TRENDnet TEG-524WS Manual de usuario
TEG-524WS (V1)
Quick Installation Guide
Table of Contents
1 English
1. Before You Start
2. Hardware Installation and Configuration
ENGLISHFRANÇAISDEUTSCH
ESPAÑOLРORTUGUÊS
1
1. Before You Start
Package Contents
ŸTEG-524WS
ŸQuick Installation Guide
ŸCD-ROM (Utility and User's Guide)
ŸPower cord (1.8m / 6 ft.)
ŸRack mount kit
Minimum Requirements
ŸComputer with an Ethernet port and web browser
ŸNetwork cable
Optional Equipment
ŸEIA standard 19” rack
ŸMini-GBIC modules (e.g. TEG-MGBSX, TEG-MGBS10, TEG-MGBS40,TEG-MGBS80)
2. Hardware Installation and Configuration
3. Assign a Static IP address to your computer's network adapter in the subnet of 192.168.10.x
(e.g. 192.168.10.25) and a subnet mask of 255.255.255.0.
4. Open your web browser, type the IP address of the switch in the address bar, and then press
Enter. The default IP address is 192.168.10.200.
2
http://192.168.10.200
http://192.168.10.200
1
2
TEG-524WS
ENGLISHFRANÇAISDEUTSCH
ESPAÑOLРORTUGUÊS
7. Configure the switch to match the requirements of your network. Then click Apply.
5. Enter the User name and Password, and then click Login. By default:
User Name: admin
Password: admin
Note: User Name and Password are case sensitive.
8. Click OK.
6. Click System and then click IPv4 Setup.
3
WARNING
The management session will be disconnected. Use new
IP address to connect to device.
Cancel
OK
OK
Switch Info
System
§ System Management
§ IPv4 Setup
§ IPv6 Setup
§ IPv6 Neighbor
§ IP Access List
§ Administration
§ Timeout
§ System Time
§ SSL
§ DHCP Auto Configuration
§ DNS
IPv4 Setup
System MAC
Address:
System IP Address:
System Subnet
Mask:
System Default
Gateway:
System IP Mode:
00:01:02:03:04:05
192 168 10 200
. ..
. ..
. ..
255 255 255 0
0000
Apply
Static
IPv4 Setup
4
10. Click Save Settings to Flash (button).
Note:
1. If you would like to easily discover all the Web Management Switches on the network, assign
IP Address, change the password, and upgrade new firmware, then install the Web Smart
Switch Management Utility. Follow the steps provided on the User's Guide.
2. For detailed information regarding the TEG-524WS’s configuration and advanced settings,
please refer to the User's Guide on the provided CD-ROM.
11. Click OK.
WARNING
Save configuration finished.
OK
Switch Info
System
Network
Security
Tools
Firmware Upgrade
QoS
Backup/Restore
Configuration
Save
Diagnostics
Reboot
Ping
Note: The switch will stop responding while saving the current configuration to flash.
Save Settings to Flash
Save Settings to Flash
Save Settings to Flash
Save
9. In the left hand panel, click Tools, click on Configuration, and click Save.
Manufacturer’s Name and Address
TRENDnet, Inc.
20675 Manhattan Place
Torrance, CA 90501 USA
Zwolsestraat 156 2587 WB
The Hague The Netherlands
Product Information:
Product Name:
Model Number:
Trade Name:
Safety
EN 55032:2012+AC: 2013 (CISPR32:2012) (Class A)
EN 61000-3-2:2014
EN 61000-3-3:2013
EN 55024:2010
AS/NZS CISPR 32:2013
Directives
Date: July 12, 2017
Title: Director of Technology
Person responsible for this declaration.
Place of Issue: Torrance, California, USA
Name: Sonny Su
Signature:
EMC Directive 2014/30/EU
RoHS Directive 2011/65/EU
WEEE Directive 2012/19/EU
REACH Regulation (EU) No. 1907/2006
Low Voltage Directive 2014/35/EU
TRENDnet hereby declare that the product is in compliance with the essential requirements
and other relevant provisions under our sole responsibility.
EN 60950-1:2006+A11:2009+A1:2010+A12:2011+A2:2013
EMC
This product is herewith confirmed to comply with the Directives
TRENDnet
TEG-524WS
52-Port Gigabit Web Smart Switch
Certifications
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received.
Including interference that may cause undesired operation.
TRENDnet
20675 Manhattan Place
Torrance, CA 90501
USA
Applies to PoE Products Only: This product is to be connected
only to PoE networks without routing to the outside plant.
Note
The Manufacturer is not responsible for any radio or TV
interference caused by unauthorized modifications to this
equipment. Such modifications could void the user’s authority
to operate the equipment.
Advertencia
En todos nuestros equipos se mencionan claramente las
caracteristicas del adaptador de alimentacón necesario para
su funcionamiento. El uso de un adaptador distinto al
mencionado puede producir daños fisicos y/o daños al equipo
conectado. El adaptador de alimentación debe operar con
voltaje y frecuencia de la energia electrica domiciliaria exitente
en el pais o zona de instalación.
Product Warranty Registration
Please take a moment to register your
product online. Go to TRENDnet’s website at:
www.trendnet.com/register
Technical Support
If you have any questions regarding the product
installation, please contact our Technical Support.
Toll free US/Canada: 1-866-845-3673
Regional phone numbers available
at www.trendnet.com/support
Waste electrical an electronic products must not
be disposed of with household waste. Please
recycle where facilities exist. Check with your
Local Authority or Retailer for recycling advice.
Copyright © 2017. All Rights Reserved. TRENDnet. TEG-524WS (V1) / 07.12.2017
