TRENDnet TE100-P21 Manual de usuario

TE100-P21/TEW-P21G Windows 7 Installation Instruction

1. Go to

Hardware Installation

http://www.trendnet.com/downloads/ to download the Windows 7 Utility. Save the file to

your desktop.

2. Right click on the file and select Extract All. Followthewizard to uncompress the file.

3. Connect a RJ-45 Network cable froma switch/router to the LANportof the PrintServer

4. Connectthe detachable antenna (forTEW-P21G only)

5. Connectthe ACpoweradapterto the PrintServer and then to a power outlet

6. Connect the Printer to the USB or parallel port on the Print Server

7. Power on the Printer

Configure the Print Server

1. Double click on PSUtilitySetup_v3.13.exe

2. Followthe stepsto configure the Print server

b. Click OK

a.Select the Print Server and

click Change IP Address.

Manually assign the IP

Address of the Print

Server and then click OK.

Note:TheIPAddress must

match the network

segment of your network.

e. Unplug the Ethernet cable

and the power adapter from

the print server. Wait 15

seconds, then plug the power

adapter back in (TEW-P21G

only).

d. Click on Configuration,

then Wireless. Select the

proper SSID and then click

Save.(Enableand enter the

encryption key if your

wireless network is

encrypted. Please contact

your Network Administrator

for the encryption

key)(TEW-P21G only).

c. Click Show Web Setup.

1. Double click on PSWizardSetup_v2.20.exe

Add the Printer to your computer

2. Follow the steps to add the printer to your computer

b. Click Select from

manufacturer list.

Select the

appropriate driver for

your printer and then

click Next.

a. Select the print server, select

thedesiredportandthenclick

Add Printer.

Note:

1. If your printer is connect to

USB1, select

PS-XXXXXX-U1. If your

printer is connected to

USB2, select

PS-XXXXXX-U2. If your

printer is connected to

LPT, select

PS-XXXXXX-P3.

2. PS-XXXXXX represents

the Server Name of your

print server. Your print

server will have a different

Server Name.

c. Click Next.

d.ClickPrint Test Page.

e. Click OK.

g. Repeat the above steps to add the

printer to other computers on the

network

f. Click Finish.

Troubleshooting

The PS Wizard / PS Utility is unable to see my printer server. What should I do?

1. Double check your hardware connections; make sure that the print server and printer are poweredON

and are properly connected.

2. Click Discover.

3. Disable any software firewall programs (e.g. ZoneAlarm). Also, disable the built in Windows firewall

program.

My printerdoes not print the entire document. What should I do?

Windows 7

1. Click on the Windows icon on the bottom left-hand corner of the screen.

2. Click Devices and Printers.

3. Right click on the printer and select Printer Properties.

4. Click the Advanced tab.

5. Uncheck Enable advanced printing features.

6. Click Apply.

7. Click OK.

I successfully added a printer to my computer and I can print a test page, but I cannot print anything from

Microsoft Word or other applications.

Make sure the printer is set as your default printer. Click the Windows icon ->Devices and Printers and verify

that your printer icon has a check on it.

I configured my print server to automatically receive an IP Address from a DHCP server, and now I cannot go

into the Print Server’s web utility.

Open PS Wizard (See Add the Printer to your PC) to locate your print server’s IPAddress.

After I successfully configured the TEW-P21G to match my wireless network settings, I can not print through

the Print Server.

1. Verify that the wireless settings match your wireless network settings.

2. Verify that the antenna is attached to the Print Server and the WLAN LED on the Print Server is lit.

I forgot the administration password. How do I reset my print server?

Factory reset the print server using the following procedure. This procedure will reset all settings to default.

By default, there is no password.

1. Take a pin or paper clip and press the reset button. The reset button is located on the back of the unit.

2. Wait 15 seconds, then let go.
