garantii hõlmab materjali- ja koostamisdefekte, mis ilmnevad toote tavapärasel kasutamisel.

Garantiiaja täpne pikkus konkretse toote puhul on leitav TRENDneti kodulehelt vastava toote infolehelt.

Garanzia limitata

TRENDnet garantisce i propri prodotti da difetti di materiali e manodopera, in condizioni di normale uso ed

esercizio. I periodi di garanzia specifici sono elencati sulle rispettive pagine di prodotto sul sito TRENDnet.

Certifications

This device complies with Part 15 of the FCC Rules.

Operation is subject to the following two conditions:

(1) This device may not cause harmful interference.

(2) This device must accept any interference received.

Including interference that may cause undesired operation.

TRENDnet

20675 Manhattan Place

Torrance, CA 90501

USA

Applies to PoE Products Only: This product is to be connected

only to PoE networks without routing to the outside plant.

Note

The Manufacturer is not responsible for any radio or TV

interference caused by unauthorized modifications to this

equipment. Such modifications could void the user’s authority

to operate the equipment.

Advertencia

En todos nuestros equipos se mencionan claramente las

caracteristicas del adaptador de alimentacón necesario para

su funcionamiento. El uso de un adaptador distinto al

mencionado puede producir daños fisicos y/o daños al equipo

conectado. El adaptador de alimentación debe operar con

voltaje y frecuencia de la energia electrica domiciliaria exitente

en el pais o zona de instalación.

Product Warranty Registration

Please take a moment to register your

product online. Go to TRENDnet’s website at:

www.trendnet.com/register

Technical Support

If you have any questions regarding the product

installation, please contact our Technical Support.

Toll free US/Canada: 1-866-845-3673

Regional phone numbers available

at www.trendnet.com/support

Waste electrical an electronic products must not

be disposed of with household waste. Please

recycle where facilities exist. Check with your

Local Authority or Retailer for recycling advice.
