TRENDnet TE100 S800i Manual de usuario
TE100-S800i
TE100-S810Fi
Quick Installation Guide
English ......................................................................................................
Troubleshooting ........................................................................................
1
1
2
3
5
1. Before You Start
2. How to Connect .................................................................................
3. Using the Switch ................................................................................
.................................................................................
Table of Contents
Version 10.13.05
System Requirements
1. Workstations with network cards
2. TCP/IP protocol installed in all workstations
3. A web browser such as Internet Explorer or Netscape Navigator
4. RJ-45 Network Patch Cable to connect your workstations to the
TE100-S800i/TE100-S810Fi
TE100-S800i/TE100-S810Fi
AC power cord
RS-232 cable
Quick Installation Guide
User’s Guide CD-ROM
Package Content
(TE100-S800i)
8-Port 10/100Mbps Layer 2 Managed Switch
or
(TEG-S810Fi)
8-Port 100Base-FX Layer 2 Managed Switch with 100Base-FX Port
Workstations with 32-bit PCI
Fast Ethernet Card
(TE100-PCIWA)
Accounting
Department
Internet
Servers with 32-bit PCI
Fast Ethernet Card
(TE100-PCIWA)
Servers with 32-bit PCI
Fast Ethernet Card
(TE100-PCIWA)
Sales
Department
8-port 10/100Mbps
Fast Ethernet Mini Switch
(TE100-S88Eplus)
5-port 10/100Mbps
Fast Ethernet Mini Switch
(TE100-S5Pplus)
8-port 10/100Mbps
Fast Ethernet Mini Switch
(TE100-S8P)
MIS
Department
100Mbps
1. Before You Start
English
1
2. Connect the network cable to the front of the
switch and your PC.
1. Connect the AC Power cord to the back of
the TE100-S800i/TE100-S810Fi.
3. Verify that the PWR led displays a solid
green light.
2. How to Connect
English
2
1. Go to Start ? Settings ?
Control Panel.
2. Double-Click the Network
Connection Icon.
3. Right-Click Local Area
Connection, and select
Properties.
3. Using the Switch
English
3
Note: For more detail on advanced features, please consult the User's Guide.
Your installation is now complete.
7. Select the appropriate option to
configure the SNMP switch.
6. User Name: root
Password: root
5. Open your web browser, type
http://192.168.16.1, and press
Enter.
4. Click the General tab, select
Internet Protocol(TCP/IP), and
click Properties. Change the IP
address to 192.168.16.222 and
click OK to apply the settings.
English
4
Q1.
A1.
Q2.
A2.
Q3.
A3.
How come I cannot see any light from any of my LED's?
Your TE100-S800i/TE100-S810Fi is not getting any power. Make
sure that your surge protector or your outlet is getting power and make
sure that the AC Power cord is properly connected to your
TE100-S800i/TE100-S810Fi.
I changed my IP settings to 192.168.16.222 to access the switch, but I
still cannot get into the Web configuration page. What should I do?
Make sure there is no other network device using the same IP
address. Afterwards, consult the User's Guide to access the switch
through the Console Port. Once you reach the command line interface,
perform a factory reset and try again.
I performed a factory reset on the TE100-S800i/TE100-S810Fi, but I
still cannot access the web configuration page. What should I do?
If you are configuring more than one TE100-S800i/TE100-S810Fi,
then it is possible that you are experiencing IP conflict between these two
switches. Please configure each switch one at a time, and make sure you
assign a unique IP address to each switch.
If you have any questions regarding the TE100-S800i/TE100-S810Fi, please
contact TRENDnet Technical Support Department.
5
Troubleshooting
Certifications
This equipment has been tested and found to comply with FCC and CE Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received. Including interference that may
cause undesired operation.
NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV
INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS
EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO
OPERATE THE EQUIPMENT.
Waste electrical and electronic products must not
be disposed of with household waste. Please
recycle where facilities exist. Check with you Local
Authority or Retailer for recycling advice.
ADVERTENCIA
En todos nuestros equipos se mencionan claramente las caracteristicas del adaptador de
alimentacón necesario para su funcionamiento. El uso de un adaptador distinto al
mencionado puede producir daños fisicos y/o daños al equipo conectado. El adaptador
de alimentación debe operar con voltaje y frecuencia de la energia electrica domiciliaria
existente en el pais o zona de instalación.
Copyright ©2006. All Rights Reserved. TRENDnet.
Product Warranty Registration
Please take a moment to register your product online.
Go to TRENDnet’s website at http://www.trendnet.com
TRENDnet Technical Support
US Canada
24/7 Tech Support
Toll Free Telephone: 1(866) 845-3673
Europe (Germany France Italy Spain Switzerland UK)
English/Espanol - 24/7
Francais/Deutsch - 11am-8pm, Monday - Friday MET
English/Espanol - 24/7
Francais/Deutsch - 11am-8pm, Monday - Friday MET
Worldwide
Telephone: +(31) (0) 20 504 05 35
Toll Free Telephone: +00800 60 76 76 67
.
. . . . .
20675 Manhattan Place
Torrance, CA 90501
USA
